Material:
• Body: Polyamide PA 6
25 % Glass-fiber Reinforced
• Seal: Tefabloc
ECA clamping ring: Polycarbonate
Characteristics:
• PG/metric thread
• ECA clamping ring
• Extended thread available
Technical properties:
• Strain relief through clamping ring
• Gas tight and watertight
• Completely twist protected
• Combinable with various sealing inserts
Applications:
• Machines and devices
• Measuring and control
engineering
• Plant installations
ECA Clamping Ring Polyamide
Outer thread
PG
PG
PG
PG
PG
PG
PG
PG
Clamping range
mm
3-6
5-8
6-10
8-12
10-14
11.5-18
15-24
5-8
8-12
10-14
11.5-18
15-24
Cat. No.
Light Grey
5313610
5313611
5313612
5313613
5313614
5313615
5313616
5313640
5313641
5313644
5313642
5313643
Cat. No.
Black
5313620
5313621
5313622
5313623
5313624
5313625
5313626
5313650
5313651
5313654
5313652
5313653
Std.
Pk.
50
50
50
50
50
20
20
50
50
50
20
20
Temperature Range
-30 to 120°C
(-22 to 248°F)
7
9
11
13.5
16
21
29
1.5
1.5/13
1.5/16
1.5
1.5
Seal Tefabloc
Dome Nut
Polyamide
Clamping
Polycarbonate
Body
Polyamide
PG/M
Metric
M 16 x
M 20 x
M 20 x
M 25 x
M 32 x
ØC
E
L
H
Thread
H
Size
mm
PG7
15
PG9
19
PG11
22
PG13.5
24
PG16
27
PG21
33
PG29
42
M 16x1.5
19
M 20x1.5/13 24
M 20x1.5/16 27
M 25x1.5
33
M 32x1.5
42
Dimensions
E
L
ØC
mm
mm
mm
8
31
6.5
8
32
8.5
8
35
11.5
9
36
12.5
10
40
14.5
11
44
18.5
12
55
25.0
8
32
8.5
9
36
12.5
9
39
14.5
11
44
18.5
12
55
25.0
ØP
ØP
mm
7.0
9.0
11.0
13.5
15.0
19.0
25.0
9.0
13.5
15.0
19.0
25.0
ØPG/M
mm
12.5
15.2
18.6
20.4
22.5
28.3
37.0
16.0
20.0
20.0
25.0
32.0
Locknuts and seal rings sold separately, see pages 24 and 35.
