F1772 X2
www.vishay.com
Vishay Roederstein
Interference Suppression Film Capacitor - Class X2
Radial MKT 310 V
AC
- High Stability Grade
FEATURES
•
•
•
•
15 mm to 37.5 mm lead pitch
Internal series construction
AEC-Q200 qualified for C
470 nF
Material categorization:
for definitions of compliance please see
www.vishay.com/doc?99912
APPLICATIONS
High stability grade for continuous across the line X2
applications.
See also application note:
www.vishay.com/doc?28153
QUICK REFERENCE DATA
Capacitance range (E12 series)
Capacitance tolerance
Rated AC voltage
Permissible DC voltage
Climatic testing class according to IEC 60068-1
Maximum application temperature
Reference standards
Dielectric
Electrodes
Construction
Encapsulation
Leads
Marking
Plastic case, epoxy resin sealed, flame retardant UL-class 94 V-0
Tinned wire
C-value; tolerance; rated voltage; sub-class; manufacturer’s type;
code for dielectric material; manufacturer location, year and week;
manufacturer’s logo or name; safety approvals
0.01 μF to 2.2 μF
(preferred values acc. to E6)
± 10 %, ± 20 % (± 5 % on request)
310 V
AC
; 50 Hz to 60 Hz
800 V
DC
at 85 °C
630 V
DC
at 110 °C
40/110/56/C
110 °C
IEC 60384-14 ed-4 and EN 60384-14
IEC 60065 pass. flamm. class C
CSA-E384-14
UL 60384-14
Polyester film
Metallized
Series construction
Note
• For more detailed data and test requirements, contact
rfi@vishay.com
DIMENSIONS
in millimeters
l
w
h
l
t
Pitch
P ± 0.4
Ø d
t
Revision: 16-Aug-17
Document Number: 28161
1
For technical questions, contact:
rfi@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
F1772 X2
www.vishay.com
COMPOSITION OF CATALOG NUMBER
MULTIPLIER
(nF)
0.1
1
10
100
2
3
4
5
CAPACITANCE
(numerically)
Example:
468 = 680 nF
Vishay Roederstein
F
1772 X XX
TYPE
XXXX
PACKAGING (Loose)
Tolerance
± 10 %
Standard
pitch size
and
dimension
Reduced
pitch size
and
dimension
(2)
Example:
2004
2000
2015
2030
2164
2160
2165
2163
± 20 %
2204
2200
2215
2230
2264
2260
2265
2263
Lead length
(mm)
4-1
6-1
15 - 1
30 + 5
4-1
6-1
15 - 1
30 + 5
PACKAGING (Taped on reel)
(1)
Tolerance
± 10 %
Standard
pitch size
and
dimension
Reduced
pitch size
and
dimension
(2)
2900
2901
± 20 %
2290
2291
Taping height
(mm)
16.5
18.5
2970
2971
2960
2961
16.5
18.5
F17724152215 means 0.15 µF, ± 20 %; standard pitch 22.5 mm; lead length 15 mm - 1 mm;
F17724152265 means 0.15 µF, ± 20 %; reduced pitch 15.0 mm; lead length 15 mm - 1 mm
Notes
• For detailed tape specifications refer to packaging information
www.vishay.com/doc?28139
(1)
Taped on reel pitch
27.5 mm is not available
(2)
Same capacitance values
0.15 μF are available in two different pitch sizes and dimensions
SPECIFIC REFERENCE DATA
DESCRIPTION
Rated AC voltage (U
RAC
)
Permissible DC voltage (U
RDC
)
Tangent of loss angle
Rated voltage pulse slope at (dU/dt)
R
435 V
DC
R between leads, for C
