SINGLE OUTPUT HIGH VOLTAGE MODULES
A SERIES
6
High Voltage Biasing Supply
The A Series of high-voltage regulated DC-DC converters addresses
the needs of the miniature PCB-mount regulated high voltage
power supply user. Designed and built utilizing state-of-the-art
power-conversion topology, these units feature surface-mount
technology and encapsulation techniques that provide high reliability
and performance. Typical applications for the A Series include the
following: bias supplies, electrostatic detectors, mass spectrometry,
and photomultiplier tubes (PMTs).
•
•
•
•
•
8 models from 0 to 62V through 0 to 6kV
4, 20 or 30 watts of output power
Maximum Iout capability down to 0 Volts
Wide input voltage range
Available with Ripple Stripper® Filter (-F
Option)
CONDITIONS
•
•
•
•
•
12V
Indefinite output short-circuit protection
Output current monitor
Fixed-frequency, low-stored-energy design
>430,000 hour MTBF @65°C
UL/cUL Recognized Component; CE Mark (LVD & RoHS)
MODELS
UNITS
PARAMETER
INPUT
Voltage Range
Voltage Range
Current
Current
Current
AC Ripple Current
Full Power
Derated Power Range
Standby / Disable
No Load, Max Eout
Max Load, Max Eout
Nominal Input, Full Load
24V
+ 23 to 30
+ 9 to 32
< 30
< 90
~ 1350
< 80
VDC
VDC
mA
mA
mA
mA p-p
+ 11 to 16
+ 9 to 32
< 30
< 100
~ 400
< 80
OUTPUT
Voltage Range
Nominal Input Voltage
Power
Current
Current Monitor Scaling
Voltage Monitor Scaling
Ripple
Ripple with -F-M Option*
Dynamic Load Regulation
Line Regulation
Static Load Regulation
Stability
Nominal Input, Max Eout
Iout Entire Output Voltage Range
Full Load
With -Y5 option
Full Load, Max Eout
½ to Full Load, Max Eout per .1mA
Nom. Input, Max Eout, Full Power
No Load to Full Load, Max Eout
30 Min. warmup, per 8 hr/ per day
Nominal Input
1/16A
0 to 62
12
4
64
24
20
24
30
12
4
32
1/8A
0 to 125
24
20
24
30
12
4
16
1/4A
0 to 250
24
20
80
24
30
120
12
4
8
1/2A
0 to 500
24
20
40
24
30
60
4
4
12
1A
0 to 1,000
24
20
20
24
30
30
4
2
12
2A
0 to 2,000
24
20
10
24
30
15
4
1
12
4A
0 to 4,000
24
20
5
66.7
6A
0 to 6,000
12
4
12.9
VDC
VDC
Watts
mA
mA/V
-
24
30
85.2
24
20
48.5
24
30
5
56.8
320 480
160 240
7.5 0.67 3.3
0.985 3.90
7.40 438.4 1860.5 2891.5 213.3 1000 1481.5 123.1 506.3 740.7 55.56 243.9 400 31.75 129.9 211.3 16.4
10:1 ± 2% into 10MΩ
.02
.03
.05 .013 .015 .016 .01
.04 .048 .001 .02 .017 .038 .071 .15
.01
100:1 ± 2% into 10MΩ
.05 .065 .019 .057 .022 .018 .073 .112 %V p-p
V pk
VDC
VDC
VDC
Full Load, Max Eout, 300pF bypass Cap
.002 .004 .006 .0048 .0056 .006 .0052 .0028 .005 .001 .0138 .0016 .001 .0008 .002 .0007 .0038 .004 .0004 .0088 .0026 .0003 .0012 .004 %V p-p
<.12 <.12 <.12 <.12 <.12 <.12 <.20 <.20 <.20 <.50 <.50 <.50 <1.0 <1.0 <1.0 <2.0 <2.0 <2.0 <4.0 <4.0 <4.0 <6.0 <6.0 <6.0
< 0.01 %
< 0.01%
< 0.01% / < 0.02%
PROGRAMMING & CONTROLS
Input Impedance
Adjust Resistance
Adjust Logic
Enable/Disable
Nominal Input
Typical Potentiometer Values
0 to +5 for +Out, +5 to 0 for - Out
ALL TYPES
+ Output Models 1.1MΩ to GND, - Output Models 1.1MΩ to +5 Vref
10K to 100K (Pot across Vref. & Signal GND, Wiper to Adjust)
+4.64 VDC for +Output or +0.36 for -Output = Nominal Eout
+ 5.00VDC ± 2%, Zout = 464Ω ± 1%
0 to +0.5 Disable, +2.4 to 32 Enable (Default = Enable)
MΩ
Ω
-
-
VDC
Output Voltage & Impedance
T=+25°C
ENVIRONMENTAL
Operating
Coefficient
Thermal Shock
Storage
Humidity
Altitude
Shock
Vibration
Full Load, Max Eout, Case Temp.
