DF6A6.8FUT
Quad Array for
ESD Protection
This quad voltage suppressor is designed for applications requiring
transient overvoltage protection capability. It is intended for use in
voltage and ESD sensitive equipment such as computers, printers,
business machines, communication systems, medical equipment, and
other applications. Its quad junction common anode design protects
four separate lines using only one package. These devices are ideal for
situations where board space is at a premium.
Specification Features
http://onsemi.com
1
2
3
6
5
4
•
•
•
•
•
SC−88 Package Allows Four Separate Unidirectional Configurations
Low Leakage < 1
mA
@ 5 Volt
Breakdown Voltage: 6.4
−
7.2 Volt @ 5 mA
Low Capacitance (40 pF typical)
ESD Protection Meeting 61000−4−2 Level 4
and 16 kV Human Body Model
•
These are Pb−Free Devices
Mechanical Characteristics
MARKING
DIAGRAM
1
SC−88
CASE 419B−02
1
68 = Specific Device Code
M = Date Code
G
= Pb−Free Package
(Note: Microdot may be in either location.)
6
68 MG
G
•
•
•
•
Void Free, Transfer−Molded, Thermosetting Plastic Case
Corrosion Resistant Finish, Easily Solderable
Package Designed for Optimal Automated Board Assembly
Small Package Size for High Density Applications
MAXIMUM RATINGS
(T
A
= 25°C unless otherwise noted)
Rating
Peak Power Dissipation @ 8 x 20
ms
(Note 1)
Steady State Power Dissipation
(Note 2)
Thermal Resistance
−
Junction−to−Ambient
Derate Above 25°C
Maximum Junction Temperature
Operating Junction and Storage
Temperature Range
ESD Discharge
MIL STD 883C
−
Method 3015−6
IEC61000−4−2, Air Discharge
IEC61000−4−2, Contact Discharge
Lead Solder Temperature
(10 seconds duration)
Symbol
P
pk
P
D
R
qJA
Value
75
385
Unit
Watts
mW
ORDERING INFORMATION
Device
DF6A6.8FUT1G
Package
SC−88
(Pb−Free)
SC−88
(Pb−Free)
Shipping
†
3000/Tape & Reel
3000/Tape & Reel
328
3.0
150
−55
to
+150
16
16
8
260
°C/W
mW/°C
°C
°C
kV
DF6A6.8FUT2G
T
Jmax
T
J
, T
stg
V
PP
†For information on tape and reel specifications,
including part orientation and tape sizes, please
refer to our Tape and Reel Packaging Specifications
Brochure, BRD8011/D.
T
L
°C
Stresses exceeding Maximum Ratings may damage the device. Maximum
Ratings are stress ratings only. Functional operation above the Recommended
Operating Conditions is not implied. Extended exposure to stresses above the
Recommended Operating Conditions may affect device reliability.
1. Per Waveform Figure 1
2. Mounted on FR−5 Board = 1.0 X 0.75 X 0.062 in.
©
Semiconductor Components Industries, LLC, 2012
October, 2012
−
Rev. 2
1
Publication Order Number:
DF6A6.8FUT1/D
DF6A6.8FUT
PACKAGE DIMENSIONS
SC−88/SC70−6/SOT−363
CASE 419B−02
ISSUE W
D
e
NOTES:
1. DIMENSIONING AND TOLERANCING PER ANSI
Y14.5M, 1982.
2. CONTROLLING DIMENSION: INCH.
3. 419B−01 OBSOLETE, NEW STANDARD 419B−02.
4
6
5
H
E
1
2
3
−E−
b
6 PL
0.2 (0.008)
M
E
M
DIM
A
A1
A3
b
C
D
E
e
L
H
E
MILLIMETERS
MIN
NOM MAX
0.80
0.95
1.10
0.00
0.05
0.10
0.20 REF
0.10
0.21
0.30
0.10
0.14
0.25
1.80
2.00
2.20
1.15
1.25
1.35
0.65 BSC
0.10
0.20
0.30
2.00
2.10
2.20
INCHES
NOM MAX
0.037 0.043
0.002 0.004
0.008 REF
0.004 0.008 0.012
0.004 0.005 0.010
0.070 0.078 0.086
0.045 0.049 0.053
0.026 BSC
0.004 0.008 0.012
0.078 0.082 0.086
MIN
0.031
0.000
A3
A
C
A1
L
SOLDERING FOOTPRINT*
0.50
0.0197
0.65
0.025
0.65
0.025
0.40
0.0157
1.9
0.0748
SCALE 20:1
mm
inches
*For additional information on our Pb−Free strategy and soldering
details, please download the ON Semiconductor Soldering and
Mounting Techniques Reference Manual, SOLDERRM/D.
