TECHNICAL CHARACTERISTICS
7,8
ø 2x 0,7
3
4
C
5
6
5x
O
1,5
(4) (5) (6)
L1
L2
5,0
(1) (2) (3)
(1) (2) (3)
2
1
C
8
7
ø 1,7
7
8
6
C
4
3
L1
L2
(4) (5) (6)
C
1
2
5,0
10,0
5
Specification
Rotary switch/Push button switch
>Rating :100mA, 30VDC
>Contact Resistance :
Initial Rotary : 200mOhm max.
Initial Push button : 50mOhm max.
After Life Test Rotary : 1OHM max.
After Life Test Push button : 200mOhm max.
>Insulation Resistance : min. 100MΩ at 500VDC for 1 minute
>Dielectric Strength : 500VAC for 1 minute
Switch function
Rotary switch
switching degree : 45+/-2
̊
Switch schematic : 1P8T
Push button
Function : momentary
Pre- Travel :0.7±0.3mm
Total-Travel : 1.8±0.3mm
Bounce: 10ms max.
Material
>Cover : Stainless steel
>LED cover/Diffuser plate : PC UL HB
>Knob: PA66 UL HB
>Frame : PA66 UL HB
>Base : PA66 UL HB
>Stationary Board : PA66 UL HB
>Stationary Contact : Brass with Silver
>Moving Contact Push button : Bronze with Silver
>Moving Contact Rotary : Copper alloy with Silver
>Terminal : Brass with Silver
>LED Terminal : Brass with Tin
>Spring/Roller ball : Stainless Steel
Soldering Information
>Terminal in THT version
> Wave soldering 260°C 10sec. max
>Hand soldering under 350°C for 3sec. max
Environmental
Storage condition : -40°C ~ +85°C ,60% RH max.
Operation condition : -40°C ~ +85°C
Compliance : ROHS ,Reach
Handling advise
> ESD prevention methods need to be applicant for manual handling
and processing by machinery
> Resistors for protection are mandatory
Packaging information
>ESD tray
Part number
Force
Color of LED
Life cycle
Rotary
20.000
Life cycle
Push button
50.000
13,0
6,5
13,0
ø 16x 0,9
19,3
19,75
RECOMMENDED LAYOUT
2,0
14,45
0,6
4,9
0,2 x0,4
3,5
0,2 x0,5
(16x) 0,6 x0,3
7
LED SCHEMATIC
8
6
1
C
O
14,2
20,4
5
2
(non-shorting)
(shorting)
CIRCUIT DIAGRAM
Scale - 1,5:1
Projection
This electronic component is designed and developed with the intention for use
in general electronics equipments.
Before incorporating the components into any equipments in the field such as
aerospace, aviation, nuclear control, submarine, transportation, (automotive
control, train control, ship control), transportation signal, disaster prevention,
medical, public information network etc. where higher safety and reliability are
especially required or if there is possibility of direct damage or injury to human
body, Wurth Elektronik must be asked for a written approval.
In addition, even electronic component in general electronic equipments, when
used in electrical circuits that require high safety, reliability functions or
performance, the sufficient reliability evaluation-check for the safety must be
performed before by the user before usage.
a
REV
shorting, non-shorting
LED Terminal: Brass with Tin
15-01-20 DaF
DATE
BY
FILE
3
C
1
4
START
481 RV 121 72100 250gf ± 100gf Red/Bright green
GENERAL TOLERANCE
.x = +/- 0,2
.xx = +/- 0,15
Date
13-10-02
13-10-02
Name
Fandrey
Hsu
Basic material
DESCRIPTION
Drawn
Checked
SwRPTL
WS-RPTL 20x20 Rotary/Push button switch with Integrated LED,
THT Type
Scale
WE
eiCan
Würth Elektronik
eiCan
1,5:1
Position
SIZE
A4
CAD
Drawing.- No.
481 RV121 72100
System :Solid Edge ST4
Emitting color
Order code
item
1
Peak wavelength typ.
Dominant Wave length
@IF=20mA
spectral Line Half-width
@IF=20mA
Capacitance
VF=0V;f=1MHZ
Forward voltage
@IF=20mA
Reverse current
@VR=5V
ESD
Viewing Angle
@20mA 2θ 50% typ
Luminous intensity
@IF=20mA
Material
lens type
unit
nm
HANDLING ADVISE
Red
RS
650
bright green
VS
574
567
typ.nm
typ.nm
typ.pF
typ. V
max.V
uA
V
º
min. mcd
typ. mcd
630
28
35
1,95
2,5
10
2000
145
120
220
AIGaInP
water clear
20
15
2,1
2,5
10
2000
145
20
50
AIGaInP
water clear
1) The solder profile has to be complied with according to the technical
reflow /or wave soldering specification, otherwise no warranty will be
sustained
2) All products are supposed to be used before the end of the period of
12 months based on the product date-code, if not 100% solderability
can't be warranted
3) Violation of the technical product specifications such as exceeding
the absolute maximum ratings will be result in the loss of warranty
4) It's also recommended to return the products into the original
packaging
5) ESD prevention methods need to be applicated for manual handling
and processing by machinery
6) Resistors for protection are obligatory
7) The standard deliveries include values in the range and limitation as
defined in the Electrical & Optical Properties specified in the datasheet.
On each reel, only one bin is sorted and taped. The bin is defined on
intensity, chromaticity coordinate or wavelength and forward voltage.In
order to ensure highest availability, the reel binning of standard
deliveries can vary. A single bin cannot be ordered.Please contact us in
advance, if you need a particular bin sorting before placing your order
to clarify the lead time, MOQ and pricing.
2
3
4
5
6
7
8
9
10
11
Absolute Maximun Ratings (Ambient Temperature 25C )
Properties
Power Dissipation
Peak Forward current
continuous Forward current
Reverse voltage
ESD Threshold / HBM
Red
75
185
30
5
2000
bright green
75
150
30
5
2000
Unit
mW
mA
mA
V
V
Projection
This electronic component is designed and developed with the intention for use
in general electronics equipments.
Before incorporating the components into any equipments in the field such as
aerospace, aviation, nuclear control, submarine, transportation, (automotive
control, train control, ship control), transportation signal, disaster prevention,
medical, public information network etc. where higher safety and reliability are
especially required or if there is possibility of direct damage or injury to human
body, Wurth Elektronik must be asked for a written approval.
In addition, even electronic component in general electronic equipments, when
used in electrical circuits that require high safety, reliability functions or
performance, the sufficient reliability evaluation-check for the safety must be
performed before by the user before usage.
GENERAL TOLERANCE
.x = +/- 0,2
.xx = +/- 0,15
Date
13-10-02
13-10-02
Name
Fandrey
Hsu
Basic material
DESCRIPTION
Drawn
Checked
SwRPTL
WS-RPTL 20x20 Rotary/Push button switch with Integrated LED,
THT Type
Scale
WE
eiCan
Würth Elektronik
eiCan
1,5:1
Position
SIZE
A4
a
REV
shorting, non-shorting
LED Terminal: Brass with Tin
15-01-20 DaF
DATE
BY
CAD
Drawing.- No.
481 RV121 72100
System :Solid Edge ST4
FILE
