Current transformer - PACT MCR-V2-6040- 96-1000-5A-1 - 2277705
Please be informed that the data shown in this PDF Document is generated from our Online Catalog. Please find the complete data in the user's
documentation. Our General Terms of Use for Downloads are valid
(http://phoenixcontact.com/download)
Window-type current transformer, 1000 A AC primary current; 5 A AC secondary current; accuracy class 1; 10
VA rated power
Why buy this product
Primary rated current Ipn: 0 ... (200 ... 2000) A
Rail dimensions: 60 x 40 mm; 50 x 50 mm
Circular conductor dimensions: Ø 61 mm
Key Commercial Data
Packing unit
GTIN
GTIN
Custom tariff number
4046356460170
85043129
1 STK
Technical data
Dimensions
Primary round conductor (diameter)
Primary round conductor (width)
Primary round conductor (height)
Primary round conductor (width)
Primary round conductor (height)
Width
Height
Depth
Width with alternative assembly
Height with alternative assembly
Depth with alternative assembly
61 mm
60 mm
40 mm
50 mm
50 mm
30 mm
121 mm
96 mm
96 mm
121 mm
30 mm
Ambient conditions
11/15/2016 Page 1 / 3
https://www.phoenixcontact.com/hq/products/2277705
Current transformer - PACT MCR-V2-6040- 96-1000-5A-1 - 2277705
Technical data
Ambient conditions
Ambient temperature (operation)
Ambient temperature (storage/transport)
-25 °C ... 40 °C
-25 °C ... 40 °C
Input data
Thermal rated short-time current
Thermal rated continuous current
Rated surge current
Rated frequency: Standard converter
Rated frequency: Calibrated converter
Surge current limitation factor
Rated power
Primary rated current I
pn
Secondary rated current I
sn
I
th
= 60 * I
n
I
d
= 1.2 * I
n
I
dyn
= 2.5 * I
th
50 Hz ... 60 Hz
50 Hz
FS 5
10 VA
0 A ... 1000 A
5 A AC
General
Converter type
Accuracy class
Can be calibrated
Rated insulation voltage
Standards/regulations
Color
Housing material
Plug-on converters
1
no
1 kV (Phase/neutral conductor)
EN 50178
EN 61869
black
WELLAMID 6600-PA66-GV 20 HWV0CP
Standards and Regulations
Standards/regulations
EN 50178
EN 61869
Environmental Product Compliance
China RoHS
Environmentally Friendly Use Period = 50
For details about hazardous substances go to tab “Downloads”,
Category “Manufacturer's declaration”
Drawings
11/15/2016 Page 2 / 3
https://www.phoenixcontact.com/hq/products/2277705
Current transformer - PACT MCR-V2-6040- 96-1000-5A-1 - 2277705
Dimensional drawing
96
30
16
54x54
44x64
105
Approvals
Approvals
Approvals
EAC
Ex Approvals
Approval details
EAC EAC-Zulassung
Phoenix Contact 2016 © - all rights reserved
http://www.phoenixcontact.com
61