0.33 μF at 100 V; 1 min
RC between leads, C > 0.33 μF at 100 V; 1 min
R between leads and case; 100 V; 1 min
Withstanding (DC) voltage (cut off current 10 mA)
(1)
; rise time
1000 V/s
C
0.47 μF
C > 0.47 μF
Withstanding (AC) voltage between leads and case
Maximum application temperature
Note
• See “Voltage Proof Test for Metalized Film Capacitors”:
www.vishay.com/doc?28169
2200 V; for 1 min
2150 V; for 1 min
2120 V; 1 min
110 °C
VALUE
310 V
630 V
100 x 10
-4
at 1 kHz
100 V/μs
> 15 000 M
> 5000 s
> 30 000 M
Revision: 16-Aug-17
Document Number: 28161
2
For technical questions, contact:
rfi@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
F1772 X2
www.vishay.com
Vishay Roederstein
ORDERING CODE
BULK
LEAD LENGTH
6 mm - 1 mm
(1)(2)
F17723102000
F17723122000
F17723152000
F17723182000
F17723222000
F17723272000
F17723332000
F17723392000
F17723472000
F17723562000
F17723682000
F17723822000
F17724102000
F17724122000
F17724152160
F17724152000
F17724182000
F17724222160
F17724222000
F17724272000
F17724332160
F17724332000
F17724392000
F17724472160
F17724472000
F17724562000
F17724682160
F17724682000
F17724822000
F17725102160
F17725102000
F17725122000
F17725152160
F17725152000
F17725182000
F17725222160
F17725222000
F17723102200
F17723152200
F17723222200
F17723332200
F17723472200
F17723682200
F17724102200
ELECTRICAL DATA AND ORDERING INFORMATION
U
RAC
(V)
CAP.
(μF)
PITCH
(mm)
DIMENSIONS
(4)
wxhxl
MAX. (mm)
MASS
(3)
(g)
SPQ
(pieces)
SHORT LEAD
d
t
= 0.60 mm ± 0.06 mm; C-TOL. = ± 10 %
0.010
0.012
0.015
0.018
0.022
0.027
0.033
0.039
0.047
0.056
0.068
0.082
0.10
0.12
0.15
0.15
0.18
0.22
0.22
0.27
0.33
310
0.33
0.39
0.47
0.47
0.56
0.68
0.68
0.82
1.0
1.0
1.2
1.5
1.5
1.8
2.2
2.2
0.010
0.015
0.022
0.033
0.047
0.068
0.10
Revision: 16-Aug-17
15
15
15
15
15
15
15
15
15
15
15
15
15
15
15
22.5
22.5
15
22.5
22.5
15
22.5
27.5
22.5
27.5
27.5
22.5
27.5
27.5
22.5
27.5
37.5
27.5
37.5
37.5
27.5
37.5
15
15
15
15
15
15
15
5.0 x 11.0 x 17.5
5.0 x 11.0 x 17.5
5.0 x 11.0 x 17.5
5.0 x 11.0 x 17.5
5.0 x 11.0 x 17.5
5.0 x 11.0 x 17.5
5.0 x 11.0 x 17.5
6.0 x 12.0 x 17.5
6.0 x 12.0 x 17.5
6.0 x 12.0 x 17.5
7.0 x 13.5 x 17.5
8.5 x 15.0 x 17.5
8.5 x 15.0 x 17.5
8.5 x 15.0 x 17.5
8.5 x 15.0 x 17.5
7.0 x 16.5 x 26.0
7.0 x 16.5 x 26.0
10.0 x 16.5 x 17.5
8.5 x 16.5 x 26.5
10.0 x 19.5 x 26.0
13.5 x 22.5 x 18.0
10.0 x 19.5 x 26.0
11.0 x 21.0 x 31.0
12.0 x 22.0 x 26.0
11.0 x 21.0 x 31.0
11.0 x 21.0 x 31.0
15.5 x 26.5 x 26.5
13.0 x 23.0 x 31.0
13.0 x 23.0 x 31.0
15.5 x 26.5 x 26.5
15.0 x 25.0 x 31.5
14.5 x 24.5 x 41.5
18.0 x 28.0 x 31.0
15.5 x 28.5 x 41.5
15.5 x 28.5 x 41.5
21.0 x 31.0 x 31.0
18.0 x 32.5 x 41.5
5.0 x 11.0 x 17.5
5.0 x 11.0 x 17.5
5.0 x 11.0 x 17.5
5.0 x 11.0 x 17.5
5.0 x 11.0 x 17.5
6.0 x 12.0 x 17.5
6.0 x 12.0 x 17.5
1.4
1.4
1.4
1.4
1.4
1.4
1.4
2.0
2.0
2.0
2.4
2.7
2.7
2.7
2.7
4.1
4.1
