HEYClip Cable Holders -
Snap Rivet Mount
•
Designed to mount easily on panel
with push rivet (see table) or a #6
screw.
•
Allows mounting to a wide range of
panel thicknesses.
•
See Quick Specs on page 7-55.
WIRE
CAPACITY
in.
x .17
x .36
x .73
x 1.04
mm.
x 4,3
x 9,1
x 18,5
x 26,4
x 3,6
x 8,6
x 18,3
x 25,4
12025
12026
12027
12028
12029
12030
12031
12032
CHSR R-11
CHSR R-16
CHSR R-25
CHSR R-33
CHSR L-11
CHSR L-16
CHSR L-25
CHSR L-33
PART NO. DESCRIPTION
Natural
OVERALL
HEIGHT
C
in.
mm.
.45
.64
1.00
1.31
.45
.64
1.00
1.31
11,4
16,3
18,5
26,4
11,4
16,3
25,4
33,3
FOOTPRINT
AxB
in.
mm.
MOUNTING
HOLE
DIAMETER
in. mm.
™
Top Entry - Regular Gate
.44
11,1
.49 x .61
12,4 x 15,5 .144
3,7
Top Entry - Latch Gate
x .14
x .34
11,1
.44
x .72
x 1.00
Standard color natural.
.49 x .61
NEW PRODUCTS!
12,4 x 15,5 .144
3,7
CHSR R
C
CHSR L
C
A
B
A
B
PART NO.
Black
9044
9046
9048
9050
9052
9054
9056
Rivet Table for CHSR
DESCRIPTION
PANEL THICKNESS
in.
mm.
PR 142-047 BLACK .01-.05
0,3-1,2
PR 142-083 BLACK .05-.08
1,2-2,1
PR 142-106 BLACK .07-.11
1,8-2,7
PR 142-118 BLACK .08-.12
2,1-3,0
PR 142-146 BLACK .11-.14
2,8-3,7
PR 142-177 BLACK .14-.18
3,6-4,6
PR 142-217 BLACK .18-.22
4,6-5,6
HEYClip Cable Holders -
Two Prong Mount
For panels up to .063" (1,6 mm) thick
•
Gather and direct single or bundles of
cable at low cost.
•
Two orientations:
1. Vertical for
Top Entry
and narrow
width.
2. Horizontal for
Side Entry
and low
height where clearance is a problem.
•
Two gate types:
1. Regular gate secures cables with
tension alone.
2. Latch gate locks cables in place.
Both types install with fingertip
pressure into a 3/16" (4,8 mm)
diameter mounting hole.
•
Part Description Key: CH X-Y-Z,
where R = Regular Gate, L = Latch
Gate, Y = Overall Height (mm) and P
indicates the Split Prong mounting
design.
•
See Quick Specs on page 7-55.
WIRE
CAPACITY
in.
x .19
x .38
x .74
x 1.05
mm.
x 4,8
x 9,7
11,1
x 18,8
x 26,7
4337
4338
4339
4340
CH R-13-P
CH R-18-P
CH R-27-P
CH R-35-P
PART DESCRIPTION
NO.
Natural
OVERALL
HEIGHT
C
in.
mm.
.51
.71
1.06
1.37
13,0
18,0
26,9
34,8
FOOTPRINT
AxB
in.
mm.
MOUNTING
HOLE
DIAMETER
in.
mm.
™
Top Entry - Regular Gate
.44
.22 x .61
5,6 x 15,5
.187
4,8
Top Entry - Latch Gate
x .14
x 3,6
4341
CH L-13-P
.51
13,0
x .33
x 8,4
4342
CH L-18-P
.71
18,0
11,1
.22 x .61
.44
x .69
x 17,5
4343
CH L-27-P
1.06
27,0
x 1.00
x 25,4
4344
CH L-35-P
1.37
34,8
Standard color natural. Flame retardant UL 94V-0 material available, consult Heyco.
5,6 x 15,5
.187
4,8
A
B
A
B
C
C
Regular Gate
Latch Gate
7-52
1-800-526-4182 • 732-286-1800 (NJ) • FAX: 732-244-8843 • www.heyco.com
