PIN Photodiodes
PNZ313
(PN313)
Silicon planar type
For optical control systems
7.0
±0.5
Unit: mm
Anode mark (φ1.6)
Device
center
(5.0)
■
Features
•
Fast response which is well suited to high speed modulated light
detection: t
r
, t
f
=
50 ns (typ.)
•
High sensitivity, high reliability
•
Peak emission wavelength matched with infrared light emitting
diodes:
λ
p
=
940 nm (typ.)
•
Wide detection area, wide half-power angle:
θ =
65° (typ.)
•
Adoption of visible light cutoff resin
8.0
±0.5
13 min.
2.3
±0.3
2-1.2
±0.15
2-0.6
±0.15
0.41
±0.15
2
1
5.08
±0.25
■
Absolute Maximum Ratings
Parameter
Reverse voltage
Power dissipation
Operating ambient temperature
Storage temperature
T
a
=
25°C
V
R
P
D
T
opr
T
stg
30
100
−30
to
+80
−40
to
+80
V
mW
°C
°C
2.8
±0.3
Symbol
Rating
Unit
1: Cathode
2: Anode
LSTFR102NC-001 Package
■
Electrical-Optical Characteristics
T
a
=
25°C
±
3°C
Parameter
Dark current
Photocurrent
Rise time
*2
Fall time
*2
Rise time
*2
Fall time
*2
Terminal capacitance
Half-power angle
*1
Symbol
I
D
I
L
λ
p
t
r
t
f
t
r
t
f
C
t
θ
V
R
=
10 V
Conditions
V
R
=
10 V, L
=
1 000 lx
V
R
=
10 V
V
R
=
10 V, R
L
=
1 kΩ
V
R
=
10 V, R
L
=
100 kΩ
V
R
=
0 V, f
=
1 MHz
The angle from which photocurrent
becomes 50%
Min
Typ
5
Max
50
Unit
nA
µA
nm
ns
ns
µs
µs
pF
°
35
50
940
50
50
5
5
70
65
Peak emission wavelength
Note) 1. Measuring methods are based on JAPANESE INDUSTRIAL STANDARD JIS C 7031 measuring methods for diodes.
2. *1: Source: Tungsten (color temperature 2 856 K)
*2: Switching time measurement circuit
Sig. in
λ
P
=
800 nm
50
Ω
R
L
V
R
=
10 V
(Input pulse)
Sig. out
(Output pulse)
t
d
t
r
t
f
90%
10%
t
d
: Delay time
t
r
: Rise time (Time required for the collector photocurrent
to increase from 10% to 90% of its final value)
t
f
:
Fall time (Time required for the collector photocurrent
to decrease from 90% to 10% of its initial value)
Note) The part number in the parenthesis shows conventional part number.
Publication date: April 2004
SHE00033BED