3.0
4.6
6.7
5.5
6.7
9.1
13.0
9.1
9.1
13.5
12.9
12.9
13.5
15.0
18.9
19.0
24.0
24.0
28.0
31.6
1.4
1.4
1.4
1.4
1.4
2.0
2.0
750
750
750
750
750
750
750
500
500
500
450
300
325
300
300
235
235
235
200
170
185
170
125
110
125
125
110
110
110
110
100
80
85
70
70
70
60
750
750
750
750
750
600
600
d
t
= 0.80 mm ± 0.08 mm; C-TOL. = ± 10 %
d
t
= 0.60 mm ± 0.06 mm; C-TOL. = ± 20 %
Document Number: 28161
3
For technical questions, contact:
rfi@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
F1772 X2
www.vishay.com
Vishay Roederstein
ORDERING CODE
BULK
LEAD LENGTH
6 mm - 1 mm
(1)(2)
F17724152260
F17724152200
F17724222260
F17724222200
F17724332260
F17724332200
F17724472260
F17724472200
F17724682260
F17724682200
F17725102260
F17725102200
F17725152260
F17725152200
F17725222260
F17725222200
ELECTRICAL DATA AND ORDERING INFORMATION
U
RAC
(V)
CAP.
(μF)
PITCH
(mm)
DIMENSIONS
(4)
wxhxl
MAX. (mm)
MASS
(3)
(g)
SPQ
(pieces)
SHORT LEAD
d
t
= 0.80 mm ± 0.08 mm; C-TOL. = ± 20 %
0.15
0.15
0.22
0.22
0.33
0.33
0.47
310
0.47
0.68
0.68
1.0
1.0
1.5
1.5
2.2
2.2
15
22.5
15
22.5
15
22.5
22.5
27.5
22.5
27.5
22.5
27.5
27.5
37.5
27.5
37.5
8.5 x 15.0 x 17.5
6.0 x 15.5 x 26.0
10.0 x 16.5 x 17.5
7.0 x 16.5 x 26.0
13.5 x 22.5 x 18.0
8.5 x 18.0 x 26.0
10.0 x 19.5 x 26.0
9.0 x 19.0 x 31.5
12.0 x 22.0 x 26.0
11.0 x 21.0 x 31.0
15.5 x 26.5 x 26.5
15.0 x 25.0 x 31.5
18.0 x 28.0 x 31.5
14.5 x 24.5 x 41.5
21.0 x 31.0 x 31.0
15.5 x 28.5 x 41.5
2.7
3.3
4.5
4.1
5.5
5.3
6.7
6.8
13.4
12.9
13.5
15.0
19.0
18.9
28.0
24.0
325
260
300
235
185
190
170
160
110
125
110
100
85
80
70
70
Notes
• SPQ = Standard Packing Quantity
• For detailed tape specifications refer to packaging information:
www.vishay.com/doc?28139
(1)
For further packaging see table “Composition of Catalog Number”
(2)
Further information about packaging quantities with different lead length and / or taped versions, see document “Packing Quantities”
www.vishay.com/doc?27608
(3)
Weight for short lead product only
(4)
For tolerances see chapter “Space Requirements for Printed-Circuit Board Applications and Dimension Tolerances”
APPROVALS
SAFETY APPROVALS X2
EN 60384-14 (ENEC)
(= IEC 60384-14 ed-4)
UL 60384-14
CSA-E 384-14
CB test-certificate
VOLTAGE
310 V
AC
310 V
AC
310 V
AC
310 V
AC
VALUE
0.01 μF to 2.2 μF X2
0.01 μF to 2.2 μF X2
0.01 μF to 2.2 μF X2
0.01 μF to 2.2 μF X2
FILE NUMBERS
40005079
E354331
E354331
DE1-58410
LINK
www.vishay.com/doc?28196
www.vishay.com/doc?28191
www.vishay.com/doc?28226
The ENEC-approval together with the CB-certificate replace all national marks of the following countries (they have already signed the
ENEC-agreement): Austria; Belgium; Czech. Republic; Denmark; Finland; France; Germany; Greece; Hungary; Ireland; Italy; Luxembourg;
Netherlands; Norway; Portugal; Slovenian; Spain; Sweden; Switzerland and United Kingdom.
