P13SM
www.vishay.com
Vishay Sfernice
Fully Sealed Container Cermet Potentiometers
Submarine Applications
FEATURES
• High power rating 1.5 W at 70 °C
• Stainless steel shaft and bushing to endure sea
salt water immersion
• Fully sealed IP68 on panel
• Tight temperature coefficient (± 75 ppm/°C typical)
• Material categorization: for definitions of compliance
please see
www.vishay.com/doc?99912
P13SM is designed for applications which need to set
electrical parameters with an immersed potentiometer in
deep water conditions up to 30 m (100 feet).
QUICK REFERENCE DATA
Multiple module
Switch module
Detent module
Special electrical laws
Sealing level
Lifespan
No
n/a
n/a
A: linear, L: logarithmic, F: reverse
logarithmic
IP 68
25K cycles
DIMENSIONS
in millimeters (inches) ± 0.5 mm (± 0.02")
P13SM N
Panel Cutout
Thread M10 x 0.75
14.6 max. 10.3
Slot 1 x 1.8 deep
Ø 16 Ø 14
FG = 16
FL = 25
FR = 50
Ø6
0.3
5.08
1.6
0.8
2.4
Ø 1.5
(1)
2 5.08
6.9 ± 0.2
5
1.6
Ø 10.5
P13SM B
1
13.2 max.
1/4-32 UNEF-2A
Slot 0.6 x 1 deep
Ø 12.6
(0.5")
9.52
5
BB = 12.7
BJ = 22.2
Ø 3.17 (0.125")
0.3
5.08
1.6
0.8
2.4
Ø 6.5
2 5.08
3.9 ± 0.2
1.6
Panel Cutout
Ø 1.5
(1)
Note
(1)
CAUTION: Ø 1.5 of panel cut out must not be fully through-hole
Undergoes European Quality Insurance System
Revision: 04-Jul-17
Document Number: 51064
1
For technical questions, contact:
sferpottrimmers@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
P13SM
www.vishay.com
Vishay Sfernice
ELECTRICAL SPECIFICATIONS
Resistive element
Electrical travel
Resistance range
Standard series E3
Tolerance
standard
on request
100
Cermet
270° ± 10°
linear taper
logarithmic taper
22
Ω
to 10 MΩ
1 kΩ to 2.2 MΩ
1, 2.2, 4.7, and on request 1, 2, 5
± 20 %
± 10 % to ± 5 %
% TOTAL RESISTANCE
80
60
40
20
0
F
A
L
Taper
0
20
40
60
80
100
% CLOCKWISE SHAFT ROTATION
a
c
(3)
b
(2)
cw
Circuit diagram
(1)
1.5
LIN. TAPER A
POWER IN W
Linear
1.5 W at 70 °C
Power rating
Logarithmic
0.75 W at 70 °C
1
0.5
LOG. TAPER
L and F
0
0
20
40
60 70 80
100
120 140
AMBIENT TEMPERATURE IN °C
Temperature coefficient (typical)
Limiting element voltage (linear law)
Contact resistance variation
End resistance (typical)
Dielectric strength (RMS)
Insulation resistance (300 V
DC
)
Independent linearity (typical)
± 150 ppm/°C
For values
≥
100
Ω
and in temperature range +20 °C to +70 °C,
the typical temperature coefficient is ± 75 ppm/°C
350 V
3 % Rn or 3
Ω
1
Ω
2000 V
10
6
MΩ
±5%
Revision: 04-Jul-17
Document Number: 51064
2
For technical questions, contact:
sferpottrimmers@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
P13SM
www.vishay.com
Vishay Sfernice
STANDARD RESISTANCE ELEMENT DATA
STANDARD
RESISTANCE
VALUES
Ω
22
47
100
220
470
1K
2.2K
4.7K
10K
22K
47K
100K
220K
470K
1M
2.2M
4.7M
10M
LINEAR TAPER
MAX.
POWER
AT 70 °C
W
1.5
1.5
1.5
1.5
1.5
1.5
1.5
1.5
1.5
1.5
1.5
1.22
0.56
0.26
0.12
0.05
0.026
0.012
MAX.
WORKING
VOLTAGE
V
5.74
8.4
12.2
18.2
26.5
38.7
57.5
84
122.5
182
265
350
350
350
350
350
350
350
MAX. CUR.
THROUGH
WIPER
mA
261
177
122
82.6
56.5
38.7
26.1
17.9
12.2
8.26
5.65
3.5
1.6
0.74
0.35
0.16
0.074
0.035
MAX.
POWER
AT 70 °C
W
-
-
-
-
-
0.75
0.75
0.75
0.75
0.75
0.75
0.75
0.56
0.26
0.12
0.05
-
-
LOGS TAPED
MAX.
WORKING
VOLTAGE
V
-
-
-
-
-
27
40
59
87
128
187
273
350
350
350
350
-
-
MAX. CUR.
