851-93-025-10-001000 datasheet, PDF

EEWORLDEEWORLD

Datasheet

Datasheet> All Categories > The connector> The connector> 851-93-025-10-001000

Preview

851-93-025-10-001000: DescriptionIC & Component Sockets 25P SINGLE ROW .161" PROFILE SOCKET; CategoryThe connector The connector; File Size374KB，1 Pages; ManufacturerMill-Max; Websitehttps://www.mill-max.com

Download Datasheet Parametric View All

851-93-025-10-001000 Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	851-93-025-10-001000	-	-	View	Buy Now

851-93-025-10-001000 Overview

IC & Component Sockets 25P SINGLE ROW .161" PROFILE SOCKET

851-93-025-10-001000 Parametric

Parameter Name	Attribute value
Is it lead-free?	Contains lead
Is it Rohs certified?	incompatible
Maker	Mill-Max
Reach Compliance Code	unknown
body width	0.087 inch
subject depth	0.161 inch
body length	1.265 inch
Body/casing type	SOCKET
Connector type	BOARD CONNECTOR
Contact to complete cooperation	GOLD (30) OVER NICKEL (100)
Contact completed and terminated	Tin/Lead (Sn/Pb) - with Nickel (Ni) barrier
Contact point gender	FEMALE
Contact material	NOT SPECIFIED
contact mode	RECTANGULAR
DIN compliance	NO
Filter function	NO
IEC compliance	NO
JESD-609 code	e0
MIL compliance	NO
Manufacturer's serial number	851
Plug contact pitch	0.05 inch
Plug information	MULTIPLE MATING PARTS AVAILABLE
Mixed contacts	NO
Installation option 1	LOCKING
Installation method	STRAIGHT
Installation type	BOARD
Number of connectors	ONE
PCB row number	1
Number of rows loaded	1
Options	GENERAL PURPOSE
Plating thickness	30u inch
Rated current (signal)	3 A
reliability	COMMERCIAL
Terminal length	0.099 inch
Terminal pitch	1.27 mm
Termination type	SOLDER
Total number of contacts	25
Base Number Matches	1

Preview

Download Datasheet

View All

INTERCONNECTS

SERIES 850, 851, 852, 853 • .050” GRID HEADERS AND SOCKETS •

SINGLE AND DOUBLE ROW STRIPS

(Number of Pins

X .050”) + .015”

.118

.087

.016 DIA.

.114

.087

.016 DIA.

•

Series 850, 851, 852, 853 single and double

row interconnects have .050” pin spacing and

permit board stacking as low as .248”

See page 208 for details

•

Pin headers have .016” dia. pins (MM #4006-0)

•

MM #0467 and MM #4890 receptacles use

.050

FIG. 1

.120

.016 DIA.

Hi-Rel, 3- nger BeCu #11 contact rated at

3 amps. ( #11 contact accepts pin diameters

from .015”-.020” ). See pages 158 and 160 for

details

suitable for all soldering operations

(Number of Pins

X .050”/2) + .015”

.118

.075 .083

•

Insulators are high temperature thermoplastic,

ORDERING INFORMATION

Series 850...001

.016 DIA.

.118

FIG. 1

.050

Single Row .087” Pro le Pin Header

850 XX 0_ _ 10 001000

01-50

FIG. 2

.087

Specify number of pins

Series 852...001

(Number of Pins

X .050”) + .015”

FIG. 2

RoHS - 2

Double Row .083” Pro le Pin Header

852 XX _ _ _ 10 001000

004-100

For

Electrical, Mechanical

& Enviromental Data,

See page 264

.120

.075

.161

Specify number of pins

XX=Plating Code

See Below

10

µ”

Au

.018 DIA.

.099

2011/65/EU

.050

SPECIFY PLATING CODE XX=

Pin Plating

90

200

µ”

Sn/Pb

40

200

µ”

Sn

FIG. 3

.120

(Number of Pins

X .050”/2) + .015”

Series 851...001

.120

.075

.158

FIG. 3

Series 853...001

Single Row .161” Pro le Socket

851 XX 0_ _ 10 001000

01-50

Specify number of pins

.018 DIA.

.102

FIG. 4

.050

Double Row .161” Pro le Socket

853 XX _ _ _ 10 001000

004-100

Specify number of pins

FIG. 4

PAGE 34 | INTERCONNECTS

.070

Series 851...002

(Number of Pins

X .050”) + .040”

FIG. 5

RoHS - 2

Single Row .185” Pro le Socket

851 XX 0_ _ 10 002000

01-77

For

Electrical, Mechanical

& Enviromental Data,

See page 264

.075

.150

.185

Specify number of pins

XX=Plating Code

See Below

91

10

µ”

Au

2011/65/EU

.018 DIA.

.115

.050

FIG. 5

SPECIFY PLATING CODE XX=

Sleeve (Pin)

Contact (Clip)

93

99

41

43

200

µ”

Sn

30

µ”

Au

47

200

µ”

Sn

Au Flash

200

µ”

Sn/Pb 200

µ”

Sn/Pb 200

µ”

Sn/Pb

200

µ”

Sn

30

µ”

Au

100

µ”

Sn/Pb

10

µ”

Au
