DIO2524CT24

Description
Audio Amplifiers 2VRMS Differential Input Audio Driver with Integrated 4-ch SD VFD
Categorysemiconductor    Analog mixed-signal IC
File Size573KB,13 Pages
ManufacturerDIOO
Environmental Compliance
Download Datasheet Parametric View All

DIO2524CT24 Online Shopping

Suppliers Part Number Price MOQ In stock
DIO2524CT24 - - View Buy Now

DIO2524CT24 Overview

Audio Amplifiers 2VRMS Differential Input Audio Driver with Integrated 4-ch SD VFD

DIO2524CT24 Parametric

Parameter NameAttribute value
Product AttributeAttribute Value
ManufacturerDIOO
Product CategoryAudio Amplifiers
RoHSDetails
ProductAudio Line Drivers / Receivers
ClassOther
Output Power-
Mounting StyleSMD/SMT
Type4-Channel Line Driver
Package / CaseTSSOP-24
Audio - Load Impedance600 Ohms, 10 kOhms
THD plus Noise0.001 %
Supply Voltage - Max5.5 V
Supply Voltage - Min3 V
Minimum Operating Temperature- 40 C
Maximum Operating Temperature+ 85 C
PackagingReel
Input TypeDifferential
Gain6 dB
Number of Channels4 Channel
ShutdownShutdown
GBP - Gain Bandwidth Product-
Ib - Input Bias Current-
Moisture SensitiveYes
Operating Supply Current16 mA, 32 mA
SR - Slew Rate-
Factory Pack Quantity2500
Vos - Input Offset Voltage800 uV
Unit Weight0.006737 oz
Rev 1.1
DIO2524
2-Vrms Audio Driver with Integrated
4-ch, 11MHz, 6
th
-Order SD Video Filter
Features
Line Output: able to drive 600Ω and 10kΩ
2-Vrms With 3.3V Supply Voltage
No Pop/Clicks Noise at the line output
when Power ON/OFF
No Need for Output DC-Blocking
Capacitors
Accepting Differential Input
Optimized Frequency Response between
20Hz–20kHz
Video Filter: Four-ch 6 -order 11MHz SD
filters
6dB Output Driver Gain and Drive Dual Video
Load
Transparent Input Clamping
AC or DC Coupled Inputs
AC or DC Coupled Outputs
Operates from 3.135V to 5.5V Single Power
Supply
The Video filter is a low voltage, triple video
amplifier with integrated reconstruction filter and
input clamps. It provides improved image quality
compared with passive LC filters and discrete
drivers solution, especially suited for standard
definition video signals, such as television and
set-top box applications. All channels can be
directly driven by a DC-coupled or an AC-coupled
signal. Internal diode-like clamps and bias circuitry
may be used if AC-coupled inputs are required.
The output in the video filter can also drive AC or
DC coupled single (150Ω) or dual (75Ω) loads. The
DC coupling capacitors can be removed.
th
Descriptions
The DIO2524 is an integrated solution for Video
driver and Audio driver, with two separated
modules, the Audio Driver module and 4-ch
6 -order 11MHz, SD Video filter driver module.
The Audio Driver allow for the removal of output
AC-coupling capacitors. It is designed to optimize
the
audio
driver
discrete
circuit
performance
for
while
noise
reducing the BOM cost by eliminating the
peripheral
components
reduction. Featuring differential input mode, gain
range of ±1V/V to ±10V/V can be achieved via
external gain resistor setting.
th
Applications
DVD Players
Video Amplifiers
Set-Top Boxes
Personal Video Recorders
Communications Devices
Ordering Information
Order Part
Number
DIO2524CT24
Top Marking
DIO2524
Green/RoHS
T
A
-40 to +85°C
TSSOP-24
Package
Tape & Reel, 2500
www.dioo.com
© 2015 DIOO MICROCIRCUITS CO., LTD
DIO2524• Rev. 1.1
