620-053
Backshell Accessory Thread Strain Reliefs
62
Dash
No.
03
04
06
08
10
12
16
20
24
28
32
D
Max
1.031 (26.2)
1.031 (26.2)
1.031 (26.2)
1.031 (26.2)
1.094 (27.8)
1.219 (31.0)
1.219 (31.0)
1.344 (34.1)
1.547 (39.3)
1.547 (39.3)
1.734 (44.0)
E
Max
1.375 (34.9)
1.375 (34.9)
1.375 (34.9)
1.375 (34.9)
1.437 (36.5)
1.437 (36.5)
1.562 (39.7)
1.812 (46.0)
2.062 (52.4)
2.062 (52.4)
2.188 (55.6)
P
Dash
R
Max
No.
Max
.844 (21.4)
n/a
03*
.844 (21.4)
04*
n/a
.906 (23.0)
06*
n/a
.969 (24.6) 1.312 (33.3)
08
.969 (24.6) 1.312 (33.3)
10
.969 (24.6) 1.344 (34.1)
12
1.062 (27.0) 1.688 (42.9)
16
1.125 (28.6) 1.906 (48.4)
20
1.188 (30.2) 1.906 (48.4)
24
1.719 (43.7) 2.125 (54.0)
28
n/a
32* 1.781 (45.2)
1.781 (45.2)
40*
n/a
* Not available in Style M clamp.
© 20053 Glenair, Inc.
TABLE III: CABLE ENTRY
F
H
G
Max
Ref
Max
.812 (20.6) .135
(3.4) .781 (19.8)
.937 (23.8) .203
(5.2) .781 (19.8)
1.062 (27.0) .285
(7.2) .781 (19.8)
1.188 (30.2) .350
(8.9) .781 (19.8)
1.312 (33.3) .390
(9.9) .844 (21.4)
1.562 (39.7) .460 (11.7) .875 (22.2)
1.750 (44.5) .510 (13.0) .875 (22.2)
2.250 (57.2) .695 (17.7) .969 (24.6)
2.375 (60.3) .715 (18.2) 1.188 (30.2)
2.625 (66.7) .915 (23.2) 1.188 (30.2)
2.812 (71.4) 1.070 (27.2) 1.375 (34.9)
J
K - Cable Range
Max
Min *
Max
.812 (20.6)
.156 (4.0) .219 (5.6)
.937 (23.8)
.188 (4.8) .312 (7.9)
1.062 (27.0)
.281 (7.1) .438 (11.1)
1.188 (30.2)
.312 (7.9) .531 (13.5)
1.312 (33.3)
.375 (9.5) .625 (15.9)
1.562 (39.7) .500 (12.7) .750 (19.1)
1.750 (44.5) .625 (15.9) .938 (23.8)
2.250 (57.2) .938 (23.8) 1.250 (31.8)
2.375 (60.3) 1.000 (25.4) 1.375 (34.9)
2.625 (66.7) 1.250 (31.8) 1.625 (41.3)
2.812 (71.4) 1.500 (38.1) 1.875 (47.6)
* Not Applicable Styles B and E
TABLE IV: CABLE ENTRY
Dash
L
M
N - Cable Range
Max
No.
Max
Min
Max
.957 (24.3)
.125 (3.2) .312 (7.9)
04
1.312 (33.3)
06
1.312 (33.3) 1.145 (29.1)
.250 (6.4) .437 (11.1)
08
1.312 (33.3) 1.332 (33.8)
.312 (7.9) .562 (14.3)
.350 (8.9) .625 (15.9)
10
1.312 (33.3) 1.332 (33.8)
1.344 (34.1) 1.551 (39.4)
.500 (12.7) .750 (19.1)
12
16
1.438 (36.5) 1.770 (45.0)
.625 (15.9) .937 (23.8)
20
1.625 (41.3) 2.113 (53.7)
.875 (22.2) 1.250 (31.8)
24
1.688 (42.9) 2.363 (60.0) 1.000 (25.4) 1.375 (34.9)
28
1.938 (49.2) 2.770 (70.4) 1.250 (31.8) 1.625 (41.3)
32
1.938 (49.2) 3.020 (76.7) 1.437 (36.5) 1.875 (47.6)
See inside back cover fold-
out or page 14 for Table II.
1. Metric dimensions (mm) are indicated in
parentheses.
2. Cable range is defined as the accommo-
dations range for the wire bundle or
cable. Dimensions shown are not
intended for inspection criteria.
3. Style C saddles are bottomed on clamp
ears.
TABLE V: CABLE ENTRY
X - Cable Range
S
T
W
Max
Max
Max
Min **
Max
.843 (21.4)
.562 (14.3)
.630 (16.0) .156 (4.0) .250 (6.4)
.906 (23.0)
.562 (14.3)
.755 (19.2) .188 (4.8) .312 (7.9)
.562 (14.3) 1.093 (27.8)
.942 (23.9) .281 (7.1) .438 (11.1)
.562 (14.3) 1.187 (30.1) 1.067 (27.1) .344 (8.7) .562 (14.3)
.562 (14.3) 1.281 (32.5) 1.192 (30.3) .375 (9.5) .625 (15.9)
.562 (14.3) 1.500 (38.1) 1.380 (35.1) .438 (11.1) .750 (19.1)
.562 (14.3) 1.719 (43.7) 1.535 (39.0) .562 (14.3) .938 (23.8)
.562 (14.3) 2.062 (52.4) 1.848 (46.9) .750 (19.1) 1.250 (31.8)
.594 (15.1) 2.312 (58.7) 2.255 (57.3) .781 (19.8) 1.375 (34.9)
.594 (15.1) 2.719 (69.1) 2.505 (63.6) .969 (24.6) 1.625 (41.3)
.750 (19.1) 2.969 (75.4) 2.755 (70.0) 1.125 (28.6) 1.875 (47.6)
.812 (20.6) 3.531 (89.7) 3.255 (82.7) 1.469 (37.3) 2.375 (60.3)
** Not Applicable Style D
CAGE Code 06324
Printed in U.S.A.
GLENAIR, INC.
•
1211 AIR WAY
•
GLENDALE, CA 91201-2497
•
818-247-6000
•
FAX 818-500-9912
www.glenair.com
E-Mail: sales@glenair.com
Series 62 - Page 22
