64
www.vishay.com
Vishay Spectrol
3/8" Square (10 mm) Multi-Turn Cermet Trimmer
FEATURES
• Industrial grade
• 0.5 W at 70 °C
• Tests according to CECC 41000 or IEC 60393-1
• Contact resistance variation < 2 %
• Material categorization: for definitions of compliance
please see
www.vishay.com/doc?99912
DESIGN SUPPORT TOOLS
Models
Available
click logo to get started
The Model 64 is a small size trimmer - 3/8" x 3/8" x 3/16" - answering PC board mounting requirements. Five versions are
available which differ by the position of the control screw in relation to the PC board plane and by the spacing of the terminals.
Excellent operational stability is provided by the use of a cermet element.
DIMENSIONS
in millimeters (± 0.5 mm)
9.8 max. 5 ± 1
64X
2.3 ± 0.2
(1)
5 max.
a
b
c
Terminal Spacing on
a 2.54 PCB
2.54
2.54
Ø 0.5
9.7 max.
a
b
c
1.3
Ø 2.2
7.9 ± 0.2
0.5
1.2 ± 0.2
Slot 0.6 x 0.6
64Z
2.54
(1)
0.6 ± 0.2
(1)
9.8 max. 5 ± 1
5 max.
a
b
c
Ø 0.5
9.7 max.
2.54
2.54
(1)
1.3
Ø 2.2
0.5
1.2 ± 0.2
7.9 ± 0.2
1.3
Ø 2.2
9.8 max. 5 ± 1
1.2 ± 0.1
1.6 ± 0.1
a
b
c
Slot 0.6 x 0.6
64W
2.3 ± 0.2
(1)
2.54
2.54
(1)
(1)
a
b
c
0.5
9.7 max.
Ø 0.5
5 max.
1.2 ± 0.1
1.6 ± 0.1
9.7 max.
Ø 0.5
Slot 0.6 x 0.6
a
b
c
64Y
0.6 ± 0.2
(1)
2.54
1.3
Ø 2.2
9.8 max. 5 ± 1
2.54
2.54
(1)
(1)
Slot 0.6 x 0.6
0.5
a
b
c
a
b
c
5 max.
5.2 max.
5±1
64P
Slot 0.6 x 0.6
4.8 ± 0.2
(1)
2.54
(1)
9.7 max.
2.54
2.54
(1)
(1)
c
b
a
Ø 0.5
Base level
Ø 2.2
1.3
9.7 max.
c
b
a
0.5
1.3 ± 0.1
1.2 ± 0.1
Note
Revision: 26-Jan-18
Document Number: 57028
1
For technical questions, contact:
sferpottrimmers@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
64
www.vishay.com
(1)
Vishay Spectrol
To be measured at base level
ELECTRICAL SPECIFICATIONS
Resistive element
Electrical travel
Resistance range
Standard series E3
Tolerance
Standard
On request
linear
Cermet
21 turns ± 2
10
to 2.2 M
1 - 2 - 2.5 - 5
10 %
5%
0.5 W at +70 °C
0.5
POWER IN W
Power rating
0
0
25
50
70
100
125
155
AMBIENT TEMPERATURE IN °C
a
c
(3)
b
(2)
cw
Circuit diagram
(1)
Temperature coefficient
Limiting element voltage (linear law)
Contact resistance variation
End resistance (typical)
Dielectric strength (RMS)
Insulation resistance (500 V
DC
)
See Standard Resistance Element table
250 V
2 % Rn or 2
1
1000 V
10
6
M
MECHANICAL SPECIFICATIONS
Mechanical travel
Operating torque (max. Ncm)
End stop torque
Net weight
Wiper (actual travel)
Terminals
23 turns ± 5
1.5
Clutch action
Approx. 0.82 g
Positioned at approx. 50 %
Pure Sn (code e3)
ENVIRONMENTAL SPECIFICATIONS
Temperature range
Climatic category
Sealing
-55 °C to +125 °C
55/125/56
Fully sealed - IP67
Revision: 26-Jan-18
Document Number: 57028
2
For technical questions, contact:
