“Stay Connected”
with
®
Liquid Tight Cordgrips
Heyco Original Series-35 Liquid Tight Cordgrips
Pigtail, PG* Hubs
CABLE DIA. RANGE
Minimum
in.
.064
.114
.069
.181
.069
.230
.170
.230
mm.
Maximum
in.
mm.
5,3
6,4
4,7
7,9
6,6
10,0
11,4
13,9
12,3
18,0
3464
3237
3466
3240
3468
3243
3246
3249
3478
3245
3465
3238
3467
3241
3469
3244
3247
3250
3479
3248
4780
4778
4784
4782
4788
4786
4790
4792
4796
4794
FLEX RLTF 7
FLEX LTF 7
FLEX RLTF 9
FLEX LTF 9
FLEX RLTF 11
FLEX LTF 11
FLEX LTF 13.5
FLEX LTF 16
FLEX RLTF 21
FLEX LTF 21
PART NO.
Including
Nylon Nut**
No Nut
Black
Gray Black
DESCRIPTION
PART DIMENSIONS
A
B
C
E
or Clearance Max. O.A. Thread
Wrenching
Hole Dia.
Length
Length
Nut Flats
in. mm. in. mm. in. mm. in. mm.
.492 12,5 2.44 62,0 .33
.599 15,2 2.77 70,4 .34
.733 18,6 3.44 87,4 .39
8,4
8,6
9,9
.59
.75
.86
15,0
19,1
21,8
24,1
26,7
33,0
®
1,6 .210
2,9 .250
1,8 .187
4,6 .312
1,8 .260
5,8 .395
4,3 .450
5,8 .546
.804 20,4 3.88 98,6 .41 10,4 .95
.886 22,5 4.36 110,7 .45 11,4 1.05
1.115 28,3 5.03 127,8 .52 13,2 1.30
.250 6,4 .485
.450 11,4 .709
Standard colors black and gray.
*Steel conduit threads per DIN 40430, see page 3-57.
**Nylon locknuts shipped unassembled.
For No Nut Part Nos. in gray color please visit our Cordgrip product section at heyco.com.
Collet design of body
accommodates various size
cords, cables, tubing.
Compress TPE gland to seal.
Acme threads
prevent skipping,
speed installation. Locking nut
with generous
wrenching flats.
Sealing nut with
flexible extender
provides lazy bend
protection for cables,
wires, and tubing.
Special contour
provides light seal
at mounting panel
without O-ring.
B
C
D***
A
•
Flexible Pigtail
™
extender prevents
sharp bends and extends cable life.
•
IP 68 rated.
•
Widest range of approved
cable diameters.
•
For use in clearance or threaded holes.
•
Acme threads on body prevent
skipping and speed installation.
•
PG hub threads are steel conduit
threads per DIN 40430, see page 3-49.
•
All nylon construction with TPE sealing
gland resists salt water, weak acids,
gasoline, alcohol, oil, grease, and
common solvents. (This feature is
not assessed by UL.)
•
Multiple sizes for flexible cord
diameters ranging from .064˝
(1,6 mm) to .709˝ (18,0 mm).
•
We recommend using the fitting with
the smallest maximum diameter that
will fit your application.
•
Unassembled Nylon Locknuts
INCLUDED.
•
For Heyco Liquid Tight Threaded Plugs,
see page 3-51.
•
Consult Heyco for cordgrips
molded in other colors.
E
SEALING NUT WITH FLEX-PROTECTOR EXTENDER
SUGGESTED CLEARANCE HOLE
FOR NONTHREADED MOUNTING
***Consult Heyco for Wrenching Nut Thickness “D”
Material
Certifications
Flammability Rating
Temperature Range
IP Rating
Nylon 6/6 w/TPE Sealing Gland
Listed under Underwriters’ Laboratories File E51579
Recognized under the Component Program of Underwriters’
Laboratories File E51579
Certified by Canadian Standards Association File 93876C
94V-2
Static -40°F (-40°C) to 239°F (115°C)
Dynamic -4°F (-20°C) to 212°F (100°C)
IP 68 (70 PSI, 5 BAR)
Quick
Specs
3-22
