MGDT Series
www.vishay.com
Vishay Custom Magnetics
Miniaturized Gate Drive Planar Transformers
FEATURES
• Deliver MOSFET / IGBT gate power and timing
signals simultaneously
Available
• Directly drive high side MOSFETs / IGBTs on busses up
to 1200 V
• Excellent rise time, overshoot, and peak current
characteristics
• 8 mm minimum creepage and clearance from drive to
gates
• Low profile planar package
• LF and SM versions are RoHS-compliant
• Material categorization: for definitions of compliance
please see
www.vishay.com/doc?99912
ABSOLUTE MAXIMUM RATINGS
PARAMETER
Dielectric
withstand
voltage
Total power
dissipation
(1)
Operating
temperature
(2)
Storage
temperature
Frequency
Size
(L x W x H)
Terminals
CONDITIONS
Drive to gate,
1 min
Gate to gate,
1 min
T
A
= 25 °C
Continuous
Continuous
LIMITS
3750
2500
2.0
-55 to +125
-55 to +130
100 to 500
20.57 x 18.42 x 11.43
Through-hole and surface-mount
UNITS
V
AC
V
AC
W
°C
°C
kHz
mm
Note
*
This datasheet provides information about parts that are
RoHS-compliant and / or parts that are non RoHS-compliant. For
example, parts with lead (Pb) terminations are not RoHS-compliant.
Please see the information / tables in this datasheet for details
Note
(1)
Derate at 33.3 mW/ºC above 25 ºC
(2)
Derate drive level to 60 V/μs above 85°C
STANDARD ELECTRICAL SPECIFICATIONS
USEFUL
FREQ.
RANGE
(kHz)
DRIVE
EXCITATION
MAX.
(Vμs)
MAGNETIZING
INDUCTANCE
MIN.
(μH)
(2)(3)
LEAKAGE
INDUCTANCE
MAX.
(μH)
(4)
DC
RESISTANCE
(2)
DRIVE
MAX.
()
0.35
0.35
0.35
0.35
0.35
0.35
GATES
MAX.
()
0.35
0.35
0.35
0.50
0.50
0.50
INTERWINDING
CAPACITANCE
DRIVE
TO
GATE
MAX.
(pF)
15
15
15
25
25
25
GATE
TO
GATE
MAX.
(pF)
10
10
10
10
10
10
PART NUMBER
TRANSFER
RATIO
(± 3 %)
(1)
MGDT100100
MGDT100100LF
MGDT100100-SM
MGDT100125
MGDT100125LF
MGDT100125-SM
100 to 500
100 to 500
100 to 500
1:1:1
1:1:1
1:1:1
80
80
80
80
80
80
240
240
240
240
240
240
0.5
0.5
0.5
0.5
0.5
0.5
100 to 500 1 : 1.25 : 1.25
100 to 500 1 : 1.25 : 1.25
100 to 500 1 : 1.25 : 1.25
Notes
(1)
Drive : gate : gate
(2)
T = 25 °C
A
(3)
100 mV at 100 kHz across the drive winding with all gates open
(4)
100 mA at 100 kHz into the drive winding with all gates shorted
Revision: 07-Sep-2018
Document Number: 34454