THROUGH
WIPER
mA
-
-
-
-
-
27
18
12
8.7
5.8
3.9
2.7
1.6
0.74
0.35
0.16
-
-
± 150
TYPICAL
TCR
-55 °C
+125 °C
ppm/°C
MECHANICAL SPECIFICATIONS
Mechanical travel
Style B
Style N
Operating torque (typical)
End stop torque
Style B
Style N
Tightening torque of mounting nut
Style B
Style N
Unit weight
Terminals
80 Ncm min., 150 Ncm max.
80 Ncm min., 250 Ncm max.
8 g to 27 g
e3: pure Sn
7 lb inch min., 13.3 lb inch max.
7 lb inch min., 22.1 lb inch max.
0.3 oz. to 1 oz.
35 Ncm max.
80 Ncm max.
3.1 lb inch max.
7.1 lb inch max.
2 Ncm
300° ± 5°
310° ± 5°
2.85 oz. inch
ENVIRONMENTAL SPECIFICATIONS
Temperature range
Climatic category
Sealing
Panel sealing
-55 °C to +125 °C
55 / 125 / 56
Fully sealed - container IP68
Immersion at 30 m (100 feet) in sea salt water or clear water
Revision: 04-Jul-17
Document Number: 51064
3
For technical questions, contact:
sferpottrimmers@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
P13SM
www.vishay.com
Vishay Sfernice
OPTIONS
Special feature command shaft
Length is measured from the mounting surface to the free end of the shaft. The
screwdriver slot is aligned with the wiper within ± 10°. Special shafts are available, in
accordance to drawings supplied by customers. We recommend that customers
should not machine tool shafts, in order to avoid damage. Bending or torsion of
terminals should also be avoided.
MARKING
Printed:
• Vishay trademark
• Part number (including ohmic value code, tolerance code and resistance law)
• Manufacturing date
• Marking of terminals a
PACKAGING
In box
Packaging quantity depending on shafts:
• Box of 5 pieces for shaft FR (code BO5)
• Box of 10 pieces for shaft FG or FL (code BO10)
• Box of 15 pieces for shaft BJ (code BO15)
• Box of 25 pieces for shaft BB (code BO25)
PERFORMANCE
TESTS
Electrical endurance
CONDITIONS
1000 h at rated power
90'/30' - ambient temperature 70 °C
Phase A dry heat 125 °C
Phase B damp heat
Phase C cold -55 °C
Phase D damp heat 5 cycles
56 days
40 °C, 93 % HR
5 cycles
-55 °C at +125 °C
25 000 cycles
50
g’s
at 11 ms
3 successive shocks
in 3 directions
10 Hz to 55 Hz
0.75 mm or 10
g’s
during 6 h
TYPICAL VALUES AND DRIFTS
ΔR
T
/R
T
(%)
±1%
ΔR
1-2
/R
1-2
(%)
-
OTHER
Contact res. variation: < 3 % Rn
Climatic sequence
± 0.5 %
±1%
-
Dielectric strength: 1000 V
Insulation resistance: > 10
4
MΩ
-
Contact res. variation: < 2 % Rn
-
Damp heat, steady state
Change of temperature
Mechanical endurance
Shock
± 0.5 %
± 0.5 %
±3%
± 0.1 %
±1%
-
-
± 0.2 %
Vibration
± 0.1 %
-
ΔV
1-2
/V
1-3
< ± 0.2 %
Note
• Nothing stated herein shall be construed as a guarantee of quality or durability
Revision: 04-Jul-17
Document Number: 51064
4
For technical questions, contact:
sferpottrimmers@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
P13SM
www.vishay.com
Vishay Sfernice
ORDERING INFORMATION
(Part Number)
P
1
3
S
M
N
F
L
SHAFT
STYLE
L
S = slotted
On request:
R = round
F = flat
D = custom
S
1
OHMIC
VALUE
Linear law
from 22
Ω
to 10 MΩ
0
3
M
A
E
MODEL
P13SM
BUSHING
Ø
L
Shaft
Ø
6
SHAFT
Ø
TOLERANCE
M = 20 %
On request:
K = 10 %
J=5%
TAPER
A = linear
L = clockwise
logarithmic
F = inverse
clockwise
logarithmic
SPECIAL
E=
locating peg
or
special code
given by
Vishay
BB 3.17 12.7
BJ 3.17 22.2
FG
FL
FR
6
6
6
16
25
50
N 10 10.3
B 6.35 9.52 3.17
Logarithmic
law from
1 kΩ to 2.2 MΩ
103 = 10 kΩ
AP Custom
PART NUMBER DESCRIPTION
(for information only)
P13SM
N
E
FL
S
10K
20 %
A
BO10
e3
MODEL BUSHING SPECIAL SHAFT
SHAFT
LEAD
VALUE TOLERANCE TAPER SPECIAL PACKAGING SHAFT SPECIAL
STYLE
(Pb)-FREE
RELATED DOCUMENTS
APPLICATION NOTES
Potentiometers and Trimmers
Guidelines for Vishay Sfernice Resistive and Inductive Components
www.vishay.com/doc?51001
www.vishay.com/doc?52029
