ALUMINUM ELECTROLYTIC CAPACITORS
UZR
Specifications
Item
Category Temperature Range
Rated Voltage Range
3.95mmL MAX. Chip Type
Chip type with 3.95mmLMAX height.
Designed for surface mounting on high density PC board.
Applicable to automatic mounting machine fed with carrier tape.
Compliant to the RoHS directive (2011/65/EU).
UZS
Smaller
UZR
Performance Characteristics
–40 to +85°C
4 to 50V
1 to 220µF
± 20% at 120Hz, 20°C
After 2 minutes' application of rated voltage at 20°C, leakage current is not more than 0.01 CV or 3 (µA) , whichever is greater.
Rated voltage (V)
tan
δ
( MAX.)
Rated voltage (V)
Impedance ratio Z–25°C / Z+20°C
ZT / Z20 (MAX.) Z–40°C / Z+20°C
4
0.50
4
7
15
6.3
0.30
6.3
4
8
10
0.24
10
3
8
16
0.19
16
2
4
25
0.16
25
2
4
35
0.14
35
2
3
50
0.14
50
2
3
Rated Capacitance Range
Capacitance Tolerance
Leakage Current
Tangent of loss angle (tan
δ)
Stability at Low
Temperature
120Hz 20°C
120Hz
Endurance
The specifications listed at right shall be met when the
capacitors are restored to 20°C after the rated voltage is
applied for 1000 hours at 85°C.
Capacitance change
tan
δ
Leakage current
Within ± 30% of the initial capacitance value
300% or less than the initial specified value
Less than or equal to the initial specified value
Shelf Life
Resistance to
soldering heat
Marking
After storing the capacitors under no load at 85°C for 1000 hours and then performing voltage treatment based on JIS C 5101-4 clause
4.1 at 20°C, they shall meet the specified values for the endurance characteristics listed above.
The capacitors are kept on a hot plate for 30 seconds, which is maintained at
250°C. The capacitors shall meet the characteristic requirements listed at right
when they are removed from the plate and restored to 20°C.
Black print on the case top.
Capacitance change
tan
δ
Leakage current
Within ±10% of the initial capacitance value
Less than or equal to the initial specified value
Less than or equal to the initial specified value
Chip Type
0.5 MAX.
Voltage (C : 16V)
Lot No.
Series
Plastic platform
0.3 MAX.
C±0.2
Positive
Type numbering system (Example : 16V 10
µ
F)
1
2
3
4
5
6
7
8
9 10 11 12 13 14
U Z R 1 C 1 0 0 MC L 1 GB
A±0.3
E
A±0.3
Taping code
A2
10C
ZR
Capacitance
3.90
+0.05
–0.2
0.5 to 0.8
Negative
Voltage
V
Code
4
g
6.3
j
10
A
16
C
25
E
35
V
50
H
φD
A
B
C
E
4
1.8
4.3
4.3
1.0
5
2.1
5.3
5.3
1.3
(mm)
6.3
2.4
6.6
6.6
2.2
φD±0.5
B±0.2
Configuration
Capacitance tolerance (±20%)
Rated capacitance (10µF)
Rated voltage (16V)
Series name
Type
Dimensions
V
Cap. (μF)
Code
4
0G
6.3
0J
10
1A
16
1C
25
1E
35
1V
1
2.2
3.3
4.7
10
22
33
47
100
220
010
2R2
3R3
4R7
100
220
330
470
101
221
4
4
5
6.3
28
33
56
96
4
5
5
6.3
28
37
45
70
5
5
6.3
33
41
52
4
5
6.3
6.3
23
37
49
58
4
5
6.3
6.3
16
27
42
52
4
5
6.3
18
29
46
50
1H
8.4
4
13
4
17
4
20
5
33
6.3
Case size
φ
D (mm)
Rated
ripple
Rated ripple current (mArms) at 85°C 120Hz
Frequency coefficient of rated ripple current
Frequency
Coefficient
50 Hz
0.70
120 Hz
1.00
300 Hz
1.17
1 kHz
1.36
10 kHz or more
1.50
Taping specifications are given in page 23.
Recommended land size soldering by reflow are given
in page 18,19.
Please refer to page 3 for the minimum order quantity.
