Liquid Tight Cordgrips
Heyco -Tite
EMC Brass Liquid Tight Cordgrips
Straight-Thru, Metric Hubs
EMC Nickel-Plated Brass with Contact Sleeve
The Ultimate in Liquid Tight Strain Relief Protection
CABLE DIA. RANGE
Minimum
in.
.098
.118
.118
.157
.177
.236
.236
.315
.315
.433
.512
.630
.709
.827
.098
.118
.118
.157
.177
.236
.236
.315
.315
.433
.512
.630
.709
.827
mm.
2,5
3,0
3,0
4,0
4,5
6,0
6,0
8,0
8,0
11,0
13,0
16,0
18,0
21,0
2,5
3,0
3,0
4,0
4,5
6,0
6,0
8,0
8,0
11,0
13,0
16,0
18,0
21,0
Maximum
in.
.138
.157
.157
.236
.236
.295
.312
.394
.433
.551
.630
.748
.827
.984
.138
.157
.157
.236
.236
.295
.312
.394
.433
.551
.630
.748
.827
.984
mm.
3,5
4,0
4,0
6,0
6,0
7,5
8,0
10,0
11,0
14,0
16,0
19,0
21,0
25,0
3,5
4,0
4,0
6,0
6,0
7,5
8,0
10,0
11,0
14,0
16,0
19,0
21,0
25,0
4613
4614
4615
4616
4618
4619
4622
4623
4625
4626
4628
4629
4631
4632
14613
14614
14615
14616
14618
14619
14622
14623
14625
14626
14628
14629
14631
14632
PART
NO.
THREAD
SIZE
or
A
Clearance
Hole Dia.
in. mm.
PART DIMENSIONS
B
C
D
Max. O.A.
Thread
Wrenching Nut
Length
Length
Flat Size
in.
mm. in.
mm. in.
mm.
®
Standard Thread
M8 x 1,25
M10 x 1,5
M12 x 1,5
M16 x 1,5
M16 x 1,5
M20 x 1,5
M20 x 1,5
M25 x 1,5
M25 x 1,5
M32 x 1,5
.315
8,0
.94
.98
1.06
1.18
1.26
1.22
1.30
1.41
1.53
1.65
24,0
25,0
27,0
30,0
32,0
31,0
33,0
36,0
39,0
42,0
.39
.39
.39
.39
.39
.43
.51
10,0
10,0
10,0
10,0
10,0
11,0
13,0
.43
.51
.59
.71
.94
1.18
1.42
11,0
13,0
15,0
18,0
24,0
30,0
36,0
.394 10,0
.472 12,0
.630
.630
.787
.787
.984
.984
16,0
16,0
20,0
20,0
25,0
25,0
1.260 32,0
Short Thread —
ALL NEW PRODUCTS!
M8 x 1,25
M10 x 1,5
M12 x 1,5
M16 x 1,5
M16 x 1,5
M20 x 1,5
M20 x 1,5
M25 x 1,5
M25 x 1,5
M32 x 1,5
.315
8,0
.75
.79
.87
.98
1.06
1.06
1.10
1.26
1.38
1.46
19,0
20,0
22,0
25,0
27,0
27,0
29,0
32,0
35,0
37,0
.20
.20
.20
.20
.24
.28
.31
5,0
5,0
5,0
5,0
6,0
7,0
8,0
.43
.51
.59
.71
.94
1.18
1.42
11,0
13,0
15,0
18,0
24,0
30,0
36,0
.394 10,0
.472 12,0
.630
.630
.787
.787
.984
.984
16,0
16,0
20,0
20,0
25,0
25,0
•
Ideal for applications where
Electromagnetic Interference (EMI)
protection or Electromagnetic
Compatibility (EMC) is needed.
•
IP 68 rated.
•
Nickel-plated finish over brass
provides excellent corrosion resistance
and durability.
•
Excellent 360° shield contact with
contact sleeve due to braided shield
which runs into the gland.
•
Combination of the sealing insert and
the contact socket guarantees a
constant contact quality with minimal
transfer impedance.
•
Inner cable protection.
•
Long thread for use in standard or
thick panels.
•
Multiple sizes for flexible cord
diameters ranging from .10˝ (2,5 mm)
to 1.00˝ (25,5 mm).
•
For use in clearance or threaded holes.
•
Cordgrips are made of nickel plated
brass and the gland is made of TPE.
•
EMC locknuts available. See page
3-40.
•
DFARS Compliant
1.260 32,0
Short Thread, High Temperature*
.236
6,0
.315 8,0
4609
M16 x 1,5
*Special sealing gland rated to 200°C (392°F).
.630 16,0
.98
25,0
.20
5,0
.71
18,0
B
C
A
D
Material
Certifications
Temperature Range
IP Rating
Nickel-Plated Brass W/TPE Sealing Gland
Recognized under the Component Program of Underwriters’ Laboratories
File E51579 to both Canadian and U.S. requirements
-40°F (-40°C) to 212°F (100°C)
IP 68, IP 69K
Quick
Specs
