Sensor/Actuator cable - SAC-12P-MS/6,0-35T/FR SH SCO - 1423618
Please be informed that the data shown in this PDF Document is generated from our Online Catalog. Please find the complete data in the user's
documentation. Our General Terms of Use for Downloads are valid
(http://phoenixcontact.com/download)
Sensor/actuator cable, 12-pos., PUR/PVC, RAL 9005 (black), shielded, straight M12 SPEEDCON plug (A-
coded) to straight M12 SPEEDCON socket (A-coded), cable length: 5 m
Key Commercial Data
Packing unit
Minimum order quantity
GTIN
GTIN
Custom tariff number
Note
4055626351278
85444290
Made to Order (non-returnable)
1 STK
50 STK
Technical data
Dimensions
Length of cable
6m
General
Rated current at 40°C
Rated voltage
Number of positions
Insulation resistance
Coding
Standards/regulations
Status display
Overvoltage category
Degree of pollution
1.5 A
30 V
12
≥ 100 MΩ
A - standard
M12 connector IEC 61076-2-101
No
II
3
Material
Flammability rating according to UL 94
Contact material
Contact surface material
Contact carrier material
Material of grip body
Material, knurls
Sealing material
V0
CuZn
Ni/Au
PA 66
TPU, hardly inflammable, self-extinguishing
Zinc die-cast, nickel-plated
NBR
11/13/2016 Page 1 / 2
https://www.phoenixcontact.com/hq/products/1423618
Sensor/Actuator cable - SAC-12P-MS/6,0-35T/FR SH SCO - 1423618
Technical data
Standards and Regulations
Standard designation
Standards/regulations
Resistance to oil
Flame resistance
Other resistance
Flammability rating according to UL 94
M12 connector
IEC 61076-2-101
DIN VDE 0472 Part 803, test type B
DIN VDE 0472 part 804, test type B
Hydrolysis and microbe resistant as per VDE 0282 section 10
V0
Drawings
Schematic diagram
11 3
4
5
6
7
8
2
10
1
9
12
Schematic diagram
10
1
9
12
8
7
5
6
2
3 11
4
Pin assignment M12 male connector, 12-pos., male side view
Pin assignment M12, 12-pos., female side view
Dimensional drawing
Dimensional drawing
46,7
45
14,1
14,1
M12 SPEEDCON plug, straight, shielded
14,8
Socket M12-SPEEDCON, straight, shielded
Circuit diagram
1
3
6
4
5
8
7
10
9
2
11
12
1
3
6
4
5
8
7
10
9
2
11
12
Contact assignment of the M12 plug and the M23 socket