Over the Specified Temperature
Mil-Std 810, Method 503-4, Proc. II
Non-Operating, Case Temp.
All Conditions, Standard Package
Standard Package, All Conditions
Mil-Std-810, Method 516.5, Proc. IV
Mil-Std-810, Method 514.5, Fig.14.5C-3
STANDARD
-40 to +65
±50
-40 to +65
-55 to +105
0 to 95% non-condensing
-25PPM OPTION
+10 to +45
+25
°C
PPM/°C
°C
°C
-
-
G’s
G’s
Sea Level through Vacuum (Vacuum may require -P2 option, contact factory for details.)
20 (Standard), 40 (-C Option)
10 (Standard), 20 (-C Option)
*Note: For additional information on the reduced ripple option, see
-F Option datasheet.
Specifications subject to change without notice.
Higher Service, Higher Performance, Higher Reliability
Making High Voltage Easier!
®
ULTRAVOLT
®
©2011, UltraVolt Inc. All rights reserved.
SINGLE OUTPUT HIGH VOLTAGE MODULES
A SERIES
STANDARD CASE
7
High Voltage Biasing Supply
CONSTRUCTION
Epoxy-filled DAP box certified to ASTM-D-5948 with -C Option:
Aluminum Alloy 5052-H32, Finish: MIL-A-8625 Type II (Anodizing)
SIZE
Volume 4.30in³ (70.5cc), w/ -C Option: 8.00in³ (131.1cc)
Weight 5.0oz (142g), w/ -C Option: 10.0oz (284g)
Overall ±0.050” (1.27)
Pin to Pin ±0.015” (0.38)
Mounting hole location ±0.025” (0.64)
TOLERANCE
NOTES
20W and 30W versions are an additional 0.062” (1.57) in height.
-M equipped units are an additional 0.030” (0.76) for each dimension.
Contact
UltraVolt’s Customer Service Department
for drawings of models
equipped with -E or -H options.
Downloadable drawings (complete with mounting &
pin information) and 3D models are available online.
WITH -C OPTION
IEC-60950-1
ORDERING INFORMATION
0 to 62 VDC Output
0 to 125 VDC Output
0 to 250 VDC Output
0 to 500 VDC Output
0 to 1,000 VDC Output
0 to 2,000 VDC Output
0 to 4,000 VDC Output
0 to 6,000 VDC Output
12VDC Nominal
24VDC Nominal
Positive Output
Negative Output
Watts Output (12 V Only)
Watts Output (24 V Only)
Watts Output (24 V Only)
Plastic Case - Diallyl Phthalate
‘Eared’ Chassis Mounting Plate
RF-Tight Aluminum Case
.400” High (sized to fit case)
Integral Output Filter*
Six-sided Mu-Metal Shield
Optional Eout Monitor
Boosted Iout Monitor Signal Level
25PPM Temperature Coefficient
5V Control and Monitors
10V Control and Monitors (24Vin only)
Flying Lead for HV Output
Shielded Flying Lead for HV Output
1/16A
1/8A
1/4A
1/2A
1A
2A
4A
6A
12
24
-P
-N
4
20
30
(Standard)
-E
-C
-H
-F
-M
-Y5
-Y10
-25PPM
-I5
-I10
-W
-WS
Type
Input
Non-RoHS compliant units are
available. Please contact the
factory for more information.
Polarity
Power
Manufactured in USA
PIN
CONNECTIONS
FUNCTION
1
Input-Power Ground Return
2
Positive Power Input
3
Iout Monitor
4
Enable/Disable
5
Signal Ground Return
6
Remote Adjust Input
7
+5VDC Reference Output
8
HV Ground Return
9
HV Ground Return or Eout Monitor (-Y5)
10 & 11 HV Output
All grounds joined internally. Power-supply mounting
points isolated from internal grounds by >100kΩ,
.01uF / 50V (Max) on all models except -M (20W and
above), -M-E, -M-C, and -M-H configurations which
are 0Ω.
Popular accessories ordered with this product include
CONN-KIT and BR-1 mounting bracket kit.
Case
Heat Sink
Ripple Stripper
®
Shield
Voltage Monitor
I
out
Monitor Boost
Temp. Coefficient
Enhanced Interface
Option
Rev. AE 10/14
*Note: For additional information on the reduced ripple option, see
-F
Option datasheet.
Example:
1/2A12-P4-M
Type
Voltage
Model
Input
Option (Mu-Metal)
Power
Polarity
Making High Voltage Easier!
®
ULTRAVOLT
®
1800 Ocean Avenue, Ronkonkoma, NY 11779
Phone: 1-631-471-4444 Fax: 1-631-471-4696 www.ultravolt.com
