RAFIX 22 FS
+
- Emergency stop contact block, 1 NC, 1 NO
1.20.126.403/9000
Caution: Only for emergency stop functions.
General information
Lamp optional
Mechanical design
Mounting
Contact system
Contact materials
Contact arrangement
NC contact forcibly actuated acc. to IEC
60947-5-1
Terminals
Electrical characteristics
Operating voltage AC / DC min.
Operating voltage AC / DC max.
Operating current AC / DC min.
Operating current AC / DC max.
Rated power max.
Other specifications
Operating life at 10 mA / 24 V DC
B10
Switching reliability at 24V / 5mA DC
Storage temperature min.
Ambient temp. operating min.
Ambient temp. operating max.
Storage temperature max.
Color of plunger
Robustness
Shock resistance acc. to IEC 60068-2-27
Resistance to vibrations acc. to IEC 60068-2-6
Environmental restistance
Solderability / solder heat resistance
Solder techniques
Color of housing
ROHS compliant
REACH compliant
SMT LED
soldering in PCB
bridge-contact self cleaning
Au
1 NC + 1 NO
yes
THT solder terminals with locating lug
5V
35 V
1 mA
100 mA
250 mW
1,000,000
1,300,000
10 x 10
-6
-40 °C
-40 °C
+85 °C
+85
yellow
acc. to IEC 60947-5-5 (TÜV)
15 g at 11 ms, amplitude half sinusoidal
5 g at 10 ... 500 Hz
acc. to IEC 60068-2-14, -30, -33 and -78
DIN EN 60068-2-20
wave solder bath / manual soldering
grey
yes
yes
