NEW Series DR
Single Output to 30A 510 Vac
DIN-Rail Solid-State Relay
Part Number
DR24D25
DR24A25
DR24A25-22
DR48D25-21
DR48D25
DR48R25
DR48A25
DR48A25-22
DR48D30
Description
25A 275 Vac Output
25A 275 Vac Output
25A 275 Vac Output
25A 480 Vac Output
25A 510 Vac Output
25A 510 Vac Output
25A 510 Vac Output
25A 510 Vac Output
30A 510 Vac Output
FEATURES/BENEFITS
• Mounting and dismounting on DIN rail without
any tool or directly mountable on panel
• Zero-cross and random models; thyristors
output
• Large control range
• Green control LED
• Very high immunity
• Low leakage current
• Internal transient suppression
DESCRIPTION
The Series DR single-phase DIN-rail relays are
designed for all types of loads. The relays utilize
optical isolation to protect the control from load
transients. DR relays have an integral heat sink, and
can be mounted and dismounted onto a DIN rail
without any tools. The relays may also be panel
mounted. All relays offer a green control LED and
transient suppression.
APPLICATIONS
• Heating control
• Motor control
• Industrial and process control
APPROVALS
Series DR relays are pending UL recognition.
Part Number Explanation
DR
24
A
25
-22
NOTES
1) Line Voltage (nominal): 24 = 240 Vac; 48 = 480Vac
2) Switch Type: D = Zero-cross turn-on; A = Zero-cross, AC control;
R = Random turn-on
3) Features: 21 = self turn-on suppression; 22 = 24 Vac control
MECHANICAL SPECIFICATION
TYPICAL APPLICATION
400 Vac 50Hz
230 Vac 50Hz
Figure 1 — DR relays; dimensions in inches (mm)
L1
Protection
Protection
L1
SSR
SSR
T1
T1
A2 A1
A2 A1
-
+
Control
– +
Control
Load
CHARGE
Load
Figure 2 — DR relay DC control (left) and DR relay AC
control (right)
© 2003 TELEDYNE RELAYS
(800) 284-7007 • www.teledynerelays.com
DR 1
DR\032003\Q1
Series DR
CONTROL CHARACTERISTIC
12
INPUT (CONTROL) SPECIFICATION
Min
Control Range
DR24D25
DR48R25
DR48D25
3
3.5
3.5
3.5
3
17
150
32
32
32
32
32
60
240
Vdc
Vdc
Vdc
Vdc
Vdc
Vac/dc
Vac/dc
Max
Units
Control Current (mA)
10
8
6
4
2
0
0
2
4
6
8 10 12 14 16 18 20 22 24 26 28 30 32
DR48D30
DR48D25-21
DRXXA25-22
DRXXA25
Control Current Range
Control Voltage (V)
Figure 3a — DRXXD and DR48R relays
8
DRXXDXX
DR48R25
DRXXA25
DRXXA25-22
3
3
10
10
7
20
mAdc
mAdc
mA
mA
Control Current (mA)
6
4
2
0
0
50
100
150
200
250
Must Turn-Off Voltage
DR24D25
DR24A25
DR24A25-22
DR48D25-21
DR48R25
DR48D25
DR48A25
DR48A25-22
DR48D30
Reverse Voltage (DC Control)
Clamping Voltage (DC Control)
Input LED
1
1
4
1
2
2
15
4
2
32
42
Green
V
V
V
V
V
V
V
V
V
V
V
Control Voltage (V)
Figure 3b — DRXXA25 relays
20
Control Current (mA)
15
10
5
0
0
10
20
30
40
50
60
Control Voltage (V)
Figure 3c — DRXXA25-22 relays
THERMAL CHARACTERISTICS
25
45
40
45
40
Load Current (Arms)
35
30
25
20
15
10
5
Load Current (Arms)
0
5 10 15 20 25 30 35 40 45 50 55 60 65 70 75 80 85
20
Load Current (Arms)
35
30
25
20
15
10
5
0
0
5 10 15 20 25 30 35 40 45 50 55 60 65 70 75 80 85
15
10
5
0
0
5 10 15 20 25 30 35 40 45 50 55 60 65 70 75 80 85
0
Ambient Temperature (°C)
Ambient Temperature (°C)
Ambient Temperature (°C)
Figure 4a — DR24X25-XX relays
DR 2
Figure 4b — DR48X25-XX relays
Figure 4c — DR48D30 relay
© 2003 TELEDYNE RELAYS
DR\032003\Q1
SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT NOTICE
Series DR
OUTPUT (LOAD) SPECIFICATION
Min
Operating Range
DR24
DR48D25-21
DR48
Peak Voltage
DR24
DR48
Clamping Voltage
DR24 (@1mA)
DR48 (@1mA)
Load Current Range (See Figure 4)
DRXXX25-XX
DR48D30
Zero-Cross Window (Typical)
DR24
DR48D25-21
DR48R25
DR48D25
DR48A25
DR48A25-22
DR48D30
10
10
Random
20
20
20
20
V
V
V
V
ENVIRONMENTAL SPECIFICATION
Min
A
A
A
Storage Temperature
Operating Temperature
Input-Output Isolation
Output-Case Isolation
0.85
0.9
0.75
V
V
V
DR24
DR48
Insulation Resistance
Rated Impulse Voltage
W
W
W
2500
4000
100
4000
Vrms
Vrms
MΩ
V
–30
–30
4000
Max
100
80
Unit
°C
°C
Vrms
V
V
I
2
t for match fusing (<8.3ms)
DR24
DR48X25
DR48D30
