Hall Sensor
Hall Sensor
Applications
Double coil DC brushless motor (PT-30E6/7).
VCD/DVD loader, CD/DVD-ROM.
Cover detector.
Speed measurement.
Home appliances.
Home safty.
Package: TO-92, PT-30E6/7
1.75mm
1.35mm
Sensor Area
200um*200um
Hall sensor
B
TO-92
1
2
3
4
D
Features
Built-in hall sensor.
Motor lock protection and automatic restart.
Built-in hysteresis comparator.
Built-in protection zener diode.
Hi-balance and low thermal drift magnetic sensing.
Low power consumption and hi-driving efficiency.
PT-30E6: 4.2~18V
PT-30E7: 4.2~18V
PT-3601: 2.6~18V
G
C
A
E
H
Package: SOT-23, PT-3601
Output Voltage
b
F
Output Voltage
RP
OFF
RP
OFF
H
E
SOT-23
ON
-100G
OP
+100G
ON
-100G
OP
+100G
D
A2 A1
e
Magnetic Flux Density in Gauss
Magnetic Flux Density in Gauss
A
Magnetic Hysteresis Characteristics
C
F
L
Specifications
Absolute Maximum Ratings (Ta = 25 C)
Parameter
Maximum supply voltage
Allowable power dissipation
Operating temperature
Storage temperature
Output Continuous current
Output Peak current
Symbol
V
DD
max
Pd
Ta
Ts
I
0ut
I
0ut
Conditions
Ratings
18
Units
V
mW
O
TO-92 / SOT-23
*
500/300
-30 ~ +85
-50 ~ +150
C
C
O
TO-92 / SOT-23
TO-92 / SOT-23
Max.
T< 20us
-
400/25
600/40
mA
mA
*
On 50mm x 50mm x 1.6mm glass epoxy board
PROLIFIC TECHNOLOGY INC.
7F, No.48, Sec.3, Nan Kang Rd., Nan Kang, Taipei, 115, Taiwan
Ver 1.0
