MAAOA/215
MAAOA/215-Series
TOGGLE SWITCHES
The MAAOA/215-Series toggle switches are single pole, AC rated at 20 amps and 125 VAC. These switches
are snap-in mounted, with a phenolic toggle and base, and are suitable for high ambient temperature
applications.
Product Highlights:
High temperature Phenolic base and toggle
Ratings to 125VAC
Optional embossed On-Off legend
Choice of screw, .250 Tab or integrated wire
lead connections
Typical Applications:
Coffee Makers
Food Warmers
Carling Technologies, Inc.
60 Johnson Avenue, Plainville, CT
06062
Email:
sales
@
carlingtech.com
Application Support:
team2
@
carlingtech.com
Phone:
860.793.9281
Fax:
860.793.9231
www.carlingtech.com
2 |
MAAOA/215-Series Toggle Switches - General Specifications, Ordering Scheme, Dimensional Specifications
Dielectric Strength
Electrical Life
25,000 cycles
UL/CSA: 1000V - live to dead
metal parts & opposite polarity
Mechanical Life
100,000 cycles
Operating Temperature
32°F to 185°F (0°C to 85°C)
1
Base Part Number
MAAOA
2
Color
BL / ON-OFF
3
Legend
1 BASE PART NUMBER: SERIES / CIRCUITRY / RATING /
TERMINATION
10A 250 VAC, 20A 125 VAC, 1/2 HP 125-250 VAC
.250
Tabs
Screw Terms.
Wire Leads
Single Pole
On-Off
MAAOA
215
215A
(On)-Off
MM-021
-
-
Notes:
Panel Cut-Out recommendations: For sheet metal panels, switch must enter panel in same
direction as the punch. (Burr on bottom.) Test cut hole in actual material.
1
Imprinting is available. ON-OFF legend is not standard and must be specified after
color. If not specified, switch will be manufactured with no legend.
( ) Indicates momentary function.
2 BASE & ACTUATOR COLOR
BL
Black
3 LEGEND
1
On-Off
BN
Brown
.075[1.90] DIA
.365[9.27]
.250[6.35]
.420[10.67]
.250 TAB (Q.C.)
#6-32NC-2
THREAD
6.000[152.4]
.500[12.70]
.270[6.86]
SCREW
(ASSEMBLED)
INTEGRATED WIRE LEAD
(no exposed conductors)
TERMINAL TYPE
1.218[30.94]
.906[23.01]
.156[3.96]
.656[16.66]
.379[9.63]
MOUNTING HOLE
Panel Thickness: .030[.762] min - .090 [2.28] max.
Specific cutout dimension range
dependent on panel thickness and material.
TEST CUT HOLE
IN ACTUAL
MATERIAL
*Manufacturer reserves the right to change product specification without prior notice.