312
1500
5000
A
2
S
A
2
S
A
2
S
.005
.005
25
30
Arms
Arms
Operating Frequency Range 0.1
Off-State dv/dt
440
500
Hz
V/µs
430
820
V
V
V
Turn-Off Time (60Hz)
DRXXD
DRXXA
DR48R25
8.3
24.9
8.3
ms
ms
ms
DR48D25-21 (ON voltage, typical) 950
600
1200
Vpeak
Vpeak
Turn-On Time (60Hz)
DRXXD
DRXXA
DR48R25
8.3
24.9
0.1
ms
ms
ms
12
12
24
275
480
510
Vrms
Vrms
Vrms
Max
Unit
OUTPUT (LOAD) SPECIFICATION (Continued)
Min
Thermal Resistance (Junction to Air)
DR24
DR48X25
DR48D30
Off-State Leakage Current (60Hz)
Max
3.8
3.3
3.2
1
Unit
°C/W
°C/W
°C/W
mA
Non-Repetitive Overload Current (See Figure 5)
DR24
DR48X25
DR48D30
On-State Voltage Drop (Typical)
DR24
DR48X25
DR48D30
Output Power Dissipation (Typical)
DR24
DR48X25
DR48D30
0.9xI+0.015xI
2
0.81xI+0.08xI
2
0.7xI+0.08xI
2
250
550
1000
© 2003 TELEDYNE RELAYS
(800) 284-7007 • www.teledynerelays.com
DR 3
DR\032003\Q1
Series DR
SURGE CURRENTS
250
200
Non-Repetitive
Apeak
150
100
50
Repetitive with initial Tj = 70˚C
0
0.01
0.1
1
10
t (s)
Figure 5a — DR24 relays
600
Non-Repetitive
Apeak
400
200
Repetitive with initial Tj = 70˚C
0
0.01
0.1
1
10
t (s)
Figure 5b — DR48X25 relays
1500
Non-Repetitive
Apeak
1000
500
Repetitive with initial Tj = 70˚C
0
0.01
0.1
1
10
t (s)
Figure 5c — DR48D30 relay
DIN-RAIL MOUNTING
NOTES:
1. Connections: For output terminals, the wire cross sections must be
adapted to the load current and to the overcurrent protection device
characteristics. The relay rated voltage must be adapted to the mains
rated voltage. These relays use screw clamp connections.
2. Mounting: Only in vertical position.
Protect heat-sensitive materials as well
as people from contact with the heat
sink. For non vertical mounting, the
load current must be derated by 50% .
The SSR requires air convection. Lack
of air convection produces an abnormal
heating. Keep a distance between the
upper SSR and the lower SSR (see
vertical
3.15 inches
figure on the right). In case of zero
position
(80mm)
space between two SSRs, reduce the
load current. It’s suggested to maintain
the heat sink temperature under 90°C.
Forced cooling significantly improves
the thermal performances.
3. Typical application loads: The DR relay
may handle motor and resistive loads.
For different loads, check the inrush
current at turn-ON and possible overvoltages at turn-OFF or contact
the factory.
• Incandescent lamps — Inrush current is generally 10 times the
current nominal for 10ms.
• Electric discharge lamp — These loads often have overcurrent at
turn-ON and overvoltage at turn-OFF. Use 480Vac SSR on 240Vac
mains.
• Transformer loads — Very high inrush current, up to 100 times the
nominal current.
• Capacitive loads — Very high current at turn-On and overvoltage at
turn-Off. Use only zero-cross models.
4. Protection: To protect the SSR against a short-circuit
1~
of the load, use a fuse with a I
2
t value = 1/2 I
2
t value.
Fuse
5. EMC:
Immunity: lmmunity levels of the DR comply with
EN61000-4-4 &5.
L1
Emission: The system integrator must ensure that
systems containing SSRs comply with the
requirements of any rules and regulations applicable
T1
at the system level. The very low zero-cross voltage
+
(<20V) improves the conducted emission level in
Load
–
comparison with most SSRs with zero-cross voltage
higher than 50V.
N
6. All electrical parameters specified at 25°C unless
otherwise noted.
A1
A2
control
Mounting
Recommended to connect
DIN rail to ground.
Dismounting
Figure 6 — DR relay
PANEL MOUNTING
M5
M4
CONNECTIONS
Drill for vertical can be adjusted
L
wires
(mm
2
)
L
torques
screwdriver
3.47±.08
(88±2)
control
1 x (0.75-->2.5)
L = 6mm
0.4N.m
(0.6N.m max)
3.5 x 0.5mm
Power
1 x (1.5-->16) 1 x (1.5-->10)
L = 10mm
.5 (12.7)
1.2N.m
(1.8N.m max)
Pozidriv2/
0.8 x 5.5 (1 x 6)
Figure 7 — DR relay
DR 4
Figure 8 — DR relay
© 2003 TELEDYNE RELAYS
DR\032003\Q1
SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT NOTICE
