8
7
6
5
4
3
REV
B
2
REVISIONS
DESCRIPTION
UPDATED OUTER BARREL DIMENSION WAS Ø0.200 IS
Ø0.216: uPDATED NOTE 3
1
DATE
11-JUN-13
29-NOV-17
APPV
SAH
CLL
DESCRIPTION MATERIAL
BODY
PIN
INSULATION
D
FINISH
GOLD
GOLD
N/A
BRASS
BeCu
PTFE
A INITIAL RELEASE OF LINX INTERNAL DRAWING
D
1/4-36UNS-2A
THREADS
4X Ø 0.018 DIMPLE(S)
EQUALLY SPACED
0.050
1.27
0.198
5.04
4X S 0.059
1.50
4X S 0.041
1.04
0.100
2.55
0.100
2.55
C
0.212±0.004
5.38±0.10
0.201
5.10
C
0.055
1.40
4X
0.059
1.50
0.310
7.87
0.370
9.40
B
0.150
3.81
0.198
5.04
0.535
13.60
S 0.276
7.00
RECOMMENDED FOOTPRINT
B
SIDE VIEW
BOTTOM VIEW
NOTES: (UNLESS OTHERWISE SPECIFIED)
1. ALL DIMENSIONS ARE IN INCHES [mm].
2. DIMENSIONS APPLY AFTER FINISHING.
3. MANUFACTURE TO BE COMPLIANT WITH EU RoHS DIRECTIVE, USE
MATERIALS THAT DO NOT CONTAIN REACH SUBSTANCES OF VERY
HIGH CONCERN >1000ppm, AND USE DRC CONFLICT-FREE
SOURCED MATERIALS.
4. SAFETY BREAK ALL SHARP CORNERS AND EDGES .02 MAXIMUM.
WARNING:
THIS DRAWING CONTAINS PROPRIETARY INFORMATION
THAT IS THE SOLE PROPERTY OF LINX TECHNOLOGIES, AND SHALL BE
TREATED AS SUCH. NO DISCLOSURE OR REPRODUCTION OF THIS
DOCUMENT IS PERMITTED, IN WHOLE OR IN PART, WITHOUT THE
EXPRESS WRITTEN PERMISSION OF LINX TECHNOLOGIES OR ITS
DESIGNATED AGENTS.
INTERPRET DIMENSIONS AND
TOLERANCES PER ASME Y14.5.
32
A
TITLE:
159 ORT LANE
MERLIN, OR 97532
A
MATERIAL:
PROJECTION:
FINISH:
SURFACE FINISH:
ANGLES: 1
TOLERANCES: .X .1 .XX .01 .XXX .005
SIZE DWG. NO.
RP-SMA FEMALE
PCB MOUNT
DRAWN: B.MURPHY DT: 2-APR-13
CONREVSMA001-G
ENGR: S.HOGAN
DT: 11-JUN-13 SCALE: 6:1
DO NOT SCALE DRAWING
2
1
B
REV
SHEET 1 OF 1
LDCFDFB_C
B
8
7
6
5
4
3
