Features
■
High resistance to heat and humidity
■
Resistance to mechanical shock and
Applications
■
Mobile phones
■
Cellular phones
■
CTV, VCR, HIC, FDD
*R
oH
S
CO
M
LE
AD
FR
EE
pressure
■
Accurate dimensions for automatic
surface mounting
■
Inductance range: 0.12 to 150 µH
■
RoHS compliant*
22
0
CM322522 Series - Chip Inductor
Operating Temperature
................................-40 °C to +125 °C
(Temperature rise included)
Storage Temperature
................................-40 °C to +125 °C
Resistance to Soldering Heat
.............................. 245 °C, 5 seconds
Temperature Rise ..........................20 °C
Rated Current .... Inductance drops 10 %
Moisture Sensitivity Level .....................3
................. N/A
Materials
Core ..............................................Ferrite
Wire ...........................Enamelled copper
Enclosure............................. Epoxy resin
Terminal Finish ...................................Sn
Packaging ...... 2,000 pcs. per 7-inch reel
Product Dimensions
2.90 ± 0.2
(.114 ± .008)
Bourns
Part No.
CM322522-R12ML
CM322522-R15ML
CM322522-R18ML
CM322522-R22*L
CM322522-R27*L
CM322522-R33*L
CM322522-R39*L
CM322522-R47*L
CM322522-R56*L
CM322522-R68*L
CM322522-R82*L
CM322522-1R0*L
CM322522-1R2*L
CM322522-1R5*L
CM322522-1R8*L
CM322522-2R2*L
CM322522-2R7*L
CM322522-3R3*L
CM322522-3R9*L
CM322522-4R7*L
CM322522-5R6*L
CM322522-6R8*L
CM322522-8R2*L
CM322522-100*L
CM322522-120*L
CM322522-150*L
CM322522-180*L
CM322522-220*L
CM322522-270*L
CM322522-330*L
CM322522-390*L
CM322522-470*L
CM322522-560*L
CM322522-680*L
CM322522-820*L
CM322522-101*L
CM322522-121*L
CM322522-151*L
0.12
0.15
0.18
0.22
0.27
0.33
0.39
0.47
0.56
0.68
0.82
1
1.2
1.5
1.8
2.2
2.7
3.3
3.9
4.7
5.6
6.8
8.2
10
12
15
18
22
27
33
39
47
56
68
82
100
120
150
µH
Inductance
Standard Other
Tol.
Tol.
(%)
(%)
Ro VE LEA
HS RS D
CO ION FRE
M SA E
PL R
IA E
NT
*
Q
Min.
± 20
± 20
± 20
± 20
± 20
± 20
± 20
± 20
± 20
± 20
± 20
± 10
± 10
± 10
± 10
± 10
± 10
± 10
± 10
± 10
± 10
± 10
± 10
± 10
± 10
± 10
± 10
± 10
± 10
± 10
± 10
± 10
± 10
± 10
± 10
± 10
± 10
± 10
N/A
N/A
N/A
± 10
± 10
± 10
± 10
± 10
± 10
± 10
± 10
±5
±5
±5
±5
±5
±5
±5
±5
±5
±5
±5
±5
±5
±5
±5
±5
±5
±5
±5
±5
±5
±5
±5
±5
±5
±5
±5
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
20
20
20
Test
Frequency
(MHz)
25.2
25.2
25.2
25.2
25.2
25.2
25.2
25.2
25.2
25.2
25.2
7.96
7.96
7.96
7.96
7.96
7.96
7.96
7.96
7.96
7.96
7.96
7.96
2.52
2.52
2.52
2.52
2.52
2.52
2.52
2.52
2.52
2.52
2.52
2.52
0.796
0.796
0.796
SRF
Min.
(MHz)
500
450
400
350
320
300
250
220
180
160
140
120
100
85
80
75
70
60
55
50
45
40
35
30
20
20
20
20
20
17
16
15
13
12
11
10
10
8
DCR
Max.
(Ω)
IDC
(mA)
0.22
0.25
0.28
0.32
0.36
0.4
0.45
0.5
0.55
0.6
0.65
0.7
0.75
0.85
0.9
1
1.1
1.2
1.3
1.5
1.6
1.8
2
2.1
2.5
2.8
3.3
3.7
5
5.6
6.4
7
8
9
10
11
11
15
450
450
450
450
450
450
450
450
450
450
450
400
390
370
350
320
290
260
250
220
200
180
170
150
140
130
120
110
80
70
65
60
55
50
45
40
70
65
2.20 ± 0.2
(.087 ± .008)
0.60 +0.3/-0.0
(.024 +.012/-.000)
3.20 ± 0.4
(.126 ± .016)
0.60 +0.3/-0.0
(.024 +.012/-.000)
0.75 +0.2
(.030 +.008)
2.50 ± 0.2
(.098 ± .008)
0.75 +0.2
(.030 +.008)
1.00 ± 0.2
(.039 ± .008)
* Enter Standard or Other Tolerance Code:
M = ±20 %, K = ±10 %, J = ±5 %
Schematic
Recommended Layout
1.9 ~ 2.4
(.075 ~ .094)
WARNING Cancer and Reproductive Harm
www.P65Warnings.ca.gov
*RoHS Directive 2002/95/EC Jan. 27, 2003 including annex and RoHS Recast 2011/65/EU June 8, 2011.
Specifications are subject to change without notice. Users should verify actual device performance in their
specific applications. The products described herein and this document are subject to specific legal disclaimers as
set forth on the last page of this document, and at
www.bourns.com/docs/legal/disclaimer.pdf
1.2 ~ 1.3
(.047 ~ .051)
DIMENSIONS:
MM
(INCHES)
1.2 ~ 1.3
(.047 ~ .051)
1.6 ~ 2.0
(.063 ~ .079)
