3M
™
Cable Accessory
Strain Relief/Grounding Clamp
3504 Series
•
Jacketed cable strain relief/grounding
clamps
transfer stresses and strains to the cabinet,
preventing damage to the connector and other internal
devices. They can also be used to ground shielded
cable to the cabinet.
• RoHS* compliant
5/
17
Date Modified: December 17, 2006
TS-0268-10
Sheet 1 of 2
3M Part
Number
3504-2
3504-3
3504-4
Dimension A
3.50 [ 88.9 ]
4.25 [ 108.0 ]
5.50 [ 139.7 ]
Dimension B
2.50 [ 63.5 ]
3.25 [ 82.6 ]
4.50 [ 114.3 ]
Dimension C
3.10 [ 78.7 ]
3.87 [ 98.3 ]
5.12 [ 130.0 ]
D
3M
Interconnect Solutions
http://www.3M.com/interconnects/
IS
C
"RoHS compliant" means that the product or part does not contain any of the following substances in excess of the following maximum
concentration values in any homogeneous material, unless the substance is in an application that is exempt under RoHS: (a) 0.1%
(by weight) for lead, mercury, hexavalent chromium, polybrominated biphenyls or polybrominated diphenyl ethers; or (b) 0.01% (by
weight) for cadmium. Unless otherwise stated by 3M in writing, this information represents 3M's knowledge and belief based upon
information provided by third party suppliers to 3M.
O
N
3M is a trademark of 3M Company.
For technical, sales or ordering information call
800-225-5373
T
IN
U
E
Dimension D
.20 [ 5.1 ]
.19 [ 4.8 ]
.19 [ 4.8 ]
D
Dimension E
.50 [ 12.7 ]
.50 [ 12.7 ]
.50 [ 12.7 ]
3M
™
Cable Accessory
Strain Relief/Grounding Clamp
3504 Series
.38
[ 9.5 ]
4x 8-32 Tapped Holes
.20
[ 5.16 ]
4x Mounting Holes
.75
[ 19.05 ]
.50
[ 12.7 ]
.20
[ 5.2 ]
E
B
A
Top
5/
4x∅ .18 Holes
[ 4.57 ]
C
O
N
T
IN
U
E
C
D
D
Inch
[mm]
Tolerance Unless Noted
Inch
.0
±.1
.00
±.05
.000
±.010
[ ] Dimensions for
Reference only
Cable Width (Maximum)
2 = 2.92 [ 74.2 ]
3 = 3.69 [ 93.7 ]
4 = 4.94 [ 125.5 ]
TS-0268-10
Sheet 2 of 2
.38
[ 9.5 ]
Ordering Information
3504-X
Note: Packaged 100 per bag.
3M
Interconnect Solutions
http://www.3M.com/interconnects/
D
Notes:
1. Material: Aluminum.
2. Plating Per Mil-C-4451, Class 3 Clear.
3. Includes Four #8-32 Round Head Screw.
IS
3M is a trademark of 3M Company.
For technical, sales or ordering information call
800-225-5373
17
Bottom
