MATERIAL NUMBER
J
ENG. PART NO.
104000K12M020
104000K12M050
104000K12M100
104000K12M200
104000K12M300
1300062166
1300060895
1300060897
1300069044
1300069045
FINISHED LENGTH
2M +89mm -0 [6' 7" +3.5 IN -0]
5M +165mm -0 [16' 5" +6.5IN -0]
10M +318mm -0 [32' 10" +12.5IN -0]
20M +622mm -0 [65' 7" +24.5IN -0]
30M +622mm -0 [98' 5" +24.5IN -0]
CHART
J
I
I
FINISH LENGTH
H
2.25
[57.2]
4.0
[102]
2.24
[56.9]
C
H
4 (1)
[25.4]
3 (2)
G
3
G
.38
[9.7]
F
6
1
5
4
2
2 (4)
1 (3)
F
FEMALE FACE VIEW
C
E
D
NOTES:
1. MATERIAL: AS NOTED
2. FINISH: AS NOTED
3. ELECTRICAL:
VOLTAGE: 320V PER IEC60664
600V PER UL2238
CURRENT: 8A
5. PROTECTION: IP67 (WHEN MATED)
6. COUPLING THREAD: 7/8-16UN
7. ALL DIMS ARE FOR REFERENCE
UNLESS NOTED OTHERWISE
104000K12M200
E
cable type
16AWG-4
FLEX TPE
C
cable length
005 = 0.5 Meters
010 = 1 Meter
100 = 10Meters
D
C
C
C
B
DESCRIPTION
GENERAL TOLERANCES
(UNLESS SPECIFIED)
DIMENSION STYLE
SCALE
DESIGN UNITS
IN / MM
DRAWN BY
DATE
CHECKED BY
DATE
NTS
TITLE
INCH
THIRD ANGLE
PROJECTION
B
=
0
C
mm
4 PLACES
3 PLACES
2 PLACES
1 PLACE
---
---
---
---
---
INCH
---
---
---
---
=
0
APPROVED BY
DATE
molex
MINI CHANGE
4 POLE FEMALE STR
16 AWG AWG TPE
MOLEX INCORPORATED
SHEET NO.
A
REV
C
13
12
11
10
9
8
DRAFT WHERE
APPLICABLE
MUST REMAIN
WITHIN DIMENSIONS
7
6
5
MATERIAL NO.
DOCUMENT NO.
SEE CHART
SIZE
A
SD-130006-062
3
2
1
C
THIS DRAWING CONTAINS INFORMATION THAT IS PROPRIETARY TO MOLEX
INCORPORATED AND SHOULD NOT BE USED WITHOUT WRITTEN PERMISSION
