“Stay Connected with Heyco”
Liquid Tight Cordgrips
NO O-RING
REQUIRED!
Heyco -Tite
Liquid Tight Cordgrips
Pigtail
™
, Metric Hubs
with Integral Sealing Ring
The Ultimate in Liquid Tight Strain Relief Protection
•
Flexible Pigtail extender prevents sharp
bends and extends cable life.
•
Integral Sealing Ring ensures a
superior seal at the clearance or
threaded mounting hole location,
every time.
•
Widest range of approved cable
diameters.
•
IP 68 rated.
•
Approved for
NEMA 4, 4X, 6 and 6P
applications.
•
Ratchet design of sealing nut
assembly provides superior anti-
vibration protection and ensures
a firm grip on the cable.
•
Acme threads on body prevent
skipping and speed installation.
•
All nylon construction with Buna N or
TPE sealing gland resists salt water,
weak acids, gasoline, alcohol, oil,
grease, and common solvents.
(This feature is not assessed by UL.)
•
Multiple sizes for flexible cord
diameters ranging from .065˝ (1,7 mm)
to .705˝ (17,9 mm).
•
We recommend using the fitting with
the smallest maximum diameter that
will fit your application.
•
Unassembled Nylon Locknuts
INCLUDED.
•
For Heyco Liquid Tight Threaded
Plugs, see page 3-49.
•
Consult Heyco for cordgrips molded
in other colors.
CABLE DIA. RANGE
Minimum
in.
.065
.115
.065
.105
.095
.170
.260
.250
®
Maximum
in.
.210
.250
.230
.315
.290
PART NO.
Including
Nylon Nut*
No Nut
Black
Gray Black
M4396
M4398
M4400
M4402
M4404
M4406
M3270
M4408
M4410
M4397
M4399
M4401
M4403
M4405
M4407
M3271
M4409
M4411
DESCRIPTION
mm.
1,7
2,9
1,7
2,7
2,4
4,3
6,6
6,4
mm.
5,3
6,4
5,8
8,0
7,4
PART DIMENSIONS
A
B
C
E
or Clearance Max. O.A. Thread Wrenching
Hole Dia. Length
Length
Nut Flats
in. mm. in. mm. in. mm. in. mm.
.473 12,0 2.44 62,0 .32
.630 16,0 2.77 70,4 .32
8,1
8,1
.63 16,0
.82 20,8
.98 24,9
M4422
Flex RLTCG M12
M4424
Flex LTCG M12
M4426
Flex RLTCG M16
M4428
Flex LTCG M16
M4430
Flex RLTCG M20
M4432
Flex LTCG M20
-
Flex LTCG LL M20
.787 20,0 3.89 98,8 .41 10,4
.450 11,4
.545 13,8
.490 12,4
.705 17,9
.787 20,0 4.34 110,2 .41 10,4 1.06 26,9
.985 25,0 5.04 128,0 .52 13,2 1.30 33,0
M4434
Flex RLTCG M25
M4436
Flex LTCG M25
.435 11,1
Standard colors black and gray.
*Nylon locknuts shipped unassembled
For No Nut Part Nos. in gray color please visit our Cordgrip product section at heyco.com
Collet design of body accommodates
various size cords, cables, tubing.
Compress gland to seal.
Acme threads prevent
skipping, speed installation.
Sealing nut with flexible extender
provides lazy bend protection for
cables, wires, and tubing.
Integral Sealing Ring
provides light seal at mounting panel without O-ring.
B
C
D**
A
E
SUGGESTED
CLEARANCE HOLE
FOR NONTHREADED
MOUNTING
SEALING NUT WITH
FLEX-PROTECTOR EXTENDER
INTEGRAL SEALING RING
**Consult Heyco for Wrenching Nut Thickness “D”
Material
Certifications
Quick
Specs
3-7
Nylon 6/6 w/Buna N or TPE Sealing Gland
Listed under Underwriters’ Laboratories File E51579
Recognized under Components Program of Underwriters’ Laboratories
File E51579
Certified by Canadian Standards Association File 93876C
Approved for NEMA 4, 4X, 6 and 6P Applications
VDE Marks License #40010390
Per CE Low Voltage Directive 73/23/EEC
94V-2
Static -40°F (-40°C) to 239°F (115°C)
Dynamic -4°F (-20°C) to 212°F (100°C)
IP 68 (70 PSI, 5 BAR)
Flammability Rating
Temperature Range
IP Rating
1-800-526-4182 • 732-286-1800 (NJ) • FAX: 732-244-8843 • www.heyco.com
