Heyco -Tite
Combiner Box
Liquid Tight Cordgrips
Multi-Hole, Snap-In Hubs -
IP 64 Rated
®
The Ultimate in Liquid Tight Strain Relief Protection
•
House multiple wires at one entry
point providing a liquid tight seal
around each wire and at the panel.
•
IP 64 Rated.
•
Easy installation–Unique fingers
securely lock into a range of panel
sizes without use of locknut.
No tools required.
•
Secure “click in place” fit reduces
tightening errors by installers.
•
Limited intrusion into enclosure
where access is tight.
•
Ideal when individual conductors for
power or control are used rather than
jacketed cable.
•
Smooth, rounded interior edges for
ease of installation.
•
Ratchet design of sealing nut
assembly provides superior
anti-vibration and ensures a firm grip
on the cable.
•
Rotation prevented when used in
“Double D” mounting holes.
•
For use in clearance holes.
•
Made of nylon construction with TPE
sealing glands that resist salt water,
weak acids, gasoline, alcohol, oil,
grease, and common solvents. (This
feature is not assessed by UL.)
•
Foam sealing washer INCLUDED with
Cordgrip.
•
For complete range of Heyco Cordgrips,
see Section 3.
For use in Clearance Holes in Panels from
.032˝ (0,8 mm) to .093˝ (2,4 mm) Thick
GLAND
CONFIGURATION
Conductors
Size
Type
AWG/
mm.
*
No.
4,2
USE-2
12/2
12/3
4,6
USE-2
12/4
10/2
5,2
USE-2
10/3
10/4
7,0
7,4
8,0
PV 1000
PV 1000
PV 1000
12/3
12/2
10/2
PART NO.
Black
DESCRIPTION
A
Mounting
Hole Dia.
in.
mm.
SCG 875
SCG 1093
SCG 1125
SCG 1093
SCG 1125
SCG 875
SCG 1093
SCG 1125
SCG 1093
SCG 1125
SCG 1093
SCG 1125
SCG 1093
SCG 1125
SCG 1093
SCG 1125
.875
1.093
1.125
1.093
1.125
.875
1.093
1.125
1.093
1.125
1.093
1.125
1.093
1.125
1.093
1.125
22,2
27,8
28,6
27,8
28,6
22,2
27,8
28,6
27,8
28,6
27,8
28,6
27,8
28,6
27,8
28,6
PART DIMENSIONS
B
C
To Prevent
Max. Overall
Rotation
Length
in.
mm.
in.
mm.
.77
.97
1.00
.97
1.00
.77
.97
1.00
.97
1.00
.97
1.00
.97
1.00
.97
1.00
19,6
24,6
25,4
24,6
25,4
19,6
24,6
25,4
24,6
25,4
24,6
25,4
24,6
25,4
24,6
25,4
1.75
1.75
1.75
44,5
44,5
44,5
1.46
37,1
1.46
37,1
M4818GAB
M4830GBD
M4836GBD
M4830GBE
M4836GBE
M4818GAE
M4830GAF
M4836GAF
M4830GAG
M4836GAG
M4830GAM
M4836GAM
M4830GAN
M4836GAN
M4830GAQ
M4836GAQ
1.75
44,5
1.75
44,5
*AWG 10 and 12 for both USE-2 and PV 1000.
Foam Washer INCLUDED.
C
A
FITS PANEL
THICKNESS
.032˝-.093˝
B
Quick
Specs
1-7
Material
Flammability Rating
Temperature Rating
IP Rating
Nylon 6/6 with TPE sealing gland
94V-2
-22°F (-30°C) to 212°F (100°C)
IP 64
