www.breedelectronics.com
File E61760(N)
57135 Actuator
59135 High Temperature Flange Mount Features and Benefits
F eatures
•
2 Part Magnetically Operated
•
•
Benefits
•
No standby power requirement
•
Operates through non-ferrous
Applications
•
•
•
•
59135 Sensor
•
•
Proximity Sensor
High temperature, rated to
200oC
Cross-slotted mounting holes for
optimum adjustability
Standard,high voltage or change
over contacts
300mm (12”) Teflon leads
materials such as wood,plastic or
aluminium
•
Hermetically sealed,magnetically
operated contacts continue to
operate long after optical and
other technologies fail due to
contamination
•
Simple installation and adjustment
Position and limit sensing
Security system switch
Linear actuators
Door switch
DIMENSIONS
Recommended Activating Positions:
Sensors and Matching Actuators (Note 2)
Must
Actuate
.350 (8,89)
Must
Release
1.15 (29,21)
Actuator
Sensor
57135-000
59135-010
59135-020
59135-030
Electrical Specifications and Operating Characteristics
Contact Type
Contact Rating
Voltage
Switching
Breakdown
Current
Switching
Carry
Resistance
Contact,Initial
Insulation
Capacitance
Temperature
Contact
Operating
Storage
Time
Operate
Release
Shock
Vibration
11ms 1⁄2 sine
50-2000 Hz
Watt - max.
Vdc - max.
Vdc - min.
A - max.
A - max.
Ω
- max.
Ω
- min.
p F - typ.
°C
°C
ms - typ.
ms - typ.
G - max.
G - max.
Form A
SPST-NO
F orm A
SPST-NO
F orm C
SPDT-CO
Standar d
10
200
250
0.5
1.2
0.2
10
10
High Volta ge
10
300
450
0.5
1.5
0.2
10
10
Standar d
5
175
200
0.25
1.5
0.2
10
9
0.3
-40 to + 105
-65 to + 105
1.0
1.0
50
30
0.3
-40 to + 105
-65 to + 105
1.0
1.0
100
30
0.2
-20 to + 105
-65 to + 105
1.0
1.0
100
30
Notes:
1.Flying Leads
59135-010,59135-020
20 AWG 19x32 teflon insulated,200 degree C, 300 vdc, UL1180/UL1332
59135-030
material same as above, colors white–common, red–normally open,blue–normally closed
2.Order Actuators as a separate item.
3.
Underwriters Laboratories recognition. For details on electrical specifications,contact Hamlin,Inc.
INFORMATION PROVIDED ON THIS DATA SHEET IS PROVIDED FOR
INFORMATION PURPOSES ONLY AND SHOULD NOT BE RELIED
UPON AS BEING ACCURATE FOR ANY PARTICULAR PURPOSE.
Product performance may be affected by the application to which the
product is put. Upon request,HAMLIN will assist purchasers by providing
information specific to any particular application.HAMLIN disclaims any
and all liability whatsoever for any purchaser’s reliance upon the
information contained on this data sheet without further consultation with
authorised representatives of HAMLIN.
Breed Electronics USA
Breed Electronics UK
Tel: 001 920 648 3000
•
Fax:001 920 648 3001
•
Email: sales@hamlin.com
Tel: +44 (0)1379 649700
•
Fax:+44 (0)1379 649702
•
Email: uksales@breedtech.com
Breed Electronics German y
Tel: +49 (0) 6181 953660
•
Fax:+49 (0) 6181 9536666
•
Email: hamlin-electronics.de@breedtech.com
Breed Electronics France
Tel: +33 1 46 87 02 02
•
Fax:+33 1 46 86 67 86
•
Email: hamectrol@hamectrol.fr
PA GE 1 OF 1
ISSUE No:1
DATE:08/12/00
SIGNED:Antony Howell
