BYG21M
Taiwan Semiconductor
CREAT BY ART
1.5A, 1000V Fast avalanche Surface Mount Rectifier
FEATURES
- Glass passivated junction chip
- Ideal for automated placement
- Fast switching for high efficiency
- High surge current capability
- Compliant to RoHS Directive 2011/65/EU and
in accordance to WEEE 2002/96/EC
- Halogen-free according to IEC 61249-2-21
TYPICAL APPLICATION
The superior avalanche capability of BYG21M is specially
suited for free-wheeling, clamping, snubber,
demagnetization in power supplies and other power switching applications.
DO-214AC (SMA)
MECHANICAL DATA
Case:
DO-214AC (SMA)
Molding compound: UL flammability classification rating 94V-0
Moisture sensitivity level (MSL): level 1, per J-STD-020
Part no. with suffix "H" means AEC-Q101 qualified
Packing code with suffix "G" means green compound (halogen-free)
Terminal:
Matte tin plated leads, solderable per JESD22-B102
Meet JESD 201 class 2 whisker test
Polarity:
Indicated by cathode band
Weight:
64 mg (approximately)
MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS
(T
A
=25°C unless otherwise noted)
PARAMETER
Maximum repetitive peak reverse voltage
Maximum RMS voltage
Maximum DC blocking voltage
Maximum average forward rectified current
Peak forward surge current, 8.3 ms single half sine-wave
superimposed on rated load
Maximum instantaneous forward voltage I
F
=1A
(Note 1)
I
F
=1.5A
T
J
=25°C
Maximum reverse current @ Rated V
R
T
J
=100°C
T
J
=125°C
Pulse energy in avalanche mode, non repetitive
(Inductive load switch off ) T
A
=25°C, I
(BR)R
=1.23A
Maximum reverse recovery time (Note 2)
Typical junction capacitance (Note 3)
Typical thermal resistance
Operating junction temperature range
Storage temperature range
Note 1: Pulse test with PW=300μs, 1% duty cycle
Note 2: Test conditions: I
F
=0.5A, I
R
=1.0A, I
RR
=0.25A
Note 3: Measured at 1 MHz and applied reverse voltage of 4.0V
Version: A1601
E
RSM
t
rr
C
J
R
θJL
R
θJA
T
J
T
STG
I
R
SYMBOL
V
RRM
V
RMS
V
DC
I
F(AV)
I
FSM
V
F
BYG21M
1000
700
1000
1.5
50
1.5
1.6
1
10
50
30
120
13
20
70
- 55 to +150
- 55 to +150
mJ
ns
pF
°C/W
°C
°C
μA
UNIT
V
V
V
A
A
V
BYG21M
Taiwan Semiconductor
ORDERING INFORMATION
PART NO.
PART NO.
SUFFIX
PACKING
CODE
R3
R2
BYG21M
(Note 1)
H
M2
F3
F2
F4
Note 1: Whole series with green compound
G
PACKING CODE
SUFFIX
PACKAGE
SMA
SMA
SMA
Folded SMA
Folded SMA
Folded SMA
PACKING
1,800 / 7" Plastic reel
7,500 / 13" Paper reel
7,500 / 13" Plastic reel
1,800 / 7" Plastic reel
7,500 / 13" Paper reel
7,500 / 13" Plastic reel
EXAMPLE
EXAMPLE
PART NO.
BYG21MHR3G
PART NO.
BYG21M
PART NO.
SUFFIX
H
PACKING CODE
R3
PACKING CODE
SUFFIX
G
DESCRIPTION
AEC-Q101 qualified
Green compound
RATINGS AND CHARACTERISTICS CURVES
(T
A
=25°C unless otherwise noted)
FIG.1 MAXIMUM AVERAGE FORWARD
CURRENT DERATING
INSTANTANEOUS REVERSE CURRENT(μA)
FIG. 2 TYPICAL REVERSE CHARACTERISTICS
100
2
AVERAGE FORWARD CURRENT (A)
T
J
=125°C
10
1.5
1
1
0.5
0.1
T
J
=25°C
0
0
25
50
75
100
125
150
LEAD TEMPERATURE (
°
C)
0.01
0
20
40
60
80
100
PERCENT OF RATED PEAK REVERSE VOLTAGE (%)
FIG. 3 MAXIMUM NON-REPETITIVE FORWARD
SURGE CURRENT
50
70
60
JUNCTION CAPACITANCE (pF)
8.3ms single half sine wave
50
40
30
20
10
0
1
10
100
0.1
FIG. 4 TYPICAL JUNCTION CAPACITANCE
PEAK FORWARD SURGE URRENT (A)
40
f=1.0MHz
Vslg=50mVp-p
30
20
10
0
1
10
100
NUMBER OF CYCLES AT 60 Hz
REVERSE VOLTAGE (V)
Version: A1601
BYG21M
Taiwan Semiconductor
CREAT BY ART
