DATA SHEET
Single Pole High Power Connector
Key Features
•
Technology
Current Rating up to
1000A , Operating Voltage up to
630V
•
Mechanical
38999 Series III or
Bulldog breakaway connector
interface, jam-nut, flange mount and
inline connections, 500+ mating
cycle durability
•
Termination
Crimp, screw or
flathead contact termination
available. Straight or right angled
backshells available for strain relief
and 360° EMC/RFI screening
•
Safety
IP2X, plastic cap on pin
contact to prevent shock
•
Environmental
Aluminium,
Stainless Steel or Aluminium Bronze
shells. Temperature range -55°C to
+125°C, IP68 sealing, plating
dependant, 500 Hrs Salt Spray.
•
RoHS Compliant
Zinc Cobalt and
Zinc Nickel plating finishes available
Amphenol Ltd combines the benefits of field proven Mil-DTL-38999
Series III circular connectors with hyperbolic contacts that extend
the boundaries of high power connector technology. Designed to
meet the latest military and industrial specifications, Rhino 38999
connectors also meet stringent safety requirements.
As one of the foremost manufacturers of both connectors and interconnect systems
specifically for applications within military, aerospace and industrial markets, Amphenol has
recognised a distinct trend towards increased power and voltage requirements within such
applications as military and electric drive vehicles, aircraft and intelligence bases stations.
The use of RADSOK contacts creates an electrical interface that exceeds typical
interconnect requirements via a hyperbolic socket contact construction which distributes
normal forces over a high percentage of the mating surface to ensure a smooth and even
engagement force with exceptionally high performance under vibration. The large surface
area of the socket contact also results in a very low contact resistance enabling much
higher current ratings compared to other power contact designs.
High reliability applications including vehicular, aerospace, industrial, automation, mining,
offshore and other harsh environments can all be addressed using the Rhino 38999 Series.
Amphenol Ltd Thanet Way Whitstable Kent CT5 3JF Tel:+44 (0)1227 773200 info@amphenol.co.uk www.amphenol.co.uk
DATA SHEET
Single Pole High Power Connector
The Rhino 38999 Series provides IP2X finger protection on both plugs and receptacles. Flange Mount, Jam nut or Inline connections
are offered with single pole high reliability, low contact resistance RADSOK contacts and durability up to 500 mating cycles.
Available in a variety of shell materials including aluminium, stainless steel and aluminium bronze, the connectors can be provided in
standard 38999 Series III shells or the new Bulldog breakaway connector style. Overmoulded cable harnesses are also available.
Ordering Information
eg. WPTV-06ZN21-340-#PNX(XXXX)
Series
Style
Plating
Shell Size
and Amp
rating
# = Contact Termination
Contact
Type
Key Way
Accessory Style
WPTV
00 = Wall
Mount
06 = Plug
ZN = Black Zinc Nickel
RW = Cadmium
RF = Nickel
13-85
15-120
17-185
21-340
23-500
1 = Crimp
2 = Threaded Post
3 = Flat tail with cross hole
5 = Tapped hole with locking
flats
6 = Reduced crimp
P = Pin
S = Socket
N
A
B
C
D
E
A = Locking ring only
B = Straight EMC backshell
C = Right angle EMC
backshell
07 = Jam Nut
SS = Stainless Steel
RB = Aluminium Bronze
25-1000
7 = Extra reduced crimp
8 = Further reduced crimp
(XXXX) = Deviation code if applicable
(W586) = Low profile
Typical Applications
• Harsh environment vehicles
• Hybrid and electric drive vehicles
• Military aircraft
• Naval systems
• C4I base stations
• Power distribution modules
• Communication towers
• Satellite communications
• Mass transit
January 2014
Amphenol Ltd Thanet Way Whitstable Kent CT5 3JF Tel:+44 (0)1227 773200 info@amphenol.co.uk www.amphenol.co.uk