Revision: 16-Aug-17
Document Number: 28161
4
For technical questions, contact:
rfi@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
F1772 X2
www.vishay.com
MOUNTING
Normal Use
The capacitors are designed for mounting on printed-circuit boards. The capacitors packed in bandoliers are designed for
mounting in printed-circuit boards by means of automatic insertion machines.
For detailed tape specifications refer to packaging information:
www.vishay.com/doc?28139.
Specific Method of Mounting to Withstand Vibration and Shock
In order to withstand vibration and shock tests, it must be ensured that stand-off pips are in good contact with the printed-circuit
board:
• For pitches
15 mm capacitors shall be mechanically fixed by the leads
• For larger pitches the capacitors shall be mounted in the same way and the body clamped
Vishay Roederstein
SPACE REQUIREMENTS FOR PRINTED-CIRCUIT BOARD APPLICATIONS AND DIMENSION
TOLERANCES
For the maximum product dimensions and maximum space requirements for length (l
max.
), width (w
max.
) and height (h
max.
)
following tolerances must be taken in account in the envelopment of the components as shown in the drawings below.
• For products with pitch
15 mm, w =
l
= 0.3 mm, and
h
= 0.1 mm
• For products with 15 mm < pitch
27.5 mm,
w
=
l
= 0.5 mm, and
h
= 0.1 mm
• For products with pitch = 37.5 mm, w =
l
= 0.7 mm, and
h
= 0.5 mm
Eccentricity defined as in drawing. The maximum eccentricity is smaller than or equal to the lead diameter of the product
concerned.
w
max.
= w +
Δw
Eccentricity
I
max.
= I +
ΔI
CBA116
h
max.
= h +
Δh
Seating plane
For the minimum product dimensions for length (l
min.
), width (w
min.
) and height (h
min.
) following tolerances of the components
are valid:
l
min.
= l -
l,
w
min.
= w -
w,
and h
min.
= h -
h
following
• For products with pitch
10 mm,
l
= 0.3 mm, and
w
=
h
= 0.3 mm
• For products with pitch = 15 mm,
l
= 0.5 mm, and
w
=
h
= 0.5 mm
• For products with 15 mm < pitch
27.5 mm,
l
= 1.0 mm and
w
=
h
= 0.5 mm
• For products with pitch = 37.5 mm, l = 1.0 mm and
w
=
h
= 1.0 mm
SOLDERING CONDITIONS
For general soldering conditions and wave soldering profile, we refer to the application note: “Soldering Guidelines for Film
Capacitors”:
www.vishay.com/doc?28171
Storage Temperature
T
stg
= -25 °C to +35 °C with RH maximum 75 % without condensation
Ratings and Characteristics Reference Conditions
Unless otherwise specified, all electrical values apply to an ambient temperature of 23 °C ± 1 °C, an atmospheric pressure of
86 kPa to 106 kPa and a relative humidity of 50 % ± 2 %.
For reference testing, a conditioning period shall be applied over 96 h ± 4 h by heating the products in a circulating air oven at
the rated temperature and a relative humidity not exceeding 20 %.
Revision: 16-Aug-17
Document Number: 28161
5
For technical questions, contact:
rfi@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
京公网安备 11010802033920号
EEWORLD
