KBPC3508-G: DescriptionBridge Rectifiers DIODE RECT BRIDGE 35A 800V; CategoryDiscrete semiconductor diode; File Size80KB，3 Pages; ManufacturerComchip Technology; Websitehttp://www.comchiptech.com/; Environmental Compliance

Download Datasheet Parametric Compare View All

KBPC3508-G Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	KBPC3508-G	-	-	View	Buy Now

KBPC3508-G Overview

Bridge Rectifiers DIODE RECT BRIDGE 35A 800V

KBPC3508-G Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
Maker	Comchip Technology
package instruction	R-XUFM-D4
Reach Compliance Code	compliant
ECCN code	EAR99
Other features	UL RECOGNIZED
Minimum breakdown voltage	800 V
Shell connection	ISOLATED
Configuration	BRIDGE, 4 ELEMENTS
Diode component materials	SILICON
Diode type	BRIDGE RECTIFIER DIODE
Maximum forward voltage (VF)	1.1 V
JESD-30 code	R-XUFM-D4
Maximum non-repetitive peak forward current	400 A
Number of components	4
Phase	1
Number of terminals	4
Maximum operating temperature	150 °C
Minimum operating temperature	-55 °C
Maximum output current	35 A
Package body material	UNSPECIFIED
Package shape	RECTANGULAR
Package form	FLANGE MOUNT
Peak Reflow Temperature (Celsius)	NOT SPECIFIED
Maximum repetitive peak reverse voltage	800 V
surface mount	NO
Terminal form	SOLDER LUG
Terminal location	UPPER
Maximum time at peak reflow temperature	NOT SPECIFIED

Preview

Download Datasheet

View All

Silicon Bridge Rectifiers

KBPC10005-G Thru. KBPC5010-G Series

Reverse Voltage: 50 to 1000V

Forward Current: 10/15/25/35/50A

RoHS Device

Features

-Surge overload -240~500 Amperes peak.

-Low forward voltage drop.

-Electrically isolated base -2000 Volts.

-Materials used carries UL recognition.

-UL recognized file # E349301

R

KBPC

0.442(11.23)

0.424(10.77)

0.921(23.40)

0.882(22.40)

0.94

(2.4)

diam

0.254(6.45)

0.242(6.15)

0.035(0.90)

0.028(0.70)

1.133(28.80)

1.114(28.30)

0.673(17.10)

0.634(16.10)

H for

ole

No.8 screw

193

"(4.9)diam

Mechanical Data

-Polarity: As marked on Body.

-Mounting position: Any.

-Weight: 28.82 grams

(approx.).

0.583(14.80)

0.543(13.80)

0.732(18.60)

0.693(17.60)

0.673(17.10)

0.634(16.10)

1.133(28.80)

1.114(28.30)

Dimensions in inches and (millimeter)

Maximum ratings and electrical characteristics

Rating at 25°C ambient temperature unless otherwise specified.

Single phase, half wave ,60Hz, resistive or inductive load.

For capacitive load, derate current by 20%

KBPC-G

10005

15005

KBPC-G

1001

1501

2501

3501

5001

100

70

100

KBPC-G

1002

1502

2502

3502

5002

200

140

200

KBPC-G

1004

1504

2504

3504

5004

400

280

400

KBPC-G

1006

1506

2506

3506

5006

600

420

600

KBPC-G

1008

1508

2508

3508

5008

800

560

800

KBPC-G

Unit

1010

1510

2510

3510

5010

1000

700

1000

V

Parameter

Symbol

25005

35005

50005

Maximum Rec

urrent

Peak Reverse Voltage

Maximum RMS Bridge Input Voltage

Maximum DC Blocking Voltage

V

RRM

V

RMS

V

DC

50

35

50

Parameter

Maximum Average Forward

Rectified Output Current @Tc=55°C

Symbol

I

(AV)

KBPC10

10

240

KBPC15

15

300

KBPC25

25

400

1.1

10.0

-55 to +150

KBPC35

35

400

KBPC50

50

500

Unit

A

V

μA

°C

Peak Forward Surge Current ,

8.3ms Single Half Sine-Wave

Super Imposed On Rated Load

Maximum Forward Voltage Drop Per Element

at 5.0/7.5/12.5/17.5/25.0A Peak

Maximum Reverse Current at rate

DC Blocking Voltage Per Element @ T

J

=25°C

Operating Temperature Range

Storage Temperature Range

I

FSM

V

F

I

R

T

J

T

STG

Company reserves the right to improve product design , functions and reliability without notice.

QW-BBR55

REV: B

Page 1

Comchip Technology CO., LTD.
