Features
n
Formerly model
n
Available in E12 series
n
Height of 2.9 mm
n
Current rating up to 2.1 A
n
RoHS compliant*
F
RE
E
Applications
n
Input/output of DC/DC converters
n
Power supplies for:
*R
oH
S
C
OM
• Portable communication equipment
• Camcorders
• LCD TVs
LE
AD
Inductance 100 kHz
PM105SB Series - Shielded SMD Power Inductor
Test
Q Frequency
Ref.
(MHz)
39
2.52
40
2.52
35
2.52
39
2.52
35
2.52
35
2.52
27
2.52
31
2.52
27
2.52
26
2.52
26
2.52
26
2.52
29
0.796
31
0.796
24
0.796
24
0.796
27
0.796
30
0.796
29
0.796
26
0.796
26
0.796
SRF
Typ.
(MHz)
29
26
24
21
18
17
14
14
11
11
10
9
8
7
6
5
5
5
4
3
3
DCR
Max.
(Ω)
0.06
0.07
0.07
0.08
0.08
0.10
0.11
0.12
0.14
0.19
0.21
0.28
0.34
0.37
0.51
0.57
0.78
0.87
1.20
1.34
1.50
Electrical Specifications
Ro VE LEA
HS RS D
C ION FRE
OM S E
PL AR
IA E
NT
*
Bourns Part No.
PM105SB-100M-RC
PM105SB-120M-RC
PM105SB-150M-RC
PM105SB-180M-RC
PM105SB-220M-RC
PM105SB-270M-RC
PM105SB-330L-RC
PM105SB-390L-RC
PM105SB-470L-RC
PM105SB-560L-RC
PM105SB-680L-RC
PM105SB-820L-RC
PM105SB-101K-RC
PM105SB-121K-RC
PM105SB-151K-RC
PM105SB-181K-RC
PM105SB-221K-RC
PM105SB-271K-RC
PM105SB-331K-RC
PM105SB-391K-RC
PM105SB-471K-RC
(µH)
10
12
15
18
22
27
33
39
47
56
68
82
100
120
150
180
220
270
330
390
470
Tol. %
±20
±20
±20
±20
±20
±20
±15
±15
±15
±15
±15
±15
±10
±10
±10
±10
±10
±10
±10
±10
±10
Idc
(A)
2.1
1.9
1.7
1.6
1.4
1.3
1.2
1.1
1.0
0.93
0.85
0.79
0.72
0.63
0.55
0.50
0.47
0.41
0.37
0.35
0.33
Test Voltage ...................................1 Volt
Reflow Soldering ....230 ˚C; 50 sec max.
Operating Temp........... -40 °C to +125 °C
(Temperature rise included)
Storage Temperature .. -40 °C to +125 °C
Resistance to Soldering Heat
................................. 260 °C for 5 sec.
Moisture Sensitivity Level .....................2
ESD Classification (HBM)................. N/A
Core Material ................. Ferrite DR & RI
Wire ...........................Enameled Copper
Terminal ....................................Ag/Ni/Sn
Rated Current
...................Ind. drop 10 % typ at I sat
Temperature Rise
...................... 15 ˚C typ. at rated I rms
Packaging .................... 500 pcs. per reel
Product Dimensions
Materials
General Specifications
100 100
9.9 ± 0.3
(.390 ± .012)
9.9 ± 0.3
(.390 ± .012)
Inductance vs. Current
104
7
5
3
2
103
7
4.5 ± 0.3
(.177 ± .012)
4.5 ± 0.3
(.177 ± .012)
2.9
TYP.
(.114)
152
471
2.9
TYP.
(.114)
Inductance (µH)
5
3
2
102
7
5
3
2
101
7
5
3
2
100
101
330
Recommended Layout
10.0
REF.
(.394)
10.0
REF.
(.394)
10.0
(.394)
REF.
10.0
(.394)
REF.
100
101
2
3
5 7 102
2
3
5 7 103
2
3
5 7 104
DC Current (mA)
*RoHS Directive 2002/95/EC Jan. 27, 2003 including annex and RoHS Recast 2011/65/EU June 8, 2011.
Specifications are subject to change without notice.
The device characteristics and parameters in this data sheet can and do vary in different applications and actual device
performance may vary over time.
Users should verify actual device performance in their specific applications.
MM
DIMENSIONS:
(INCHES)
2.8
(.110)
REF.
2.8
(.110)
REF.
PM105SB Series - Shielded SMD Power Inductor
Soldering Profile
275
<1> Maximum of 10 seconds between
+255°C and +260°C
225
220°C
190°C
60 - 90
seconds
Ramp Down
6°C/second
maximum
260°C peak
<1> 255°C
Electrical Schematic
Temperature (°C)
175
150°C
125
120 - 150 seconds
10 seconds minimum
75
Ramp Up
3°C/second maximum
25
0
50
100
150
200
250
Rev. 02/22/05
300
Time (seconds)
Packaging Specifications
330.0
330.0 (12.992)
(12.992) DIA.
DIA.
2.0
±
0.5
2.0
±
0.5
(.079
±
.020)
(.079
±
.020)
30.4
30.4
(1.197)
(1.197)
DIA.
DIA. 13.0 ± 0.5
13.0 ± 0.5
(.512 ± .020)
(.512 ± .020)
50.0 - 0
50.0 - 0 (1.969 - 0)
(1.969 - 0)
21.0
±
0.8
21.0
±
0.8
(.827
±
.032)
(.827
±
.032)
13.0 ± 0.5
DIA.
13.0 ± 0.5
(.512 ± .020)
DIA.
(.512 ± .020)
26. + 0
26. + 0 (1.023 + 0)
(1.023 + 0)
END
END
16.0
(.630)
16.0
(.630)
4.0
(.157)
4.0
(.157)
START
START
100
100
100
100
NO COMPONENT
NO COMPONENT
200
100
MM
DIMENSIONS:
(INCHES)
100
100
100
100
100
200
(7.87)
(7.87)
COMPONENTS
COMPONENTS
NO COMPONENT
NO COMPONENT
400
400
(15.75)
(15.75)
USER DIRECTION OF FEED
USER DIRECTION OF FEED
QTY: 500 PCS. PER REEL
REV. 03/18
Specifications are subject to change without notice.
The device characteristics and parameters in this data sheet can and do vary in different applications and actual device performance may vary over time.
Users should verify actual device performance in their specific applications.
