Liquid Tight Cordgrips
HEYbrid Brass/Nylon Liquid Tight
Cordgrips
™
Straight-Thru, PG Hubs
The Ultimate in Liquid Tight Strain Relief Protection
•
Provide the durability of a nickel-plated
brass enclosure with
drastically lower
installed cost
and more secure wire
gripping with nylon finger design.
•
HEYBrid Cordgrips make it possible to
insert different diameters of cable in the
same cable gland easily, flexibly and
with a good seal.
•
Movable articulated fingers provide
large clamping and sealing areas for
secure and flexible everyday use.
•
When tightening the compression nut
of the cordgrip, the segmented finger
design compresses around the gland
and wire to provide a torsion proof seal.
•
Nickel-plated brass construction for
superior protection of flexible cables.
•
Nickel-plated finish over brass
provides excellent corrosion
resistance and durability.
•
IP 68 rated.
•
For use in clearance or threaded holes.
•
Multiple sizes for flexible cord
diameters ranging from .04˝ (1,0 mm)
to 1.10˝ (28,0 mm).
•
We recommend using the smallest
cordgrip that accommodates your
cable size.
•
Sealing gland is molded in
Thermoplastic Polymer Elastomer
(TPE) material.
•
Locknuts not included.
For metal
locknut specifications or to order
locknuts separately, see page 3-42.
•
DFARS Compliant
CABLE DIA. RANGE
Minimum
in.
.04
.12
.08
.18
.14
.28
.14
.28
.14
.28
.20
.39
.28
.51
.59
.75
mm.
1,0
3,0
2,0
4,5
3,5
7,0
3,5
7,0
3,5
7,0
5,0
10,0
7,0
13,0
15,0
19,0
Maximum
in.
.20
.28
.24
.39
.31
.51
.31
.51
.31
.51
.43
.67
.59
.83
.91
1.10
mm.
5,0
7,0
6,0
10,0
8,0
13,0
8,0
13,0
8,0
13,0
11,0
17,0
15,0
21,0
23,0
28,0
4450
4451
4452
4453
4454
4455
4456
4457
4458
4459
4460
4461
4462
4463
4464
4465
PG 7
PG 9
PG 11
PG 13.5
PG 16
PG 16
PG 21
PG 29
PART
NO.
THREAD
SIZE
A
Clearance
Hole Dia.
in.
mm.
.50
.61
.75
.83
.91
.91
1.14
1.48
12,7
15,5
19,0
21,1
23,1
23,1
29,0
37,6
PART DIMENSIONS
B
C
D
Max. O.A.
Thread
Wrenching Nut
Length
Length
Flat Size
in.
mm. in.
mm.
in.
mm.
.87
1.02
1.22
1.24
1.24
1.48
1.57
1.89
22,0
26,0
31,0
31,5
31,5
37,5
40,0
48,0
.20
.24
.24
.26
.26
.26
.28
.31
5,0
6,0
6,0
6,5
6,5
6,5
7,0
8,0
.59
.71
.87
.87
.94
1.10
1.42
1.81
15,0
18,0
22,0
22,0
24,0
28,0
36,0
46,0
For certifications consult Heyco.
COMPRESSION
NUT
SEALING
RING
FINGER
INSERT
BODY
INSERT
O-RING
B
A
D
C
CLEARANCE HOLE
Quick
Specs
3-35
Material
Temperature Range
IP Rating
Nickel-plated Brass w/polyamide PA 6 finger insert,
TPE Sealing Gland and Buna-N O-ring
-40°F (-40°C) to 212°F (100°C)
IP 68, IP 69K
