Cartridge Fuse Holders
Enclosed Fuseholders > Panel Mounted
342 Series Panel Mount Enclosed Fuse Holders for 3AG Fuses
General Application Products
Watertight Product
Product Characteristics
General Application
Products
Compatible
Fuses
Electrical
Ambient
Temperature
Dielectric
Strength
Mounting
Molded
Parts
Seal
2400 volts minimum.
Withstands 15 lb.-
in. mounting torque;
maximum panel thickness:
.187”
.
Black thermoplastic
(UL94 V-0).
Not Applicable
Copper & copper alloy.
Tin plated, except
¼” Quick-Connect
terminals are nickel plated.
Comes with a mounting
nut and neoprene washer
3AG
Rated at 20 amperes for any voltage up to 250 volts.
–40ºC to +85ºC.
1500 volts minimum.
Withstands 15 lb.-in.
mounting torque; maximum
panel thickness is .250”
.
Black thermoset
(UL94 V-0).
O-ring provides a watertight
seal on the front side of the
panel per MIL
-PRF-19207
.
Copper & copper alloy.
Tin plated.
O-rings (2) and hex nut,
unassembled.
Watertight Product
Straight Terminal
with Knurled Knob
Right Angle Terminal
with Fluted Knob
Dimensions
General Application / Straight Terminal Product Dimensions
.7"
.78"
.7"
Terminals
.090" X .12"
HOLE
.45"
FLATS
TYP.
1.31"
1"
.3"
1"
.475"
.480"
.032"
.502"
.510"
Hardware
.4"
.020"
.11" DIA.
.69"
HEX
FLATS
Agency Approvals
Agency
Agency File Number
IZLT2.E14721
007316 (*Except 342 006 and 342 012)
.78"
General Application / Right Angle Terminal Product Dimensions
.69" DIA.
.78"
.7"
1"
1"
1"
.475"
.480"
.502"
.510"
DETENT
Ordering Information
body Terminal Type
Angle
Connect
Catalog Number
Fluted Knob
Knurled Knob
.63"
.69"
DIA.
.085" X .12"
HOLE
.020"
.187"
.06" DIA.HOLE
.032"
.45"
FLATS
TYP.
.14" DIA. HOLE
.69"
HEX
FLATS
.56"
.69"
DIA.
TYP.
.250"
General Application Products:
Solder
.59"
342 014
342 038
342 838
342 004
342 028
342 828
342 012
*
342 058
342 858
342 022
342 048
342 848
Straight
3/16” Q.C.
1/4” Q.C.
Solder
Watertight Product Dimensions
.12" DIA.
HOLES
.94"
DIA.
.81"
1.3 "
Right Angle
Watertight Product:
Straight
3/16” Q.C.
1/4” Q.C.
Solder
342 006
*
Not Applicable
NOTE: Ensure that proper fuse de-rating is factored in fuseholder selection.
MOUNTING HOLE
.570"
.575"
"
Additional Information
.81
.625"
.635"
Datasheet
Resources
Samples
© 2013 Littelfuse, Inc.
Specifications are subject to change without notice.
Revised: 12/19/13
