Resistors
Make Possible
General Purpose Radial Terminal
Power Wirewound Resistor
General Purpose
PW Radial Series
Radial Terminal
0.10 to 2.0K
Power Wirewound Resistor
20 watts to 50 watts
±10% or ±5% tolerance
RoHS compliant construction available
•
0.10Ω to 2.0KΩ
Custom parts available - consult factory
•
20 watts to 50 watts
PW Radial Series
•
±10% or ±5% tolerance
•
RoHS compliant construction available
•
Custom parts available - consult factory
Inorganic
fireproof
encapsulant
Tinned steel
Steatite
ceramic case
All Pb-free parts comply with EU Directive 2011/65/EU (RoHS2)
All Pb-free parts comply with EU Directive 2011/65/EU amended by (EU) 2015/863 (RoHS3)
Alloy resistance wire on
fiberglass substrate
Electrical Data
Type
PW-20E
PW-30
PW-40
PW-50E
- Flameproof inorganic construction
- EIA RS-344, insulated fixed wirewound resistors
- 1000 hour load life at 25°C: 5% max.
- Moisture no load 240 hours: 2% max.
- Temperature cycling (5 cyc.): 5% max.
Power Rating @ 25°C
(watts)
20
30
40
50
Resistance
Range (ohms)
0.1 to 2.0K
0.5 to 1.2K
0.65 to 1.5K
0.08 to 1.8K
Temperature Rise Chart
300
Power Derating Curve
100
Temperature Rise (°C)
PW - 50E
200
PW - 40
100
PW - 30
Percent of Rated Load
PW - 20E
80
60
40
20
0
PW - 20E, PW - 30, PW - 40
PW - 50E without Bracket
0
0
25
50
75
100
Percent of Rated Load
125
0
50
100
150
200
Ambient Temperature (°C)
With Bracket:
PW-30 Increased to 40 watts
PW-40 Increased to 50 watts
PW-50 Increased to 60 watts
250
General
Note
General Note
General
Note
TT Electronics reserves the
own
to
and is
changes in product specification without notice or liability.
TT
information is subject to IRC’s
right
data
make
considered
in product
time of going to print.
All
Electronics reserves the
right
to
make
changes
accurate at
specification without notice or liability.
All information is subject to TT Electronics’ own data and is considered accurate at time of going to print.
All information is subject to TT Electronics’ own data and is considered accurate at time of going to print.
Wire and Film Technologies Division
• 4222 South Staples Street • Corpus Christi Texas 78411 USA
IRC reserves the right to make changes in product specification without notice or liability.
BI Technologies IRC Welwyn
TT electronics plc
www.ttelectronicsresistors.com
www.ttelectronics.com/resistors
PW Radial Series Issue March 2011 Sheet 1 of 2
A subsidiary of
© TT Electronics plc
© TT Electronics plc
Telephone: 361 992 7900 • Facsimile: 361 992 3377 • Website: www.irctt.com
07.14
06.18
General Purpose Radial Terminal
General Purpose Radial Terminal
Power Wirewound Resistor
Power Wirewound Resistor
General Purpose
Radial Terminal
PW Radial Series
PW Radial Series
Power Wirewound Resistor
Physical Data
PW-20E Wirewound
0.250 (Typ.)
5/32 Dia. Thru (2)
A
0.032±0.0025
0.157±0.020
0.5±0.030
Make Possible
PW-30, 40 and 50E Wirewound
A
0.282±0.020
5/32 Dia. Thru (2)
0.032±0.0025
0.75±0.030
0.25
B
0.5±0.030
0.75±0.030
0.875
0.375
0.75
7/32 Dia.
PW-20E Alternate
Terminal
Configuration
-0.020" Tin coated Steel
Printed Circuit Terminal
0.205 or
0.187±0.005
0.125±0.015
0.200 (Typ.)
0.25±0.031
0.069±0.005
0.135±0.015
Dimensions (Inches)
Type
PW-20E
PW-30
PW-40
PW-50E
A
1.875 ±0.030
2.00 ±0.030
2.45 ±0.030
3.075 ±0.030
B
2.5 ±0.060
2.55 ±0.060
3.00 ±0.060
3.625 ±0.060
Wire and Film Technologies Division
• 4222 South Staples Street • Corpus Christi
Texas
78411 USA
Telephone:
361 992 7900 •
Facsimile:
361 992 3377 •
Website:
www.irctt.com
PW Radial Series Issue March 2011 Sheet 2 of 2
