Axial Power Inductor
AIAP-03
•
Low cost axial leaded inductors
•
High current rating
•
Wide inductance range
•
Covered with UL heat shrink tubing
ELECTRICAL SPECIFICATIONS:
Part No.
AIAP-03-3R9
AIAP-03-4R7
AIAP-03-5R6
AIAP-03-6R8
AIAP-03-8R2
AIAP-03-100
AIAP-03-120
AIAP-03-150
AIAP-03-180
AIAP-03-220
AIAP-03-270
AIAP-03-330
AIAP-03-390
AIAP-03-470
AIAP-03-560
AIAP-03-680
AIAP-03-820
AIAP-03-101
AIAP-03-121
AIAP-03-151
AIAP-03-181
AIAP-03-221
AIAP-03-271
AIAP-03-331
AIAP-03-391
AIAP-03-471
AIAP-03-561
AIAP-03-681
AIAP-03-821
AIAP-03-102
AIAP-03-122
AIAP-03-152
AIAP-03-
182
AIAP-03-
222
AIAP-03-
272
AIAP-03-
332
AIAP-03-
392
AIAP-03-
472
AIAP-03-
562
AIAP-03-
682
AIAP-03-
822
AIAP-03-
103
AIAP-03-
123
AIAP-03-
153
L(µH)
3.9
4.7
5.6
6.8
8.2
10
12
15
18
22
27
33
39
47
56
68
82
100
120
150
180
220
270
330
390
470
560
680
820
1000
1200
1500
1800
2200
2700
3300
3900
4700
5600
6800
8200
10000
12000
15000
Pb
RoHS/RoHS II Compliant
APPLICATIONS:
22.9 x ϕ11.4mm
FEATURES:
•
Power supplies
•
Switching circuits
•
TV and audio equipment
•
Telecommunication devices
•
RF and other filters
Tolerance
(%)
K
K
K
K
K
K
K
K
K
K
K
K
K
K
K
K
K
K
K
K
K
K
K
K
K
K
K
K
K
K
K
K
K
K
K
K
K
K
K
K
K
K
K
K
DCR(Ω)
(max)
0.007
0.008
0.011
0.013
0.017
0.019
0.020
0.022
0.023
0.026
0.027
0.032
0.033
0.035
0.037
0.047
0.060
0.090
0.113
0.129
0.150
0.162
0.208
0.212
0.281
0.380
0.420
0.548
0.655
0.844
1.04
1.18
1.56
2.00
2.06
2.63
2.75
3.19
3.92
5.69
6.32
7.30
10.0
11.2
I
DC
(A)
(max)
15.50
13.90
12.60
11.60
9.89
8.70
8.21
7.34
6.64
6.07
5.36
4.83
4.36
3.98
3.66
3.31
3.10
2.79
2.54
2.22
1.98
1.89
1.63
1.51
1.39
1.24
1.17
1.050
0.970
0.870
0.790
0.700
0.640
0.580
0.530
0.470
0.430
0.390
0.359
0.322
0.293
0.266
0.257
0.230
ABRACON IS
ISO
ISO 9001:2008
9001 / QS 9000
CERTIFIED
30332
Esperanza, Rancho Santa Margarita, California
92688
Visit
www.abracon.com
for Terms & Conditions of Sale
Revised: 04.15.16
tel 949-546-8000
|
fax 949-546-8001
| www.abracon.com
Axial Power Inductor
AIAP-03
Part No.
AIAP-03-183
AIAP-03-223
AIAP-03-273
AIAP-03-333
AIAP-03-393
AIAP-03-473
AIAP-03-563
AIAP-03-683
AIAP-03-823
AIAP-03-104
AIAP-03-124
L(µH)
18000
22000
27000
33000
39000
47000
56000
68000
82000
100000
120000
(%)
K
K
K
K
K
K
K
K
K
K
K
Pb
RoHS/RoHS II Compliant
Tolerance
DCR(Ω)
(max)
15.2
16.8
18.6
26.7
29.0
31.8
42.6
46.9
64.9
71.7
37.0
I
DC
(A)
(max)
0.210
0.190
0.171
0.155
0.143
0.131
0.119
0.108
0.099
0.098
0.070
22.9 x ϕ11.4mm
Test Conditions and equipments
Test frequency: 1kHz 0.1Vrms
I
DC
: 10% inductance drops typical
Operating Temperature
-55
o
C ~ +125
o
C
Storage Temperature
-40
o
C ~ +105
o
C
PART NUMBER IDENTIFICATION
AIAP-03-
Inductance Code
Please refer to the
table above
Tolerance
K: ±10%
Packing (500pcs / bag)
OUTLINE DRAWING:
Heat shrink tube UL VW-1
Dimension: inch/mm
ATTENTION:
Abracon Corporation’s products are COTS – Commercial-Off-The-Shelf products; suitable for Commercial, Industrial and, where designated, Automotive Applications.
Abracon’s products are not specifically designed for Military, Aviation, Aerospace, Life-dependant Medical applications or any application requiring high reliability where component
failure could result in loss of life and/or property. For applications requiring high reliability and/or presenting an extreme operating environment, written consent and authorization from
Abracon Corporation is required. Please contact Abracon Corporation for more information.
ABRACON IS
ISO
ISO 9001:2008
9001 / QS 9000
CERTIFIED
30332
Esperanza, Rancho Santa Margarita, California
92688
Visit
www.abracon.com
for Terms & Conditions of Sale
Revised: 04.15.16
tel 949-546-8000
|
fax 949-546-8001
| www.abracon.com
