— Subminiature Connectors for coaxial cables —
For
Oct.1.2018 Copyright 2018 HIROSE ELECTRIC CO., LTD. All Rights Reserved.
Antenna
PO5G
<
In-line and board mounted.
>
GT7
GT3
GT32
GT17
GT11
GT36
GT26
GT21
GT19
Features
Space-saving design
Compact and light comparing to HRS GT5 series.
Excellent high frequency performance
Refer to V.S.W.R. data on the following pages.
GT18W
GT10
Applications
In-car communication, car sensors(temperature, pressure), automotive audio systems, GPS antenna
systems, RACS antenna audio/video antenna systems, CRT displays, medical and measuring
instrumentation LAN systems.
GT15
GT9
GT8E
GT25
48
In cases where the application will demand a high level of reliability, such as automotive,
please contact a company representative for further information.
GT16 Series
●
For Antenna
GT5
GT16 Series
F Connectors (Common Use)
Center terminal
7.6
0.8
4
GT13
GT16
PO5G
φ1.28
For Antenna
0.2
GT19
Oct.1.2018 Copyright 2018 HIROSE ELECTRIC CO., LTD. All Rights Reserved.
Part No.
GT16-2428SCF
GT16-30SCF
HRS No.
766-0001-2
766-0055-1
Material/Plating
Phosphor bronze/
Tin plating
Conductor Size
24 to 28 AWG
30 AWG
Packaging
10,000 pcs/reel
RoHS
YES
GT21
GT26
Insulator (Common Use)
GT36
GT11
φ4.4
φ3.8
φ3.2
φ3.4
GT17
＊
GT32
Part No.
GT16-SC
HRS No.
766-0002-5
Material
PBT
Color
White
Packaging
1
RoHS
YES
GT3
GT7
M Connectors (Common Use)
GT10
Center Terminals
9.25
0.8
4
GT18W
GT25
φ1.28
φ0.72
0.2
GT8E
GT9
Part No.
GT16-2428PCF
GT16-30PCF
HRS No.
766-0006-6
766-0015-7
Material/Plating
Brass/Tin plating
Conductor Size
24 to 28 AWG
30 AWG
Packaging
10,000 pcs/reel
RoHS
YES
49
GT15
GT16 Series
●
For Antenna
GT5
Insulator (Common Use)
GT13
GT16
6.3
4.1
φ3.8
For
Oct.1.2018 Copyright 2018 HIROSE ELECTRIC CO., LTD. All Rights Reserved.
Antenna
GT21
GT19
PO5G
Part No.
GT16-PC
HRS No.
766-0007-9
Material
PBT
Color
White
Packaging
1
RoHS
YES
GT26
Without retainer type (F Connector)
Housing
GT11
GT36
ＰＢＴ
＊
GT32
GT17
Part No.
GT16F-1S-HU(A)
GT16F-1S-HU(B)
HRS No.
766-0082-4
766-0083-7
Material
PBT
Color
Brown
Green
Packaging
1
RoHS
YES
GT7
GT3
GT10
Outer terminal
15.7
GT18W
7.2
GT8E
GT25
Part No.
GT16-/1.6-2.9SC
GT16-/0.7-1.5SC
HRS No.
766-0003-8
766-0056-4
Material/Plating
Phosphor bronze/
Tin plating
Insulator Diameter Outer Diameter
Ø
1.5 to 2.0
Ø
2.6 to 3.4
Ø
0.6 to 0.9
Ø
1.4 to 1.8
φ5
GT9
Packaging
1
RoHS
YES
GT15
50
φ2.8
＊
GT16 Series
●
For Antenna
GT5
Without retainer type (M Connector)
Housing
B
Mated condition
25.1
9.1
10
4.05
ＰＢＴ
Ａ
ＧＴ１６Ｆ−１Ｐ−ＨＵ（Ａ）
GT13
GT16
GT16F-1S-HU(A)
(31.4)
ＰＢＴ
Ａ
ＧＴ１６Ｆ−１Ｐ−ＨＵ（Ａ）
(6.3)
PO5G
GT19
For Antenna
Oct.1.2018 Copyright 2018 HIROSE ELECTRIC CO., LTD. All Rights Reserved.
Part No.
GT16F-1P-HU(A)
GT16F-1P-HU(B)
HRS No.
766-0086-5
766-0087-8
Material
PBT
Color
Brown
Green
Packaging
1
RoHS
GT21
YES
GT26
Outer terminals
GT36
GT11
GT17
Part No.
GT16C-/1.6-2.9PC
GT16C-/0.7-1.5PC
HRS No.
766-0019-8
766-0018-5
Material
Phosphor
bronze
Plating
Tin plating
Insulator Diameter Outer Diameter
Ø
1.5 to 2.0
Ø
2.6 to 3.4
Ø
0.6 to 0.9
Ø
1.4 to 1.8
Packaging
1
RoHS
YES
GT32
●
Printed
Circuit Board Type
（SMT Type）
Vacuum pick up area
ＧＴ１６Ｆ−１Ｐ−Ｈ（Ａ）
9.8
3.95
9.3
B
Recommended PCB pattern
1.2
2.8
6.3
7
GT3
14.5
Ø8
13.1
16
3
GT7
10
5
B
Mated condition
(23)
(6.3)
4.1
1.2
0.7
16.7
GT10
GT18W
3.8
ＧＴ１６Ｆ−１Ｐ−Ｈ（Ａ）
GT25
GT16F-1S-HU(A)
Part No.
HRS No.
Material/Plating
Housing：PPS
Inner Terminal：Phosphor bronze/Tin plating
Outer Terminal：Phosphor bronze/Tin plating
Insulator：PPS/Natural
Shield plate：Phosphor bronze/Tin plating
Metal reinforcement：Brass/Tin plating
Color
Brown
1
Green
YES
Packaging RoHS
GT8E
GT16F-1P-H(A) 766-0078-7
GT16F-1P-H(B) 766-0079-0
51
GT9
GT15
GT16 Series
●
For Antenna
GT5
Genuine Market Parts F Connectors
Housing (Retainer Stopper Specification)
GT16
GT13
7.5
17.5
For
Oct.1.2018 Copyright 2018 HIROSE ELECTRIC CO., LTD. All Rights Reserved.
Antenna
PO5G
GT19
11.6
10.1
GT21
GT26
Part No.
GT16C-1S-HU
GT16C-1S-HU(A)
GT16C-1S-HU(B)
HRS No.
766-0010-3
766-0060-1
766-0061-4
Material
PBT
Color
Light Gray
Brown
Green
Packaging
1
RoHS
YES
Note :
This product is used in conjunction with retainer GT16C-1P/S-R (CL766-0011-6) which is a separate item.
GT11
GT36
Outer terminal (Retainer Stopper Specification)
GT17
15.7
7.2
GT32
GT7
GT3
Part No.
GT16C-/1.6-2.9SC
GT16C-/0.7-1.5SC
HRS No.
766-0012-9
766-0057-7
Material/Plating
Phosphor bronze/
Tin plating
Insulator Diameter Outer Diameter
Ø
1.5 to 2.0
Ø
2.6 to 3.4
Ø
0.6 to 0.9
Ø
1.4 to 1.8
φ5
Packaging
1
RoHS
YES
GT10
Retainer
GT18W
R2.6
GT25
1.25
2.15
11.2
GT16C−1S−HU
＊
GT8E
GT9
GT15
Part No.
GT16C-1P/S-R
HRS No.
766-0011-6
Material
PBT
Color
Dark Gray
Packaging
1
RoHS
YES
52
