F-214
PCIEC–098–0151–EC–EC–P
PCIEC–064–0151–EC–EM
PCIe
®
Gen 2 and Gen 3
protocol supported
(1,00 mm) .0394"
PCIEC SERIES
PCI EXPRESS JUMPERS
SPECIFICATIONS
For complete specifications and
recommended PCB layouts see
www.samtec.com?PCIEC
®
Mates with:
PCIE
30 AWG
ribbon cable
®
Connector:
PCIEC
Cable
Length
10" (0,25 m)
Rated @ 7dB
Insertion Loss
–DP
5.00 GHz / 10.00 Gbps
Insulator Material:
Black Nylon
Contact:
Phosphor Bronze
Plating:
Au or Sn over
50µ" (1,27 µm) Ni
Operating Temp:
-55°C to +125°C
Card Insertion Depth:
(8,00 mm) .315" nominal
RoHS Compliant:
Yes
Performance data for other cable lengths
and complete test data available at
www.samtec.com?PCIEC or contact
sig@samtec.com
Supports one, four,
eight and sixteen
PCI Express
®
links
Card:
APPLICATIONS
Loop back Extender (From one PCIe slot to another PCIe slot)
Ser-Des Physical Extender (From one PCIe
®
slot to another PCIe
®
Ser-Des)
Physical Extender for easy troubleshooting of PCIe
®
card debug and analysis
(PCIe
®
slot to Emulator or Analyzer)
®
®
Conductor:
1 oz. Copper
Contact Area:
Hard Gold (Contact area)
Insulator:
Nelco 4000-13
RoHS Compliant:
Yes
30 AWG twinax
ribbon cable
Cable:
Conductor:
30 AWG shielded twinax
30 AWG standard ribbon
RoHS Compliant:
Yes
PCIEC
NO. OF
POSITIONS
WIRE
LENGTH
END
NO. 1
END
NO. 2
POWER
LINES
Leave blank for
no Power Lines
IMPEDANCE
OTHER
SOLUTIONS
PCI Express
®
Card Sockets. See
www.samtec.com?PCIE
–036 (x1),
–064 (x4),
–098 (x8),
–164 (x16)
–“XXXX”
= Wire Length
in millimeters
0050 mm
minimum
–EC
= Edge
Card
–EC
= PCIe
®
Edge Card
Leave blank
for 100Ω
–P
= Power Lines
–85
= 85Ω
–EM
= PCIe
®
Edge
Mount Connector
OAL = Wire Length +
L
END TO END
–EC to –EC
–EC to –EM
L
(39,6) 1.56
(49,6) 1.95
A
B
NO. OF
POSITIONS
–036 (x1)
–064 (x4)
–098 (x8)
–164 (x16)
A
(20,30) .800
(34,30) 1.35
(51,30) 2.02
(84,30) 3.32
B
(25,40) 1.00
(39,40) 1.55
(56,40) 2.22
(89,40) 3.52
PCI Express
®
is a registered
trademark of PCI-SIG
®
.
Note:
This Series is non-standard,
non-returnable.
(1,57)
.062
Wire Length = ±(1,27) .050
(8,71)
.343
(10,11)
.398
WWW.SAMTEC.COM