sferpottrimmers@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
64
www.vishay.com
Vishay Spectrol
LINEAR LAW
MAX. POWER
AT 70 °C
W
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.31
0.25
0.125
0.063
0.031
MAX. WORKING
VOLTAGE
V
2.2
3.2
5
7.1
10
11.2
15.8
22.4
31.6
35.4
50
70.7
100
112
158
224
250
250
250
250
250
MAX. CURRENT
THROUGH WIPER
mA
224
158
100
71
50
45
32
22
16
14
10
7.1
5
4.5
3.2
2.2
1.3
1
0.5
0.25
0.13
TYPICAL
TCR
-55 °C
+125 °C
ppm/°C
STANDARD RESISTANCE ELEMENT DATA
STANDARD
RESISTANCE
VALUES
10
20
50
100
200
250
500
1K
2K
2.5K
5K
10K
20K
25K
50K
100K
200K
250K
500K
1M
2M
± 100
PERFORMANCES
TESTS
Load life
CONDITIONS
1000 h at rated power
90'/30' - ambient temp. 70 °C
Phase A dry heat 125 °C - 30 % Pr
Phase B damp heat
Phase C cold -55 °C
Phase D damp heat 5 cycles
56 days
40 °C, 93 % RH
5 cycles
-55 °C to +125 °C
50 g at 11 ms
3 successive shocks
in 3 directions
10 Hz to 55 Hz
0.75 mm or 10 g
during 6 h
200 cycles
TYPICAL VALUES AND DRIFTS
R
T
/R
T
(%)
±1%
Contact res. variation: < 1 % Rn
± 0.5 %
± 0.5 %
Dielectric strength: 1000 V
RMS
Insulation resistance: > 10
4
M
± 0.5 %
± 0.1 %
R
1-2
/R
1-2
(%)
±2%
Climatic sequence
±1%
Long term damp heat
Rapid temperature change
Shock
±1%
V
1-2
/V
1-3
± 1 %
± 0.2 %
Vibration
Rotational life
± 0.1 %
±4%
Contact res. variation: < 1 % Rn
V
1-2
/V
1-3
± 0.2 %
-
Note
• Nothing stated herein shall be construed as a guarantee of quality or durability
MARKING
•
•
•
•
•
•
•
Vishay trademark
Model
Style
Ohmic value (in
,
k, M)
Tolerance (in %)
Manufacturing date
Marking of terminal 3
Revision: 26-Jan-18
Document Number: 57028
3
For technical questions, contact:
sferpottrimmers@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
64
www.vishay.com
Vishay Spectrol
PACKAGING
• In box of 200 pieces code B40 (BO200)
On request:
• In box of 100 pieces code B30 (BO100)
• In tube of 50 pieces code T20 (TU50)
ORDERING INFORMATION
(part number)
M
6
4
P
2
2
4
K
B
4
0
Model
M64
STYLE
P
W
X
Y
Z
OHMIC VALUE
From
10
to 2.2 M
224
= 220 k
TOLERANCE
K
= 10 %
On request
J
=5%
PACKAGING
B40
= box
200 pieces
On request:
B30
= box
100 pieces
T20
= tube
50 pieces
SPECIAL
NUMBER
(If applicable)
Given by Vishay
for custom design
DESCRIPTION
(for information only)
64
MODEL
P
STYLE
220K
VALUE
10 %
TOLERANCE
SPECIAL
BO200
PACKAGING
e3
LEAD FINISH
RELATED DOCUMENTS
APPLICATION NOTES
Potentiometers and Trimmers
Guidelines for Vishay Sfernice Resistive and Inductive Components
www.vishay.com/doc?51001
www.vishay.com/doc?52029
Revision: 26-Jan-18
Document Number: 57028
4
For technical questions, contact:
sferpottrimmers@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
