21.05.2018
RAFIX 22 QR - Lamp socket assembly, spring-type terminals,
with coupling
1.71.214.001/0000
Dimensions
Dimensions with coupling
Mounting depth without cable
Mechanical design
Mounting
Diode and resistor
Terminals
Terminal marking
Lamp characteristics
Lamp socket
Operating voltage AC/DC
Lamp power max.
Lamp voltage
Other specifications
Approvals
Robustness
Shock resistance acc. to IEC 60068-2-27
Resistance to vibrations acc. to IEC 60068-2-6
Environmental restistance
Storage temperature min.
Ambient temp. operating max.
Ambient temp. operating min.
Storage temperature max.
Flame class acc. to UL 94
Hot wire ignition acc. to IEC 60695-2-1
ROHS compliant
REACH compliant
with contact block
39.5 x 49.9 x 30 mm
56.4 mm
snap on coupling and actuator
no
spring type
X1 = anode, X2 = cathode
BA 9 s
6 ... 250 V
2W
6 ... 250 V
ENEC 10/15; ULc
acc. to IEC 60947-5-5
50 g at 11 ms, amplitude half sinusoidal
10 g at 40 ... 500 Hz
acc. to IEC 60068-2-14, -30, -33 and -78
-40 °C
+70 °C
-25 °C
+80 °C
V0
yes
yes
yes
Technical data are approximate and intended solely for general orientation in the selection of a product.
Subject to modifications and errors. Images and other graphics may only be similar.
