BRC144ECM Series
NPN Built-in Resistor Transistor CMPAK Series
Inverter, Driver, Switching
ADE-208-1445B (Z)
Rev.2
Sep. 2001
Features
•
Built–in Resistor Type
•
Simplifies Circuit Design
•
Reduces Board Space
•
Complementary pair with BRA144ECM series
Outline
CMPAK
3
3
R
1
2
1
R
2
2
1. Ground (Emitter)
2. Input (Base)
3. Output (Collector)
1
Note: Marking is shown in below.
Device
BRC144ECM
BRC124ECM
BRC114ECM
BRC143ECM
BRC123ECM
Marking
BG
DG
FG
HG
KG
R1 (kΩ)
Ω
47
22
10
4.7
2.2
R2 (kΩ)
Ω
47
22
10
4.7
2.2
BRC144ECM Series
Absolute Maximum Ratings
(Ta = 25°C)
Item
Supply voltage
Input voltage
BRC144ECM
BRC124ECM
BRC114ECM
BRC143ECM
BRC123ECM
Output current
Total power dissipation
Junction temperature
Storage temperature
I
O
P
T
*
Tj
Tstg
Symbol
V
CC
V
I
Ratings
50
−10
to +50
−10
to +45
−10
to +30
−10
to +20
−10
to +15
100
150
150
−55
to +150
mA
mW
°C
°C
Unit
V
V
*Value on the glass epoxy board. (10 mm
×
10 mm
×
0.7 mm)
Rev.2, Sep. 2001, page 2 of 12
BRC144ECM Series
Electrical Characteristics
(Ta = 25°C)
Item
Input on voltage BRC144ECM
BRC124ECM
BRC114ECM
BRC143ECM
BRC123ECM
Input off voltage BRC144ECM
BRC124ECM
BRC114ECM
BRC143ECM
BRC123ECM
Output saturation voltage
Output cutoff current
DC current
transfer ratio
BRC144ECM
BRC124ECM
BRC114ECM
BRC143ECM
BRC123ECM
Input resistance BRC144ECM
BRC124ECM
BRC114ECM
BRC143ECM
BRC123ECM
Resistance ratio
R
1
/R
2
R
1
V
O(on)
I
O(off)
Gi
V
I(off)
Symbol
V
I(on)
Min
1.5
1.3
1.2
1.1
1.1
1.0
1.0
1.0
1.0
1.0
70
56
30
20
20
33
15
7
3.3
1.5
0.8
Typ
47
22
10
4.7
2.2
1.0
Max
4.5
3.0
2.4
2.0
1.8
1.5
1.5
1.5
1.5
1.5
0.3
0.5
61
28
13
6.1
2.8
1.2
kΩ
V
CC
= 5 V, I
O
= 10 mA
V
CC
= 5 V, I
O
= 20 mA
V
µA
I
O
= 10 mA, I
I
= 0.5 mA
V
CC
= 50 V, I
I
= 0
V
CC
= 5 V, I
O
= 5 mA
V
V
CC
= 5 V, I
O
= 100
µA
Unit
V
Test conditions
V
CC
= 0.3 V, I
O
= 5 mA
Rev.2, Sep. 2001, page 3 of 12
BRC144ECM Series
Total Power Dissipation Curve
200
Total Power Dissipation P
T
* (mW)
150
*Value on
the grass epoxy board.
(10 mm
×
10 mm
×
0.7 mm)
100
50
0
50
100
150
200
Ambient Temperature Ta (°C)
Rev.2, Sep. 2001, page 4 of 12
BRC144ECM Series
Main Characteristics (BRC144ECM)
Output Current vs. Supply Voltage
100
R
L
= 0
Output Current I
O
(mA)
.0
Pulse test
1
0.9
0.8
DC Current Gain vs. Output Current
200
V
CC
= 5 V
R
L
= 0
Pulse test
75 ˚C
0.7
0.6
0.5
0.4
60
40
20
DC Current Gain Gi
80
0.3
100
25 ˚C
Ta = –25 ˚C
0.2
I
I
= 0.1 mA
0
1
2
3
4
Supply Voltage V
CC
(V)
Input Voltage vs. Output Current
V
CC
= 0.3 V
R
L
= 0
Pulse test
Ta = –25 ˚C
25 ˚C
5
0
1
10
Output Current I
O
(mA)
100
100
V
I
(V)
10
Output Current I
O
(mA)
1.0
Output Current vs. Input Voltage
V
CC
= 5 V
R
L
= 0
Pulse test
10
Input Voltage
0.1
75 ˚C
25 ˚C
1.0
75 ˚C
0.01
Ta = –25 ˚C
0.5
1.0
1.5
2.0
Input Voltage V
I
(V)
2.5
0.1
0.1
1.0
10
Output Current I
O
(mA)
100
0.001
0
Output On Voltage V
O(on)
(V)
Output On Voltage vs. Output Current
1.0
I
O
/ I
I
= 20
Pulse test
25 ˚C
Ta = –25 ˚C
0.1
75 ˚C
0.01
0.01
0.1
1.0
10
Output Current I
O
(mA)
100
Rev.2, Sep. 2001, page 5 of 12
