SI6926AEDQ-T1-GE3

Description
MOSFET 20V 4.5A 1.0W 30mohm @ 4.5V
CategoryDiscrete semiconductor    The transistor
File Size118KB,7 Pages
ManufacturerVishay
Websitehttp://www.vishay.com
Environmental Compliance
Download Datasheet Parametric View All

SI6926AEDQ-T1-GE3 Online Shopping

Suppliers Part Number Price MOQ In stock
SI6926AEDQ-T1-GE3 - - View Buy Now

SI6926AEDQ-T1-GE3 Overview

MOSFET 20V 4.5A 1.0W 30mohm @ 4.5V

SI6926AEDQ-T1-GE3 Parametric

Parameter NameAttribute value
Is it lead-free?Lead free
Is it Rohs certified?conform to
MakerVishay
Parts packaging codeTSSOP
package instructionSMALL OUTLINE, R-PDSO-G8
Contacts8
Reach Compliance Codeunknown
ECCN codeEAR99
ConfigurationSEPARATE, 2 ELEMENTS WITH BUILT-IN DIODE
Minimum drain-source breakdown voltage20 V
Maximum drain current (Abs) (ID)4.1 A
Maximum drain current (ID)4.1 A
Maximum drain-source on-resistance0.03 Ω
FET technologyMETAL-OXIDE SEMICONDUCTOR
JESD-30 codeR-PDSO-G8
JESD-609 codee3
Humidity sensitivity level1
Number of components2
Number of terminals8
Operating modeENHANCEMENT MODE
Maximum operating temperature150 °C
Package body materialPLASTIC/EPOXY
Package shapeRECTANGULAR
Package formSMALL OUTLINE
Peak Reflow Temperature (Celsius)260
Polarity/channel typeN-CHANNEL
Maximum power dissipation(Abs)1 W
Certification statusNot Qualified
surface mountYES
Terminal surfaceMATTE TIN
Terminal formGULL WING
Terminal locationDUAL
Maximum time at peak reflow temperature40
transistor applicationsSWITCHING
Transistor component materialsSILICON
Base Number Matches1
Si6926AEDQ
Vishay Siliconix
Dual N-Channel 2.5-V (G-S) Input Protected Load Switch
PRODUCT SUMMARY
V
DS
(V)
20
R
DS(on)
(Ω)
0.030 at V
GS
= 4.5 V
0.033 at V
GS
= 3.0 V
0.035 at V
GS
= 2.5 V
I
D
(A)
4.5
4.2
3.9
7.6
Q
g
(Typ.)
FEATURES
Halogen-free
Low R
DS(on)
V
GS
Max Rating: 14 V
Exceeds 2 kV ESD Protection
RoHS
COMPLIANT
DESCRIPTION
The Si6926AEDQ is a dual N-Channel MOSFET with ESD
protection and gate over-voltage protection circuitry
incorporated into the MOSFET. The device is designed for
use in Lithium Ion battery pack circuits. The 2-stage input
protection circuit is a unique design, consisting of two stages
of back-to-back zener diodes separated by a resistor. The
first stage diode is designed to absorb most of the ESD
energy. The second stage diode is designed to protect the
gate from any remaining ESD energy and over-voltages
above the gates inherent safe operating range. The series
resistor used to limit the current through the second stage
diode during over voltage conditions has a maximum value
which limits the input current to
10 mA at 14 V and the
maximum t
off
to 15 µs. The Si6926AEDQ has been
optimized as a battery or load switch in Lithium Ion
applications with the advantage of both a 2.5 V R
DS(on)
rating
and a safe 14 V gate-to-source maximum rating.
APPLICATION CIRCUITS
D
ESD and
Overvoltage
Protection
ESD and
Overvoltage
Protection
R*
G
S
*R typical value is 1.9 kΩ by design.
Battery Protection Circuit
See Typical Characteristics,
Gate-Current vs. Gate-Source Voltage, Page 3.
Figure 1. Typical Use In a Lithium Ion Battery Pack
Figure 2. Input ESD and Overvoltage Protection Circuit
Document Number: 73090
S-81056-Rev. B, 12-May-08
www.vishay.com
1
