260 Wa t t , Hi Re l, M ed i ca l Gr ade P ow er Su p p li e s
PSX300
Universal Input, 90 to 264 VAC
12V to 54V Outputs (250W to 270W)
Very Cool Housing
Temperature, Cooling Fan
IP21 or IP22 Ingress Protection Rating
Class I or Class II Input Versions
series
XL VENTED CASE
10uA Leakage Current Option
(CF Isolation Option)
Model Number Output VDC (nom.) Output Amps (max.) Output Power (nom.) Output Ripple (max.)
SINGLE OUTPUT
Overvoltage Protection:
115% - 130% of nominal output voltage
PSX312M
12
20.8
250W
(60V max, for 48V and 54V models)
17.3
260W
Overcurrent Protection:
110% - 150% of output current rating,
PSX316M
16
260W
auto-recovery
16.2
removal of overload
upon
Overtemperature Protection:
Integrated
14.4
control chip, prevents
into
PSX318M
18
260W
damage if air flow is obstructed
PSX320M
20
13.0
260W
Hold-Up Time:
20mS min @ full load
120mV p-p
150mV p-p
160mV p-p
180mV p-p
200mV p-p
240mV p-p
280mV p-p
360mV p-p
480mV p-p
540mV p-p
PSX315M
15
t
PSX324M
PSX328M
Operating Temperature:
24
28
PSX336M
Temperature:
36
Storage
PSX348M
Humidity:
48
Relative
PSX354M
Elevation:
0 to 40C, linear derating to 75% of full
9.3
260W
power at 60C (see graph on pg 4)
260W
-40 to +80C
7.2
10% to 90%,
5.6
non-condensing
0 – 5000M
10.8
260W
270W
270W
54
5.0
ctor
(Standard models shown, other output voltages and model numbers available as UL approved custom versions. Contact Jerome Customer Service for more info.)
Dimensions:
7.1” x 3.75” x 2.56”
300mV
Model Number System and Suffix Options:
Safety, Medical:
Safety, ITE:
Weight:
0.9 Kg max
MOPP Isolation to IEC60601-1 3
rd
edition
Example: PSX312M
S
X
3
M
Switch-Mode
XL Size Enclosure
IEC 60950-1
Additional Suffix Options:
C
D
H
I
Class I Input, CF Isolation at Output
Class II Input, BF Isolation at Output
Non-Detachable, Hospital Grade Input Cord
Non-Detachable, SVT Input Cord
available
P
Ingress Protection:
IP21, or optional IP22
Power Factor Corrected
Power Code (typical 260W, for family)
Medical (leave blank for ITE product)
Spec Version V2
June, 2013
12
Voltage Code
meindustries.com
WWW.ASTRODYNETDI.COM
PHONE: 1-908-353-5700
FAX: 1-908-353-1021
DF Writer - Trial :: http://www.docudesk.com
260 Wa t t , Hi Re l, M ed i ca l Gr ade P ow er Su p p li e s
INPUT SPECIFICATIONS
Input Voltage Range
Input Current
Power Factor
Leakage Current, Earth
Leakage Current, Output
90-264VAC
50/60Hz, Single Phase
100Vac: 3.3A max.,
240Vac: 1.4A max.
0.90 minimum @ 240Vac in
140-280uA optional configurations
BF Isolation: 100uA max
CF Isolation: 10uA max
Storage Temperature
Relative Humidity
Elevation
Ingress Protection
PSX300
ENVIRONMENTAL SPECIFICATIONS
Operating Temperature
series
0 to +40°C linear derating to
75% of full power at 60°C
(see graph on page 4)
-40 to +80°C
*
10% to 95% non-condensing*
0-5000M
IP21 or optional IP22
OUTPUT SPECIFICATIONS
Voltage and Current
Minimum Load
Load Regulation
Line Regulation
Output Voltage Tolerance
Output Ripple
Over Voltage Protection
Over Current Protection
See Selection Chart Page 1
Not Required
± 2% typ, depending on cord and
connector
± 0.1% max.
