ALUMINUM ELECTROLYTIC CAPACITORS
UAQ
Specifications
Wide Temperature Range, Permissible
Abnormal Voltage
Improved safety feature for abnormally excessive voltage.
High ripple current product.
Compliant to the RoHS directive (2011/65/EU).
UAQ
Smaller
UAS
Performance Characteristics
–40 to +105°C
200
·
400V
10 to 220µF
± 20% at 120Hz, 20°C
After 1 minute's application of rated voltage at 20°C, leakage current is 0.04CV+100 (µA) or less.
Rated voltage (V)
tan
δ
(MAX.)
Item
Category Temperature Range
Rated Voltage Range
Rated Capacitance Range
Capacitance Tolerance
Leakage Current
Tangent of loss angle (tan
δ)
200
0.15
400
0.15
Measurement frequency:120Hz at 20°C
Rated voltage (V)
Stability at Low Temperature
Impedance ratio ZT / Z20 (MAX.)
Z– 25°C / Z+20°C
Z– 40°C / Z+20°C
200
3
6
400
8
10
Measurement frequency : 120Hz
Endurance
Shelf Life
The specifications listed at right shall be met when the
Within ±20% of the initial capacitance value
Capacitance change
capacitors are restored to 20°C after D.C. bias plus rated
200% or less than the initial specified value
tan
δ
ripple current is applied for 2000 hours at 105°C, the peak
Less than or equal to the initial specified value
Leakage current
voltage shall not exceed the rated voltage.
After storing the capacitors under no load at 105°C for 1000 hours and then performing voltage treatment based on JIS C 5101-4
clause 4.1 at 20°C, they shall meet the specified values for the endurance characteristics listed above.
The pressure relief vent will operate in normal conditions, with no dangerous conditons such as flames, ignitions or dispersion of pieces of the capacitor and / or case.
Test conditions
voltage (V)
Safety Performance
200
400
Marking
Limited DC current
4A
2A
Test Voltage
300VDC and 375VDC
500VDC and 600VDC
Printed with white color letter on dark brown sleeve.
Radial Lead Type
Sleeve (P.E.T. )
φd
Type numbering system (Example : 200V 100
µ
F)
1
2
3
4
5
6
7
8
9 10 11
12
Size code
U AQ 2 D 1 0 1 MHD
φD
+
MAX.
P±
0.5
Configuration
Capacitance tolerance (±20%)
Rated capacitance (100µF)
(mm)
Rated voltage (200V)
Series name
Type
Configuration
φ
D
10
12.5 to 18
22
Pb-free leadwire
Pb-free PET sleeve
Pressure
relief vent
L+
MAX.
15
MIN
4
MIN
φD
10 12.5 16
P
18
22
10
0.5 0.5 0.5 0.5 1.0
5.0 5.0 7.5 7.5
φd
0.6 0.6 0.8 0.8 1.0
•
Please refer to page 20 about the end seal
configuration.
In case L>25 for
φ12.5
(D) case sizes,
lead diameter
φ0.8
(d) will be applied.
PD
HD
RD
(φD 18) 2.0
(φD >18) 3.0
Dimensions
V(Code)
Cap.(µF)
Code
φD
φ
10
φ
12.5
200 (2D)
φ
16
400 (2G)
φ
18
φ
22
φ
12.5
φ
16
φ
18
φ
22
010
022
033
047
056
068
082
100
150
180
220
100
220
330
470
560
680
820
101
151
181
221
10
×
20
120
10
×
25
160
0.10
×
31.5
195
12.5
×
20.0
160
12.5
×
20.0
195
12.5
×
25.0
210
12.5
×
25.0
250
12.5
×
31.5
285
12.5
×
35.5
335
12.5
×
20.0
100
12.5
×
31.5
145
12.5
×
40.0
195
16
×
20
285
16
×
25
335
0.16
×
31.5
435
0.16
×
35.5
495
16
×
20
145
16
×
25
195
0.16
×
35.5
280
0.16
×
35.5
320
16
×
40
350
18
×
20
335
18
×
25
435
18
×
31.5
495
0.18
×
35.5
575
18
×
20
195
18
×
25
280
18
×
31.5
320
18
×
35.5
350
18
×
40
420
22
×
20
280
22
×
25
320
22
×
20
435
22
×
25
495
Case size
φD×L
(mm)
Rated ripple
Frequency coefficient of rated ripple current
Frequency
Coefficient
50, 60Hz
0.80
120Hz
1.00
300Hz
1.25
1kHz
1.40
10kHz or more
1.60
Rated ripple current (mArms) at 105°C 120Hz
: In case of low profile type, 6 will be put at 12th digit of type numbering system.
: For further low profile product, 3 will be put at 12th digit.
267
Please refer to page 20, 21, 22 about the formed or taped product spec.
Please refer to page 4 for the minimum order quantity.
