D32P - D60P
V
BR
: 32 - 60 Volts
FEATURES :
*
*
*
*
*
High current capability
High reliability
Low leakage current
Low power dissipation
Pb / RoHS Free
BI-DIRECTIONAL TRIGGER DIACS
DO - 41
0.107 (2.7)
0.080 (2.0)
1.00 (25.4)
MIN.
0.205 (5.2)
0.166 (4.2)
MECHANICAL DATA :
* Case : DO-41 Molded plastic
* Epoxy : UL94V-O rate flame retardant
* Lead : Axial lead solderable per MIL-STD-202,
Method 208 guaranteed
* Polarity : Color band denotes cathode end
* Mounting position : Any
* Weight : 0.339 gram
0.034 (0.86)
0.028 (0.71)
1.00 (25.4)
MIN.
Dimensions in inches and ( millimeters )
MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS
Rating at 25 °C ambient temperature unless otherwise specified.
RATING
Minimum Breakover Voltage
Typical Breakover Voltage
Maximum Breakover Voltage
Peak Pulse Current
Maximum Breakover Voltage Symmetry
Minimum Dynamic Breakback Voltage
Maximum Breakover Current
Power Dissipation @ Ta = 50°C
Maximum Leakage Current
Junction Temperature Range
Storage Temperature Range
Note :
(1) For 10µs @ 120Hz repetition rate, Ta
≤
40
°
C
SYMBOL
V
BR(Min.)
V
BR(Typ.)
V
BR(Max.)
I
TRM
[V
(BR)1
] - [V
(BR)2
]
|
∆V ±
|
I
(BR)1
& I
(BR)2
P
D
I
B
T
J
T
STG
D32P
27
32
37
D35P
30
35
40
2.0
3.0
5.0
D40P
35
40
45
D50P
42
50
58
1.6
4.0
8.0
D60P
56
60
70
UNIT
Volts
Volts
Volts
Amps.
Volts
10
Volts
µA
mW
µA
°C
°C
100
300
10
- 40 to + 100
- 40 to + 125
Page 1 of 1
Rev. 02 : March 25, 2005