± 5% standard, tighter tolerances
available on request
See Selection Chart Page 1
115% - 130% of nominal output
(60V max, for 48V & 54V models)*
110-150% of output current
rating, auto-recovery upon
removal of over load.
Over Temperature Protection
Integrated into control chip,
prevents damage if air flow is
obstructed
Turn On Time
Hold-Up Time
500mS maximum
20mS min @ full load
GENERAL SPECIFICATIONS
Medical Output Isolation Options
1. BF Output, Class I input
2. BF Output, Class II Input
3. CF Output, Class I Input
Safety, Medical
Designed to Meet MOPP
Isolation
to IEC60601-1 3rd edition
Safety, ITE
Designed to Meet IEC
60950-1
PHYSICAL SPECIFICATIONS
Size
Weight
7.1” x 3.75” x 2.56”
29.7oz (900g)
All specifications are typical at nominal input, full load, and 25°C unless other-
wise noted
WWW.ASTRODYNETDI.COM
PHONE: 1-908-353-5700
FAX: 1-908-353-1021
260 Wa t t , Hi Re l, M ed i ca l Gr ade P ow er Su p p li e s
MECHANICAL DIMENSIONS
7.41
PSX300
series
IEC 60320 INPUT SHOWN
OTHER INPUT AND OUTPUT
CORD AND CONNECTOR
OPTIONS AVAILABLE
XL VENTED CASE
3.75
VENTS DO NOT OBSTRUCT
3.75
2.56
2.75
IEC 60320 OPTION
IEC CLAMP ALSO
AVAILABLE
C 14 Style Inlet
C 18 Style Inlet
Class I Input
Class II Input
1 CUSTOMIZABLE TOP SURFACE
MARKING AREA = 2.49" X 2.87"
2 STANDARD JEROME/ASTRODYNE
INFO
A) JEROME/ASTRODYNE NAME,
AND WEB URL
B) MODEL NUMBER AND PRODUCT
DESCRIPTION
C) ELECTRICAL RATINGS
D) COMPLIANCE AGENCY MARKS
3 OPTIONAL- SERIAL NUMBER
AND/OR BAR CODE
4 DATE CODE
5 BUMP-ON (4 CORNERS) -BLACK
US
VENTS DO NOT OBSTRUCT
WWW.ASTRODYNETDI.COM
PHONE: 1-908-353-5700
FAX: 1-908-353-1021
260 Wa t t , Hi Re l, M ed i ca l Gr ade P ow er Su p p li e s
Thermal Derating Graph
•
•
•
•
•
•
•
•
Expanded Operating Temperature Range
Additional Noise and/or Surge Protection
Output Cord Sets and Connector Configurations
Case Colors, Markings & Logos
16 Hour Burn-in
Output Voltage up to 200VDC (NRE fees apply)
DC Input Rating (NRE fees apply)
400 Hz Input (NRE fees apply)
PSX300
series
OUTPUT POWER
100%
75%
50%
25%
PSX300 Series
260 Watt Output, Hi
0%
Rel
Medical Grade Power Supply
Standard 5 Year Warranty
-10
40
50
60
70
AMBIENT TEMPERATURE,
CELSIUS
Optional Features:
•
•
•
•
•
•
•
•
•
•
•
LED Power On Indicator (Blue or Green, Blue required for Efficiency Level 5)
Jerome Industries
www.jeromeindustries.com
Spec Version V2
Power On/Off Switch
730 Division St.
June, 2013
Tighter Output Voltage limits (tighter tolerance)
Elizabeth, NJ 07201
Expanded Operating Temperature Range
Additional Noise and/or Surge Protection
Output Cord Sets and Connector Configurations
Case Colors, Markings &
with deskPDF PDF Writer - Trial :: http://www.docudesk.com
