UG2001 - UG2007
2.0A ULTRA-FAST GLASS PASSIVATED RECTIFIER
Features
•
•
•
•
•
Glass Passivated Die Construction
Ultra-Fast Switching for High Efficiency
Surge Overload Rating to 60A Peak
Low Reverse Leakage Current
Lead Free Finish, RoHS Compliant (Note 4)
Mechanical Data
•
•
•
•
•
•
•
•
•
Case: DO-15
Case Material: Molded Plastic. UL Flammability Classification
Rating 94V-0
Moisture Sensitivity: Level 1 per J-STD-020D
Terminals: Finish - Tin. Plated Leads Solderable per
MIL-STD-202, Method 208
Polarity: Cathode Band
Marking: Type Number
Ordering Information: See Page 3
Weight: 0.4 grams (approximate)
Maximum Ratings
@T
A
= 25°C unless otherwise specified
Single phase, half wave, 60Hz, resistive or inductive load.
For capacitance load, derate current by 20%.
Characteristic
Peak Repetitive Reverse Voltage
Working Peak Reverse Voltage
DC Blocking Voltage (Note 5)
RMS Reverse Voltage
Average Rectified Output Current @T
A
= 55°C (Note 1)
Non-Repetitive Peak Forward Surge Current
8.3ms Single half sine-wave Superimposed on Rated Load
Symbol
V
RRM
V
RWM
V
R
V
R(RMS)
I
O
I
FSM
UG2001 UG2002 UG2003 UG2004 UG2005 UG2006 UG2007 Unit
50
35
100
70
200
140
400
280
2.0
60
600
420
800
560
1000
700
V
V
A
A
Thermal Characteristics
Characteristic
Typical Thermal Resistance Junction to Ambient
Operating and Storage Temperature Range
Symbol
R
θ
JA
T
J,
T
STG
Value
50
-55 to +150
Unit
°C/W
°C
Electrical Characteristics
Characteristic
Forward Voltage
Peak Reverse Current
at Rated DC Blocking Voltage (Note 5)
Typical Total Capacitance (Note 2)
Reverse Recovery Time (Note 3)
Notes:
1.
2.
3.
4.
5.
@T
A
= 25°C unless otherwise specified
Symbol
V
F
I
R
C
T
t
rr
UG2001 UG2002 UG2003 UG2004 UG2005 UG2006 UG2007 Unit
1.0
1.3
1.7
V
5.0
μA
100
30
15
pF
50
75
ns
@ I
F
= 2.0A
@ T
A
= 25°C
@ T
A
= 100°C
Valid provided that leads are maintained at ambient temperature at a distance of 9.5mm from the case.
Measured at 1.0MHz and applied reverse voltage of 4.0V DC.
Measured with I
F
= 0.5A, I
R
= 1.0A, I
rr
= 0.25A. See figure 5.
EU Directive 2002/95/EC (RoHS). All applicable RoHS exemptions applied. Please visit our website at http://www.diodes.com/products/lead_free.html.
Short duration pulse test used to minimize self-heating effect.
UG2001 - UG2007
Document number: DS27009 Rev. 5 - 3
1 of 4
www.diodes.com
October 2010
© Diodes Incorporated
NOT RECOMMENDED
FOR NEW DESIGN
I
(O)
, AVERAGE FORWARD RECTIFIED CURRENT (A)
UG2001 - UG2007
I
F
, INSTANTANEOUS FORWARD CURRENT (A)
10
2.0
1.6
1.2
1.0
0.8
0.1
0.4
Single phase half-wave
60Hz resistive or inductive load
0
25
50
75
100
125
150
175
200
0.01
0.6
0.8
1.0
1.2
1.4
1.6
1.8
2.0
T
A
, AMBIENT TEMPERATURE (
°
C)
Fig. 1 Forward Current Derating Curve
60
I
FSM
, PEAK FORWARD SURGE CURRENT (A)
C
T
, TOTAL CAPACITANCE (pF)
100
V
F
, INSTANTANEOUS FORWARD VOLTAGE (V)
Fig. 2 Typical Forward Characteristics
40
UG2005
UG2001 -
UG2004
10
20
T
j
= 25
°
C
f = 1.0MHz
0
1
10
NUMBER OF CYCLES AT 60Hz
Fig. 3 Peak Forward Surge Current
100
1
1
10
V
R
, REVERSE VOLTAGE (V)
Fig. 4 Typical Total Capacitance
100
(+)
(-)
UG2001 - UG2007
Document number: DS27009 Rev. 5 - 3
2 of 4
www.diodes.com
October 2010
© Diodes Incorporated
NOT RECOMMENDED
FOR NEW DESIGN
UG2001 - UG2007
Ordering Information
Part Number
UG2001-T
UG2002-T
UG2003-T
UG2004-T
UG2005-T
UG2006-T
UG2007-T
Notes:
(Note 6)
Case
DO-15
DO-15
DO-15
DO-15
DO-15
DO-15
DO-15
Packaging
4K/Tape & Reel, 13-inch
4K/Tape & Reel, 13-inch
4K/Tape & Reel, 13-inch
4K/Tape & Reel, 13-inch
4K/Tape & Reel, 13-inch
4K/Tape & Reel, 13-inch
4K/Tape & Reel, 13-inch
6. For packaging details, go to our website at http://www.diodes.com/datasheets/ap02007.pdf.
Package Outline Dimensions
Dim
A
B
C
D
DO-15
Min
Max
25.40
⎯
5.50
7.62
0.686
0.889
2.60
3.60
All Dimensions in mm
UG2001 - UG2007
Document number: DS27009 Rev. 5 - 3
3 of 4
www.diodes.com
October 2010
© Diodes Incorporated
NOT RECOMMENDED
FOR NEW DESIGN
UG2001 - UG2007
