76650-0083

Description
Headers & Wire Housings MiniFit Jr Conn Kit V Hdr Recept 4Ckt
CategoryThe connector
File Size30KB,2 Pages
ManufacturerMolex
Websitehttps://www.molex.com/molex/home
Environmental Compliance
Download Datasheet Parametric View All

76650-0083 Online Shopping

Suppliers Part Number Price MOQ In stock
76650-0083 - - View Buy Now

76650-0083 Overview

Headers & Wire Housings MiniFit Jr Conn Kit V Hdr Recept 4Ckt

76650-0083 Parametric

Parameter NameAttribute value
Product AttributeAttribute Value
ManufacturerMolex
Product CategoryHeaders & Wire Housings
RoHSDetails
ProductConnector Kits
Number of Positions-
Pitch4.2 mm
Mounting Style-
Termination StyleThrough Hole
Mounting AngleVertical
Contact GenderPin (Male), Socket (Female)
Contact Plating-
PackagingBulk
Current Rating6 A
Voltage Rating600 V
Contact Material-
Wire Gauge24-18
1801 Morgan Street
Rockford, Illinois 61102
800-435-2931
www.molexkits.com
Datasheet for 76650-0083
General Information
Part Number:
Manufacturer:
Title:
Description:
Product Family:
Certificates:
76650-0083
Molex / Waldom
Mini-Fit Jr. Connector Kit
Vertical Header and Receptacle, 4 Circuit
Mini-Fit Jr.™
(Molex parts within this kit) - EU and China RoHS, UL, CSA and TUV
Country of Origin:
Kit assembled in U.S.A.
Specifications
Design
Configuration:
Pitch:
Connector Type:
Mounting
Orientation:
Circuit Sizes:
Current Rating:
Voltage:
Wire size:
Product Highlights
The Mini-Fit Jr. Series is designed for high current/high density applications. The
Mini-Fit Jr. is appropriate for both power and signal applications. The Mini-Fit
product family accepts the same terminals and application tooling, further reducing
your design and qualification effort.
Features and Benefits
• Fully isolated terminals
• Positive housing locks
• Four point of contact for reliability
• Low engagement force terminals
Applications
• Security and Alarms
• Vending and Gaming Machines
• White Goods
• Production Equipment
• Broadcast Equipment
• Telecom Infrastructure
Wire-to-Board
4.2mm (.165")
Receptacles and Vertical Headers
Vertical
4
6 Amps
600 Volts
24-18 AWG
For additional Molex / Waldom Design and Solution kits please go to www.molexkits.com
Page 1 of 2
