34062-0009 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > The connector> 34062-0009

34062-0009: DescriptionAutomotive Connectors 1.5mm FemFuel Injtr 2Way W/OCPA OptD Gry; CategoryThe connector; File Size37KB，1 Pages; ManufacturerMolex; Websitehttps://www.molex.com/molex/home; Environmental Compliance

Download Datasheet Parametric View All

34062-0009 Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	34062-0009	-	-	View	Buy Now

34062-0009 Overview

Automotive Connectors 1.5mm FemFuel Injtr 2Way W/OCPA OptD Gry

34062-0009 Parametric

Parameter Name	Attribute value
Product Attribute	Attribute Value
Manufacturer	Molex
Product Category	Automotive Connectors
RoHS	Details
Product	Connectors
Number of Positions	2 Position
Gender	Female
Mounting Style	Wire
Termination Style	Crimp
Packaging	Bulk
Color	Gray
Current Rating	15 A
Housing Material	Polyester, Polyphenylene Ether Alloy
Number of Rows	2 Row
Type	Receptacle
Pitch	5 mm
Maximum Operating Temperature	+ 125 C
Minimum Operating Temperature	- 40 C
Factory Pack Quantity	1000
Unit Weight	0.141378 oz

Preview

Download Datasheet

View All

This document was generated on 11/02/2015

PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION

Part Number:

Status:

Overview:

Description:

0340620009

Active

MX150™ Sealed and Unsealed Connector System

MX150™ Cable Sealed Female Connector, Single Row, 2 Circuits, Polarization D,

without Connector Position Assurance, Gray

Documents:

Drawing (PDF)

Application Specification AS-34062-000 (PDF)

General

Product Family

Series

Application

Comments

More Detailed Tech Information

Overview

Product Name

UPC

Physical

Circuits (maximum)

Circuits Detail

Color - Resin

Gender

Glow-Wire Compliant

Keying to Mating Part

Lock to Mating Part

Material - Resin

Net Weight

Number of Rows

Packaging Type

Panel Mount

Pitch - Mating Interface

Pitch - Termination Interface

Polarized to Mating Part

Stackable

Temperature Range - Operating

Electrical

Current - Maximum per Contact

Solder Process Data

Lead-freeProcess Capability

Material Info

Reference - Drawing Numbers

Application Specification

Sales Drawing

RoHS Certificate of Compliance (PDF)

Series image - Reference only

Crimp Housings

34062

Power

No Connector Position Assurance (CPA)

http://uscar.org/guest/teams/10/Electrical-Wiring-

Component-Applications -Partnership

MX150™ Sealed and Unsealed Connector System

MX150™

822348110032

Gray

Female

Yes

Nylon

4.008/g

Bag

5.00mm

Yes

-40°C to +125°C

15.0A

N/A

EU ELV

Compliant

EU RoHS

China RoHS

Compliant

REACH SVHC

Contains SVHC(17.

December 2014): No

Halogen-Free

Status

Not Relevant

Need more information on product

environmental compliance?

Email productcompliance@molex.com

Please visit the Contact Us section for any

non-product compliance questions.

China ROHS

ELV

Not Relevant

Compliant

Search Parts in this Series

34062 Series

Mates With

Direct Connect only

Use With

34083 Tin (Sn) Cable Seal Female Terminal,

34081 Silver (Ag) and Gold (Au) Cable Seal

Female Terminal

AS-34062-000

SD-34062-001

This document was generated on 11/02/2015

PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION
