ALUMINUM ELECTROLYTIC CAPACITORS
UKZ
Premium Grade Type, For Audio Equipment
Premium grade “nichicon MUSE” acoustic series.
Ideally suited for first class audio equipment where qualitative and quantitative
comfortableness is required.
Compliant to the RoHS directive (2011/65/EU).
UKZ
Specifications
Item
Category Temperature Range
Rated Voltage Range
Rated Capacitance Range
Capacitance Tolerance
Leakage Current
Tangent of loss angle (tan
δ)
High Grade
UFG
Performance Characteristics
–40 to +85°C
25 to 100V
10 to 1000µF
± 20% at 120Hz, 20°C
After 1 minute's application of rated voltage at 20°C, leakage current is 0.01CV or less.
Measurement frequency : 120Hz at 20°C
Rated voltage (V)
tan
δ
(MAX.)
25
0.12
25
2
4
50
0.08
50
2
3
100
0.07
100
2
3
Measurement frequency : 120Hz
Stability at Low Temperature
Rated voltage (V)
Impedance ratio
ZT / Z20 (MAX.)
Z– 25°C / Z+20°C
Z– 40°C / Z+20°C
Endurance
Shelf Life
Marking
The specifications listed at right shall be met
Capacitance change
Within ±20% of the initial capacitance value
when the capacitors are restored to 20°C after
150% or less than the initial specified value
tan
δ
the rated voltage is applied for 1000 hours at
Less than or equal to the initial specified value
Leakage Current
85°C.
After storing the capacitors under no load at 85°C for 1000 hours and then performing voltage treatment based on JIS C 5101-4
clause 4.1 at 20°C, they shall meet the specified values for the endurance characteristics listed above.
Printed with gold color letter on black sleeve.
Radial Lead Type
Sleeve (P.E.T.)
Sleeve (P.E.T.)
φ
0.8 copper wire
φ
0.8 tinnedtinned copper wire
Type numbering system (Example : 25V 100
µ
F)
1
10
2 1 3 2 43 5 4 65 7 6 8 7 98 109 11
11
UK Z 1 E
1 M P
U K Z 1 E 1 01 10 M P M M
φD
+
0.5MAX.
φD
+
0.5MAX.
P ±
0.5
P ±
0.5
Configuration
Configuration
φD φD
CodeCode
8 · 10 8 · 10
PM PM
Rated capacitance (100µF)
Rated capacitance (100µF)
12.5 18
12.5 to 18 to HM HM
Rated voltage
Rated voltage (25V)(25V)
Series
Series namename
Capacitance tolerance
Capacitance tolerance
(±20%)
(±20%)
Pressure
Pressure
relief
relief vent vent
L+
MAX.
L+
MAX.
15
MIN
15
MIN
MIN
4
MIN
4
(mm) (mm)
Type Type
α
(φD < 10) 1.0
(φD 10) 1.5
φD
P
φD
810 10
8
12.5 12.5
16 16
18 18
P
3.5
5.0
5.0
7.5
3.5
5.0
5.0
7.5
7.5 7.5
•
Please refer to page 20 about the end seal configuration.
Dimensions
Cap.(µF)
V
Code
25
1E
8
×
11.5
10
×
12.5
10
×
16
12.5
×
20
12.5
×
25
16
×
25
16
×
35.5
10
22
33
47
1000
2200
3300
4700
100000
100
220
330
470
101
221
331
471
102
50
1H
8
×
11.5
10
×
12.5
10
×
16
12.5
×
20
16
×
25
16
×
31.5
16
×
35.5
18
×
40
φ
D
×
L (mm)
100
2A
8
×
11.5
10
×
16
10
×
20
12.5
×
20
16
×
25
16
×
35.5
18
×
35.5
Please refer to page 20, 21, 22 about the formed or taped product spec.
Please refer to page 4 for the minimum order quantity.
270
