INTERCONNECTS
SERIES 800 & 801 • 2,54 GRID (0,76 DIA. PINS), STRAIGHT &
RIGHT ANGLE HEADERS AND SOCKETS • SINGLE ROW STRIPS
Number of Pins
X 2,54
2,54
•
Pin interconnects available with straight MM
#7007 or right angle MM #5005 solder tails.
See page 215 for details
0,76 DIA.
4,95
•
Sockets are available with straight MM #1304
or right angle MM #1305 soldertails. See
pages 177 and 179 for details
2,79
0,61 DIA.
3,18
3,0
•
MM #1304 and MM #1305 receptacles use
2,54
FIG. 1
4,95
2,79
Number of Pins
X 2,54
Hi-Rel, 6- nger BeCu #47 contact rated at 4.5
amps. Receptacles accept 0,76 diameter and
0,64 square pins. See page 256 for details
•
Insulators are high temperature thermoplastic,
suitable for all soldering operations
ORDERING INFORMATION
2,54
1,27
0,61 DIA.
0,76 DIA.
4,5
2,54
Series 800...10-001
Straight Pin Header
01-64
3,2
FIG. 1
800 XX 0_ _ 10 001000
Specify number of pins
Series 800...20-001
Right Angle Pin Header
02-64
For
Electrical, Mechanical
& Enviromental Data,
See page 264
FIG. 2
0,64-0,94
0,64 * 0,64
2,54
Number of Pins
X 2,54
FIG. 2
RoHS - 2
800 XX 0_ _ 20 001000
Specify number of pins
XX=Plating Code
See Below
10
0,25µm Au
2011/65/EU
2,24
6,1
6,55 7,01
SPECIFY PLATING CODE XX=
Pin Plating
90
5,08µm Sn/Pb
40
5,08µm Sn
0,61 DIA.
3,0
Series 801...10-001
2,54
FIG. 3
7,01
FIG. 3
801 XX 0_ _ 10 001000
Specify number of pins
01-50
Series 801...20-001
Number of Pins
X 2,54
2,54
O
O
Straight Socket
Right Angle Socket
01-50
For
Electrical, Mechanical
& Enviromental Data,
See page 264
PAGE 54 | INTERCONNECTS
5,8
2,24
FIG. 4
RoHS - 2
801 XX 0_ _ 20 001000
Specify number of pins
XX=Plating Code
See Below
91
93
99
41
1,27
0,61 DIA.
3,2
2011/65/EU
8,31
2,54
SPECIFY PLATING CODE XX=
Sleeve (Pin)
Contact (Clip)
43
44
47
Au Flash
5,08µm Sn/Pb 5,08µm Sn/Pb 5,08µm Sn/Pb
5,08µm Sn 5,08µm Sn 5,08µm Sn 5,08µm Sn
FIG. 4
0,25µm Au 0,76µm Au
2,54µm Sn/Pb
0,25µm Au 0,76µm Au 2,54µm Sn
Mill-Max Mfg. Corp. • 190 Pine Hollow Road, P.O. Box 300, Oyster Bay, NY 11771 • 516-922-6000 • Fax: 516-922-9253 • www.mill-max.com
O
44 Plating Non-Standard
